Metallized Polyester Film Capacitors
EPOXY COATED, NON-INDUCTIVE, CAPACITORS,
REDUCED SIZE, RADIAL LEAD
FEATURES
• NON-INDUCTIVE CONSTRUCTION
• EPOXY RESIN COATED FOR EXCELLENT MOISTURE RESISTANCE
• METALLIZED CONTRUCTION PROVIDE SELF HEALING CHARACTERISTICS
• HIGH STABILITY WITH FREQUENCY OVER AN EXTENDED OPERATING LIFE
• HIGH PERFORMANCE AT LOW COST
• REDUCED SIZE
• LEAD FORMING AND CUT LEADS AVAILABLE
NRM-S Series
includes all homogeneous materials
RoHS
Compliant
SPECIFICATIONS
Operating Temperature
Rated Voltage (VDC)
Capacitance Range
Capacitance Tolerance
Insulation Resistance
Dissipation Factor
Dielectric Strength
-40°C ~ +85°C
100V, 250V, 400V, 630V
0.01μF ~ 10μF
±10% (K), ±5% (J)
C < 0.33μF IR > 9,000 Megohm
C > .33μF IR > 3,000 Megohm/μF
1% (at 1KHz/25°C)
150% of Rated Voltage for 5 Seconds
*See Part Number System for Details
L max.
T max.
H max.
*2mm max. L > 20mm
1.5mm max. L < 20mm
PART NUMBER SYSTEM
NRM-S 104
K 250
F2
F
LL = 25mm min.
dφ
RoHS compliant
Special Lead Forming
Voltage (VDC)
Tolerance Code J =
±5%,
K =
±10%
Capacitance code in pF,
fi
rst two digits are
significant, third digit is no. of zeros.
E.G. 102 = .001μF, 103 = .01μF, 104 = .1μF
S ± 1mm
LEAD SPACING (BULK) AND DIAMETER (mm)
L
13.0
18.0
26.0
31.0
S
10.0
15.0
22.5
27.5
0.6
0.8
0.8
0.8
dφ
SEE TAPING SPECIFICATION FOR PARTS ON TAPE
Series
STANDARD PRODUCTS AND CASE SIZE TABLE (mm)
Cap. (μF)
0.01
0.015
0.022
0.033
0.047
0.068
0.1
0.15
0.22
0.33
0.47
0.68
1.0
1.5
2.2
3.3
4.7
6.8
10.0
®
100VDC/63VAC
L
T
H
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
12.5
6.5
10.5
12.5
7.0
12.0
18.5
8.5
13.0
18.5
7.5
15.5
18.5
9.0
16.5
26.0
8.0
16.5
26.0
9.5
17.5
26.0 11.0 21.0
250VDC/160VAC
L
T
H
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
12.5
8.5
10.5
12.5
7.0
12.0
18.5
6.0
12.5
18.5
7.0
13.5
18.5
8.0
16.0
18.5
9.5
17.5
26.0
9.0
17.5
26.0 11.0 19.5
26.0 12.5 22.5
31.0 14.0 22.5
31.0 16.0 28.5
400VDC/200VAC
L
T
H
-
-
-
-
-
-
-
-
-
-
-
-
12.5
5.5
8.5
12.5
6.0
10.0
12.5
7.0
11.0
18.5
5.5
12.0
18.5
6.5
13.0
18.5
7.5
14.0
18.5
8.5
16.5
26.0
7.5
17.0
26.0
8.5
18.5
31.0
9.5
19.0
31.0 11.5 21.5
-
-
-
-
-
-
-
-
-
-
-
-
630VDC/220VAC
L
T
H
12.5
5.0
8.5
12.5
5.5
8.5
12.5
5.5
10.5
12.5
6.5
11.0
12.5
7.5
12.0
18.5
6.5
11.5
18.5
7.0
13.5
18.5
8.0
16.0
18.5
9.5
17.5
26.0
8.5
18.0
26.0 10.5 19.0
26.0 12.0 22.0
31.0 13.5 22.0
31.0 18.5 25.0
31.0 20.0 29.0
-
-
-
-
-
-
-
-
-
-
-
-
NIC COMPONENTS CORP.
www.niccomp.com
www.lowESR.com
www.RFpassives.com
www.SMTmagnetics.com
Specifications are subject to change
1
Radial Lead Taping Specifications
TAPE & REEL FOR RADIAL LEAD CAPACITOR
REFER TO EIA STANDARD RS-468
CRIMPED LEAD TAPING
(STANDARD)
P
2
P
Film Capacitors
STRAIGHT LEAD TAPING
(SPECIAL) Contact NIC for Availability*.
P
2
P
P
1
H
1
L
F
H
0
W
2
H
2
W
1
W
0
W
L
P
1
F
W
2
W
1
W
0
W
P
0
I
0
D
0
I
P
0
I
0
D
0
Δh
B max.
*NOTE:
STANDARD LEAD SPACING ON
TAPED PARTS IS 5MM. SPECIAL 7.5MM,
10MM AND 15MM LEAD SPACING
MAY BE AVAILABLE UPON SPECIAL
REQUEST.
TO SPECIFIC:
LEAD SPACING
P/N SUFFIX
5MM
TR
7.5MM
TR (7.5MMLS)
10MM
TR (10MMLS)
P
P
0
P
2
P
1
F*
Δh
W
W
1
H
1
H
2
H
0
I
I
0
φD
0
W
0
t
W
2
L
Dimensions MM (inch)
12.7 ± 1.0
(0.5 ± 0.0394)
12.7 ± 0.2
(0.5 ± 0.008)
6.35 ± 1.3
(.025 ± 0.051)
3.85 ± 0.5
(0.152 ± 0.020)
5.0 ± 0.8
(0.197 ± 0.0315)
0 ± 2.0
(0 ± 0.0787)
18.0 ± 0.5
(0.709 ± 0.020)
9.0 ± 0.5
(0.354 ± 0.020)
20.0 ± 0.75
(0.787 ± 0.030)
18.0 ± 0.5
(0.709 ± 0.020)
16.0 ± 0.5
(0.630 ± 0.020)
2.0 max.
(0.079 max.)
7.0 max.
(0.276 max.)
4.0 ± 0.2
(0.157 ± 0.008)
12.5 min.
(0.492 min.)
0.7 ± 0.2
(0.028 ± 0.008)
3.0 max.
(0.118 max.)
11.0 max.
(0.433 max.)
t
AMMO BOX PACKING TB (TAPE BOX)
REEL PACKING TR (TAPE/REEL)
A
B
W
1
W
2
A
B
C
D
®
A – 15mm
B – 80mm
D – 370mm
www.lowESR.com
W
1
W
2
–
–
45mm
55mm
www.SMTmagnetics.com
2
NIC COMPONENTS CORP.
www.niccomp.com
www.RFpassives.com
Specifications are subject to change
