IHLP-5050EZ-01
Vishay Dale
Low Profile, High Current
IHLP
®
Inductors
FEATURES
• Shielded construction
• Frequency range up to 5.0 MHz
• Lowest DCR/µH, in this package size
• Handles high transient current spikes without saturation
Manufactured under one or more of the following:
US Patents; 6,198,375/6,204,744/6,449,829/6,460,244.
Several foreign patents, and other patents pending.
• Ultra low buzz noise, due to composite construction
• Compliant to RoHS directive 2002/95/EC
STANDARD ELECTRICAL SPECIFICATIONS
L
0
DCR
INDUCTANCE
± 20 % AT 100 kHz, TYP.
25 °C
0.25 V, 0 A
(mΩ)
(µH)
0.10
0.22
0.33
0.47
0.56
0.68
0.82
1.0
1.5
1.8
2.2
3.3
4.7
5.6
6.8
7.8
8.2
10
0.53
0.64
0.85
1.1
1.3
1.5
2.0
2.1
3.4
4.2
4.6
7.7
12.8
14.0
15.4
17.2
18.9
21.4
HEAT
RATING SATURATION
DCR
MAX. CURRENT
CURRENT
25 °C DC TYP.
DC TYP.
(A)
(3)
(mΩ)
(A)
(4)
0.60
0.80
1.1
1.3
1.5
1.7
2.3
2.5
4.1
4.9
5.5
9.2
15.0
16.5
18.5
20.5
22.5
25.5
55
51
42
38
36
34
31
29
23
19
20
15
12
11.5
11
10
9.5
9.0
118
110
80
65
55
54
53
50
48
40
32
32
27
22
21
18
18
16
APPLICATIONS
• Notebook/desktop/server applications
• High current POL converters
• Low profile, high current power supplies
• Battery powered devices
• DC/DC converters in distributed power systems
• DC/DC converter for Field Programmable Gate Array
(FPGA)
DIMENSIONS
in inches [millimeters]
Typical Pad Layout
0.542
[13.76]
0.195
[4.95]
0.310
[7.87]
0.508
[12.9] Max.
Notes
(1)
All test data is referenced to 25 °C ambient
(2)
Operating temperature range - 55 °C to + 125 °C
(3)
DC current (A) that will cause an approximate
ΔT
of 40 °C
(4)
DC current (A) that will cause L to drop approximately 20 %
0
(5)
The part temperature (ambient + temp rise) should not exceed
125 °C under worst case operating conditions. Circuit design,
component placement, PWB trace size and thickness, airflow
and other cooling provisions all affect the part temperature. Part
temperature should be verified in the end application.
0.520 ± 0.02
[13.2 ± 0.5]
0.197
[5.0] Max.
0.091 ± 0.01
[2.3 ± 0.3]
0.185 ± 0.01
[4.7 ± 0.3]
DESCRIPTION
IHLP-5050EZ-01
MODEL
1.0 µH
INDUCTANCE VALUE
± 20 %
INDUCTANCE TOLERANCE
ER
PACKAGE CODE
e3
JEDEC LEAD (Pb)-FREE STANDARD
GLOBAL PART NUMBER
I
H
L
P
5
0
5
SIZE
0
E
Z
E
R
1
R
INDUCTANCE
VALUE
0
M
TOL.
0
1
PRODUCT FAMILY
PACKAGE
CODE
SERIES
Document Number: 34126
Revision: 02-Jun-09
For technical questions, contact:
magnetics@vishay.com
www.vishay.com
1
