1
4
WIRE-WOUND CHIP INDUCTORS (LB SERIES)
WIRE-WOUND CHIP INDUCTORS （LB SERIES）
■PARTS
NUMBER
*Operating Temp. : -40½+105℃（Including self-generated heat）
REFLOW
L
①
B
△ △
②
2
0
③
1
2
T
④
1
0 0
⑤
M △ △ △ △
⑥ ⑦
⑧
④Packaging
Code
T
△＝Blank space
①Series name
Code
LB
②Characteristics
Code
△△
△C
△R
MF
③Dimensions（L×W）
Code
1608
2012
2016
2518
3218
3225
Series name
Wound chip inductor
Packaging
Taping
Characteristic
Standard
High current
Low Rdc
Low loss
⑤Nominal inductance
Code
（example）
1R0
100
101
※R＝Decimal point
⑥Inductance tolerance
Code
K
M
⑦Special code
Code
△
R
⑧Internal code
INDUCTORS STANDARD INDUCTORS
Nominal inductance［μH½
1.0
10
100
Type（inch）
1608（0603）
2012（0805）
2016（0806）
2518（1007）
3218（1207）
3225（1210）
Dimensions
（L×W）［mm½
1.6×0.8
2.0×1.25
2.0×1.6
2.5×1.8
3.2×1.8
3.2×2.5
／
Inductance tolerance
±10％
±20％
Special code
Standard
Low Rdc type
■STANDARD
EXTERNAL DIMENSIONS / STANDARD QUANTITY
Recommended Land Patterns
Surface Mounting
・Mounting and soldering conditions should be checked beforehand.
・Applicable soldering process to these products is reflow soldering
Type
A
1608
0.55
MF1608
0.55
2012
0.60
2016
0.60
2518
0.60
3218
0.85
3225
0.85
only.
B
0.7
0.7
1.0
1.0
1.5
1.7
1.7
C
0.9
1.0
1.45
1.8
2.0
2.0
2.7
Unit：mm
Type
LB
1608
L
1.6±0.1
（0.063±0.004）
1.6±0.2
（0.063±0.008）
2.0±0.2
（0.079±0.008）
2.0±0.2
（0.079±0.008）
2.5±0.2
（0.098±0.008）
3.2±0.2
（0.128±0.008）
3.2±0.2
（0.128±0.008）
W
0.8±0.1
（0.031±0.004）
0.8±0.2
（0.031±0.008）
1.25±0.2
（0.049±0.008）
1.6±0.2
（0.063±0.008）
1.8±0.2
（0.071±0.008）
1.8±0.2
（0.071±0.008）
2.5±0.2
（0.098±0.008）
T
0.8±0.1
（0.031±0.004）
0.8±0.2
（0.031±0.008）
1.25±0.2
（0.049±0.008）
1.6±0.2
（0.063±0.008）
1.8±0.2
（0.071±0.008）
1.8±0.2
（0.071±0.008）
2.5±0.2
（0.098±0.008）
e
0.35±0.15
（0.014±0.006）
0.45±0.15
（0.016±0.006）
0.5±0.2
（0.020±0.008）
0.5±0.2
（0.020±0.008）
0.5±0.2
（0.020±0.008）
0.6±0.2
（0.024±0.008）
0.6±0.3
（0.024±0.012）
Standard quantity [pcs]
Paper tape
Embossed tape
4000
－
－
－
－
－
－
－
3000
3000
2000
2000
2000
1000
Unit：mm（inch）
LBMF1608
LB
LB
LB
LB
LB
LB
LB
LB
LB
2012
C2012
R2012
2016
C2016
2518
C2518
R2518
3218
LB C3225
i_wound_LB_e-E02R01
▶
This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our specification.
For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our Web site (http://www.ty-top.com/) .
1
