MC SERIES
50mW (0201) to 3W (2040)
ZC SERIES
Zero-ohm Chip Jumpers
H
Industry’s widest selection -
0.1Ω to 22M, 50mW to 3W, 0.25% to 5%, TC’s to 50ppm
H
0402, 0603, 0805, 1206 sizes heavily stocked in 1% & 5%
(other sizes available from stock in many popular values)
THICK FILM CHIP RESISTORS AND JUMPERS
t
L
T
W
RESISTORS
M
CAPS &COILS
M
DELAY LINES
Industry’s lowest prices!
RCD’s Series MC resistors utilize precision thick film technology
offering inherently low inductance, exceptional reliability, and
superior performance under demanding applications. Heavy solder
plating with
NO LEACH
TM
nickel barrier assures superb solderabil-
ity and long shelf life. State-of-the-art production line enables the
industry’s most precise accuracies (as tight as 0.25% 50ppm!)
thereby replacing more costly thin-film chips in many applications.
RCD offers low cost offshore assembly of SM and leaded
PCB’s. Why not consider us to assemble your products?
MC Voltage TYPE ZC
Rating** Jumper**
25V
OPTIONS
H
Lead-free solder terminations (Option ‘W’)
H
User-trimmable chips (Option ‘U’)
H
Increased pulse capability (Option ‘P’)
H
Mil-spec screening/burn-in, special marking, non-standard
values & TC, high frequency designs, etc., are an RCD specialty!
RCD
Wattage Std TC** Res. Range
Type
C
Rating
ppm/° typ
±0.5% Tol**
MC, ZC
0201
.05W
100
200
400
100
200
400
100
200
400
100
200
400
100
200
400
100
200
400
100
200
400
100
200
400
100
200
400
Res. Range
±1% Tol**
10
Ω
to 22K
Ω
22.1K to 1M
Ω
10
Ω
to 1M
Ω
1Ω to 9.76
Ω
10
Ω
to 1M
Ω
1Ω to 9.76
Ω
10
Ω
to 1M
Ω
Resis Range
±5% Tol**
10
Ω
to 1M
Ω
1- 9.1
Ω
,1.1M- 2.2M
10
Ω
to 1M
Ω
1- 9.1
Ω
,1.1M- 4.7M
10
Ω
to 1M
Ω
1- 9.1
Ω
,1.1M- 10M
Dimensions
Inch [mm]
L
W
T
t
1 Amp Max. .024±.002 .012±.002 .010±.002 .006±.002
50m
Ω
Max. [0.6±.03] [.3±.03] [.25±.03] [.15±.05]
1 Amp Max. .040±.004 .020±.004 .014±.004 .010±.004
50m
Ω
Max. [1.00±.1]
[.5±.1]
[.35±.1]
[.25±.1]
1 Amp Max. .061±.005 .031±.004 .016±.006 .010±.006
50m
Ω
Max. [1.55±.12] [.8±.1]
[.40±.15] [.25±.15]
1.5Amp
.079±.005 .050±.006 .020±.006 .016±.008
Max.
[2.0±.15] [1.25±.15] [.50±.15]
[.4±.2]
50m
Ω
Max.
2 Amp Max. .126±.008 .061±.006 .024±.006 .020±.008
50m
Ω
Max. [3.2±.2] [1.55±.15] [.61±.15] [.51±.2]
3 Amp Max. .126±.008 .098±.008 .024±.008 .020±.010
50m
Ω
Max. [3.2±.2]
[2.5±.2]
[.6±.2]
[.5±.25]
3 Amp Max. .197±.008 .102±.008 .024±.008 .020±.010
50m
Ω
Max. [5.0±.2]
[2.6±.2]
[.6±.2]
[.50±.25]
4 Amp Max. .250±.01 .125±.010 .024±.008 .034±.021
50m
Ω
Max. [6.35±.25] [3.2±.25]
[.6±.2]
[.86±.53]
N/A
.201±.008 .402±.008 .024±.008 ±.018
[5.1±.2] [10.2±.2]
[.6±.2]
[1.4±.46]
0402
.063W
Stock i tem
0603
Stock i tem
.1W
50V
10
Ω
to 1M
50V
0805
.125W
Stock i tem
1206
.25W
Stock i tem
1210
.33W
10
Ω
to 1M
10
Ω
to 1M
10
Ω
to 1M
10
Ω
to 1M
2010
.75W
10
Ω
to 1M
2512
1.0W
2040
2.0/3.0*
10
Ω
to 1M
Ω
0.1-9.76
Ω
, 1.02M-10M 0.1-9.1
Ω
, 1.1M-20M
10
Ω
to 1M
Ω
1.02M to 5.6M
10
Ω
to 5.6M
Ω
0.1-9.76
Ω,
5.62M-10M 0.1-9.1
Ω
, 6.2M-22M
10
Ω
to 1M
Ω
1.02M to 5.6M
10
Ω
to 5.6M
Ω
0.1-9.76
Ω,
5.62M-10M 0.1-9.1
Ω
, 6.2M-22M
10
Ω
to 1M
Ω
1.02M to 5.6M
10
Ω
to 5.6M
Ω
0.1-9.76
Ω,
5.62M-10M 0.1-9.1
Ω
, 6.2M-22M
10
Ω
to 1M
Ω
1.02M to 5.6M
10
Ω
to 5.6M
Ω
0.1-9.76
Ω,
5.62M-10M 0.1-9.1
Ω
, 6.2M-22M
10
Ω
to 1M
Ω
10
Ω
to 1M
Ω
1- 9.1
Ω
150V
200V
200V
200V
250V
350V
* 2040 chips may be operated up to 3W with consideration of mounting density, termination pad area, board material, and ambient temperature to control self-heating to 155° ** Extended range avail.
C.
TYPICAL PERFORMANCE
Thermal Shock (-55° to +125° )
C
Overload (2.5x W, 5S, NTE 2x rated V)
Low Temp. Operati on (-55° )
C
Hi gh Temp. Exposure (125° , 100hrs)
C
Resi stance to Solder Heat
Moi sture Resi stance
Load Li fe(1000 hrs.)
Operati ng Temp. (+175° avail.)
C
Power D erati ng (above 70° )
C
0.2%
∆R
1%
∆R
0.2%
∆R
0.5%
∆R
0.2%
∆R
0.5%
∆R
1.0%
∆R
-55 to +155°
C
Derate by 1.18%/°
C
PULSE WITHSTAND CHART
(increased pulse levels avail.)
500
Peak Power (Watts)
100
MC2512P
MC2010P
MC1210P
MC1206P
MC0805P
MC0603P
MC0402P
1uS
10uS
100uS
1mS
10mS
100mS
10
P/N DESIGNATION:
MC 1206
- 2210 - F T
1
RCD Type:
MC or ZC
Chip Size:
0201 to 2040
Options:
W, U, P, etc (leave blank if std)
Resis. Value:
4 digit code if tol. is 0.25% to 1%
(R100= .1Ω, 1R00=1Ω, 10R0=10Ω, 1000=100Ω, 1001=1KΩ)
3 digit code if tol. is 2% or 5% (R10=0.1Ω, 1R0=1Ω, 100=10Ω,
101=100Ω, 102=1KΩ) Leave blank on ZC zero-ohm chips
Tolerance:
J=5%, G=2%, F=1%, D=0.5%, C=0.25%
Leave blank on ZC zero-ohm chips. Opt.U trimmable
chips use W=±15%, M=±20%, U=0 to +30%
Pulse Duration
Packaging:
B=Bulk, T=Tape & Reel
TC:
50=50ppm, 101=100ppm, 201=200ppm (leave
blank if std)
Pulse capability is dependent on res. value, waveform, repetition, etc.
Chart is a general guide for Opt. P version, single or infrequent pulses,
with peak voltage levels not exceeding 150V for 0402 & 0603 size,
300V for 0805, 400V for 1206 & 1210, 450V for 2010 & 2512. Max
pulse wattage for standard parts (w/o Opt.P) is 50% less, max pulse
voltage is 50V less. Increased pulse levels available. For improved
performance and reliability, a 30% pulse derating factor is recommended
(50% for frequent pulses, high values, etc). Consult RCD for application
assistance. Verify selection by evaluating under worst-case conditions.
RCD Components Inc.,
520 E. Industrial Park Dr., Manchester, NH USA 03109
Tel: (603) 669-0054 Fax:(603) 669-5455 E-mail: sales@rcdcomponents.com
www.rcdcomponents.com
FA033C Specifications subject to change without notice
