F-213-1
ZSS–113–03–L–D–0735
HTSS–125–01–L–DV
(2,54 mm) .100"
TSS, HTSS, ZSS SERIES
SHROUDED .025" SQ POST HEADERS
Mates with:
SSW, SSQ, ESW, ESQ,
SSM, BCS
TYPE
STRIP
1
NO. PINS
PER ROW
LEAD
STYLE
Specify
LEAD
STYLE
from
chart.
PLATING
OPTION
ROW
OPTION
SPECIFICATIONS
For complete specifications
see www.samtec.com?TSS,
www.samtec.com?HTSS or
www.samtec.com?ZSS
Insulator Material:
Black Glass
Filled Polyester
(TSS, ZSS)
Natural PCT (HTSS)
Insulation Resistance:
5000 MΩ min
Terminal Material:
Phosphor Bronze
Plating:
Au or Sn over
50µ" (1,27 µm) Ni
Current Rating:
3A per contact
Operating Temp Range:
-55°C to +125°C with Gold
-55°C to +105°C with Tin
Flammability Rating:
UL 94V-O
Withstanding Voltage:
1000 VRMS
RoHS Compliant:
Yes
TSS
= Connector Strip
05, 07, 08, 10,
12, 13, 15, 17,
20, 25, 32, 36
(Call Samtec for other sizes.)
–F
= Gold flash on post,
Matte Tin on tail
(Not available on -DV)
–D
= Double Row
Through-hole
(lead style –01,
–02 & –03 only)
HTSS
= High Temp
Connector Strip
–L
= 10µ" (0,25 µm)
Gold on post,
Matte Tin on tail
–DV
= Double Row
Surface Mount
(lead style
–01 only)
(HTSS only)
LEAD
STYLE
–01
–02
–03
T/H
(A)
(2,92)
.115
(4,19)
.165
(14,35)
.565
(2,54) .100 x No. of Positions + (7,62) .300
(2,54) .100 x No. of Positions + (5,08) .200
(2,54)
.100
–T
= Matte Tin
LEAD RIGHT
STYLE ANGLE
(B)
–04
(3,30) .130
–05
(5,84) .230
(10,16)
.400
(6,35)
.250
02
(9,27)
.365
01
–D–RA
B
= Double Row
Right Angle
(lead style –04
& –05 only)
(2,54)
.100
(8,89)
.350
(5,08)
.020
A
–D
Processing:
(0,38)
.015
(11,18) .440
(0,64) .025 SQ TYP
Lead–Free Solderable:
Yes (HTSS)
Wave Only (TSS, ZSS)
SMT Lead Coplanarity:
(0,15 mm) .006"
–DV
(HTSS ONLY)
–D–RA
ALSO
AVAILABLE
Shrouded IDC headers
and stackers to mate
with IDSD, SMSD Series.
See TST, HTST and
ZST Series.
ZSS
1
NO. PINS
PER ROW
LEAD
STYLE
Specify
LEAD
STYLE
from
chart.
PLATING
OPTION
D
BODY
HEIGHT
–F
= Gold flash on post,
Matte Tin on tail
05, 07, 08, 10, 12, 13,
15, 17, 20, 25, 32, 36
(Call Samtec for other sizes.)
(2,54) .100 x No. of Positions + (3,81) .150
(2,54) .100 x No. of Positions + (1,27) .050
02
–“XXXX”
= Body Height
LEAD
STYLE
–01
–02
–03
–04
–05
–06
–07
–08
–09
C
(OAL)
(16,00) .630
(18,54) .730
(21,08) .830
(23,62) .930
–L
= 10µ" (0,25 µm)
Gold on post,
Matte Tin on tail
MAX BODY
HEIGHT
(13,72) .540
(16,26) .640
(18,80) .740
(21,34) .840
APPLICATION
SPECIFIC OPTION
• Alignment Pins
• Single Row
• Locking Leads
• Polarized
Call Samtec.
Note:
Other Gold plating
options available.
Contact Samtec.
Note:
Some lengths, styles
and options are non-standard,
non-returnable. ZSS is
non-standard, non-returnable.
(9,27)
.365
(2,54)
.100
–T
= Matte Tin
01
(2,54)
.100
(6,35)
.250
(2,29)
.090
MIN
(0,64) .025 SQ TYP
(26,16) 1.030 (23,88) .940
(28,70) 1.130 (26,42) 1.040
(31,24) 1.230 (28,96) 1.140
(33,78) 1.330 (31,50) 1.240
(36,32) 1.430 (34,04) 1.340
(8,89)
.350
(0,38)
.015
BODY
HEIGHT
C
(OAL)
(2,54)
.100
Note:
For added mechanical stability, Samtec
recommends mechanical board spacers be
used in applications with gold or selective
gold plated connectors. Contact ipg@
samtec.com for more information.
WWW.SAMTEC.COM
