54291050001E datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> 54291050001E

54291050001E: DescriptionBarrier Strip Terminal Block; CategoryThe connector; File Size298KB，1 Pages; ManufacturerAPEM

Download Datasheet Parametric View All

54291050001E Overview

Barrier Strip Terminal Block

54291050001E Parametric

Parameter Name	Attribute value
Objectid	1480522294
Reach Compliance Code	compliant
ECCN code	EAR99
Manufacturer's serial number	54291
Terminal and terminal strip types	BARRIER STRIP TERMINAL BLOCK

Preview

Download Datasheet

View All

Push-In |

Spacing 3.5 mm

AK4291/..KD-3.5-PEBBLE GREY

1- to n-poles

Technical Data

Wire Sizes

Solid min

solid max

Stranded (flexible)

min

Stranded (flexible)

max

0.08 mm²

1.5 mm²

0.14 mm²

1.0 mm²

Insulating Material

Material

Flammability Class

Temperatures

Operating Temperature

Wave Soldering Process

Soldering Temperature,

recommended

Peak Soldering Time,

recommended

Reflow Process

Soldering Temperature,

recommended

Peak Soldering Time,

recommended

Leere Zeile

265 °C

3-4 s

-30 °C - 105 °C

PA 6.6

UL 94 V-0

Order Data (Spacing 3.5 mm)

Poles

Width (mm)

8.50

12.00

15.50

19.00

22.50

26.00

29.50

33.00

36.50

40.00

43.50

Article Designation

AK4291/2KD-3.5-PEBBLE GREY

AK4291/3KD-3.5-PEBBLE GREY

AK4291/4KD-3.5-PEBBLE GREY

AK4291/5KD-3.5-PEBBLE GREY

AK4291/6KD-3.5-PEBBLE GREY

AK4291/7KD-3.5-PEBBLE GREY

AK4291/8KD-3.5-PEBBLE GREY

AK4291/9KD-3.5-PEBBLE GREY

AK4291/10KD-3.5-PEBBLE GREY

AK4291/11KD-3.5-PEBBLE GREY

AK4291/12KD-3.5-PEBBLE GREY

Article Number

54291020001F

54291030001F

54291040001F

54291050001E

54291060001E

54291070001E

54291080001D

54291090001D

54291100001D

54291110001D

54291120001D

200

100

Stranded with Ferrule 0.14 mm²

min

Stranded with Ferrule 0.5 mm²

max

Dimensions

Stripped Length

PCB Hole Diameter

Materials

Contact Tag

Copper Alloy

9.0 mm

1.0 mm

Accessories

Figure

Designation

Bridge, 2-pole, BR/2-5.0/5.08-L7.5

Article Number

50000000015

Colours

PEBBLE GREY

ORANGE

BLUE

LIGHT GREEN

RAL7032

RAL2011

RAL5015

similar RAL 6018

RAL7032

Bridge, 3-pole, BR/3-3.5/3.81-L7.5

50000000016

RAL2011

RAL5015

similar RAL 6018

Colours according to RAL, there may be variations on colour due to production conditions.

Special colours on request.

Bridge, 2-pole, insulated, BRI/2-7.0/7.62-

L7.5-LIGHT GREY

50000000018

Spacer SPC-AK4291-KIESELGRAU

54291000000

Ratings

Usegroup

Rated Voltage

Rated Current

Rated Wire Size

solid

stranded

Test Voltage

300 V

AWG 22-16

1.6 kV

min

0.2 mm²

130 V

max

0.75 mm²

2.0 kV
