Multilayer Ceramic Chip Capacitors
FEATURES
• X7R, X5R AND Y5V DIELECTRICS
• HIGH CAPACITANCE & LOW PROFILE
• RoHS COMPLIANT
• SAC SOLDER COMPATIBLE
RoHS
Compliant
NMC-T Low Profile Series
Includes all homogeneous materials
*See Part Number System for Details
Temperature Coefficient
X7R
X5R
Y5V
Capacitance Range
1.0μF
0.22μF ~ 22μF
1.0μF ~ 10μF
Capacitance Tolerance
10% (K) & 20% (M)
10% (K) & 20% (M)
+80%/-20% (Z)
Operating Temperature Range
-55°C ~ +125°C
-55°C ~ +85°C
-25°C ~ +85°C
Temperature Characteristics
±15%
Δ
Cap.
±15%
Δ
Cap.
+30%, -80%
Δ
Cap.
Rated Voltages
25VDC
6,3, 10, 16 & 25VDC
10, 16, 25 & 50VDC
Dissipation Factor
10%
6.3V: 15%, 10V, 16V & 25V: 10% 10V & 16V: 12.5%, 25V: 9%, 50V: 7%
insulation Resistance
500Megohm/μF minimum @ +25°C
Dielectric Withstanding Voltage
250% of Rated Voltage for 5 ± 1 sec., 50mA max.
Test Conditions (EIA-198-2E)
1KHz, 1.0V ±0.2Vrms (ALC on), for C > 10μF 120Hz, 0.5 ±0.2 VRMS (ALC on)
*Reflow soldering is recommended. Contact NIC regarding the use of other soldering methods.
PART NUMBER SYSTEM
NMC-T 0603 X5R 105 K 16 TRP or TRPLP R60
F
RoHS Compliant
Maximum Thickness
R33 = 0.33mm,
R60 = 0.6mm,
R95 = 0.95mm, 1R3 = 1.3mm
Tape & Reel (Embossed Plastic Carrier)
Tape & Reel (Punched carrier)
Voltage (Vdc)
Capacitance Tolerance Code (see chart)
Capacitance Code, expressed in pF,
fi
rst 2 digits are
significant, 3rd digit is no. of zeros
Temperature Characteristic (X7R, X5R OR Y5V)
Size Code (see dimensions table)
Series
®
NIC COMPONENTS CORP.
www.niccomp.com
www.lowESR.com
www.RFpassives.com
www.SMTmagnetics.com
SPECIFICATIONS ARE SUBJECT TO CHANGE
1
Multilayer Ceramic Chip Capacitors
PART NUMBERS AND SPECIFICATIONS
Part Number
NMC-T0402X5R224_25TRPR33F
NMC-T0402X5R474_25TRPR33F
NMC-T0402X5R105_6.3TRPR33F
NMC-T0603X5R224_10TRPR60F
NMC-T0603X5R224_16TRPR60F
NMC-T0603X5R105_10TRPR60F
NMC-T0603X5R105_16TRPR60F
NMC-T0805X5R105_10TRPR95F
NMC-T0805X5R105_16TRPR95F
NMC-T0805X5R105_25TRPR95F
NMC-T0805Y5V105Z50TRPR95F
NMC-T0805X5R155_10TRPR95F
NMC-T0805X5R155_16TRPR95F
NMC-T0805X5R225_6.3TRPR95F
NMC-T0805X5R225_10TRPR95F
NMC-T0805X5R225_16TRPR95F
NMC-T0805Y5V225Z16TRPR95F
NMC-T0805Y5V335Z10TRPR95F
NMC-T0805X5R475_6.3TRPR95F
NMC-T0805X5R475_10TRPR95F
NMC-T0805Y5V475Z10TRPR95F
NMC-T0805X5R475_16TRPR95F
NMC-T0805Y5V475Z16TRPR95F
NMC-T0805X5R106_6.3TRPR95F
NMC-T0805X5R106_10TRPR95F
NMC-T0805Y5V106Z10TRPR95F
NMC-T0805X5R226M6.3TRPR95F
NMC-T1206X5R105_10TRPR95F
NMC-T1206X5R105_16TRPR95F
NMC-T1206X5R105_25TRPR95F
NMC-T1206X7R105_25TRPR95F
NMC-T1206X5R155_10TRPR95F
NMC-T1206X5R155_16TRPR95F
NMC-T1206X5R155_25TRPR95F
NMC-T1206X5R225_10TRPR95F
NMC-T1206Y5V225Z10TRPR95F
NMC-T1206X5R225_16TRPR95F
NMC-T1206Y5V225Z16TRPR95F
NMC-T1206X5R225_25TRPR95F
NMC-T1206Y5V225Z25TRPR95F
NMC-T1206Y5V225Z50TRPR95F
NMC-T1206X5R335_10TRPR95F
NMC-T1206X5R335_16TRPR95F
NMC-T1206X5R335_25TRPR95F
NMC-T1206X5R475_10TRPR95F
NMC-T1206Y5V475Z10TRPR95F
NMC-T1206X5R475_16TRPR95F
NMC-T1206Y5V475Z16TRPR95F
NMC-T1206X5R475_25TRPR95F
NMC-T1206Y5V685Z10TRPR95F
NMC-T1206X5R106_6.3TRPLP1R3F
NMC-T1206X5R106_10TRPLPR95F
NMC-T1206X5R106_10TRPLP1R3F
NMC-T1206Y5V106Z10TRPR95F
NMC-T1206X5R226M6.3TRPR95F
NMC-T1210X5R335_10TRPLPR95F
NMC-T1210X5R475_10TRPLPR95F
NMC-T1210Y5V106Z10TRPLPR95F
Case
Size
0402
Cap.
(μF)
0.22
0.47
1.0
0.22
0.22
1.0
1.0
1.0
1.0
1.0
1.0
1.5
1.5
2.2
2.2
2.2
2.2
3.3
4.7
4.7
4.7
4.7
4.7
10
10
10
22
1.0
1.0
1.0
1.0
1.5
1.5
1.5
2.2
2.2
2.2
2.2
2.2
2.2
2.2
3.3
3.3
3.3
4.7
4.7
4.7
4.7
4.7
6.8
10
10
10
10
22
3.3
4.7
10
Cap.
Tolerance
±10%(K) & ±20%(M)
±10%(K) & ±20%(M)
±10%(K) & ±20%(M)
±10%(K) & ±20%(M)
±10%(K) & ±20%(M)
±10%(K) & ±20%(M)
±10%(K) & ±20%(M)
±10%(K) & ±20%(M)
±10%(K) & ±20%(M)
±10%(K) & ±20%(M)
+80%/-20%(Z)
±10%(K) & ±20%(M)
±10%(K) & ±20%(M)
±10%(K) & ±20%(M)
±10%(K) & ±20%(M)
±10%(K) & ±20%(M)
+80%/-20%(Z)
+80%/-20%(Z)
±10%(K) & ±20%(M)
±10%(K) & ±20%(M)
+80%/-20%(Z)
±10%(K) & ±20%(M)
+80%/-20%(Z)
±10%(K) & ±20%(M)
±10%(K) & ±20%(M)
+80%/-20%(Z)
±20%(M)
±10%(K) & ±20%(M)
±10%(K) & ±20%(M)
±10%(K) & ±20%(M)
±10%(K) & ±20%(M)
±10%(K) & ±20%(M)
±10%(K) & ±20%(M)
±10%(K) & ±20%(M)
±10%(K) & ±20%(M)
+80%/-20%(Z)
±10%(K) & ±20%(M)
+80%/-20%(Z)
±10%(K) & ±20%(M)
+80%/-20%(Z)
+80%/-20%(Z)
±10%(K) & ±20%(M)
±10%(K) & ±20%(M)
±10%(K) & ±20%(M)
±10%(K) & ±20%(M)
+80%/-20%(Z)
±10%(K) & ±20%(M)
+80%/-20%(Z)
±10%(K) & ±20%(M)
+80%/-20%(Z)
±10%(K) & ±20%(M)
±10%(K) & ±20%(M)
±10%(K) & ±20%(M)
+80%/-20%(Z)
±20%(M)
±10%(K) & ±20%(M)
±10%(K) & ±20%(M)
+80%/-20%(Z)
Dielectric
X5R
X5R
X5R
X5R
X5R
X5R
X5R
X5R
X5R
X5R
Y5V
X5R
X5R
X5R
X5R
X5R
Y5V
Y5V
X5R
X5R
Y5V
X5R
Y5V
X5R
X5R
Y5V
X5R
X5R
X5R
X5R
X7R
X5R
X5R
X5R
X5R
Y5V
X5R
Y5V
X5R
Y5V
Y5V
X5R
X5R
X5R
X5R
Y5V
X5R
Y5V
X5R
Y5V
X5R
X5R
X5R
Y5V
X5R
X5R
X5R
Y5V
NMC Low Profile Series
Voltage
(Vdc)
25
25
6.3
10
16
10
16
10
16
25
50
10
16
6.3
10
16
16
10
6.3
10
10
16
16
6.3
10
10
6.3
10
16
25
25
10
16
25
10
10
16
16
25
25
50
10
16
25
10
10
16
16
25
10
6.3
10
10
10
6.3
10
10
10
Withstanding
Voltage
62.5
62.5
15.75
25
40
25
40
25
40
62.5
125
25
40
15.75
25
40
40
25
15.75
25
25
40
40
15.75
25
25
15.75
25
40
62.5
62.5
25
40
62.5
25
25
40
40
62.5
62.5
125
25
40
62.5
25
25
40
40
62.5
25
15.75
25
25
25
15.75
25
25
25
Min. Insulation
Resistance (MΩ)
2272.7
1063.0
500.0
2272.7
2272.7
500.0
500.0
500.0
500.0
500.0
500.0
333.3
333.3
227.3
227.3
227.3
227.3
151.5
106.4
106.4
106.4
106.4
106.4
50.0
50.0
50.0
22.7
500.0
500.0
500.0
500.0
333.3
333.3
333.3
227.3
227.3
227.3
227.3
227.3
227.3
227.3
151.5
151.5
151.5
106.4
106.4
106.4
106.4
106.4
73.5
50.0
50.0
50.0
50.0
22.7
151.5
106.4
50.0
0603
0805
1206
1210
"_" insert desired capacitance tolerance code
®
