Wirewound Chip Inductors
FEATURES
•
•
•
•
•
SIZES K(0402), J (0603), D (0805), C (1008), E (1206), A (1210) and B (1812)
HIGH Q, HIGH CURRENT AND HIGH SRF CHARACTERISTICS
REFLOW SOLDERING APPLICABLE
HIGH INDUCTANCE AVAILABLE IN SMALL SIZE
EMBOSSED PLASTIC CARRIER PACKAGING FOR AUTOMATIC PICK-PLACE*
NIN-H Series
*0402 PUNCHED CARDBOARD CARRIER
Specifications
Inductance Range
Inductance Tolerance
Operating Temperature Range
Specifications
Inductance Range
Inductance Tolerance
Operating Temperature Range
0402 (K)
1.0nH ~ 68nH
±0.3nH (S), ±5% (J)
Case Size Code
0603 (J)
0805 (D)
1008 (C)
1.8nH ~ 270nH
2.2nH ~ 910nH
10nH ~ 4.7μH
±2% (G), ±5% (J), ±10% (K), ±20% (M)
-40°C ~ +125°C
1812 (B)
1.0μH ~ 33μH
1206 (E)
3.3nH ~ 1.2μH
1210 (A)
3.9nH ~ 8.6μH
See Product Standard Values Tables
-40°C ~ +125°C
ENVIRONMENTAL CHARACTERISTICS
Specifications
75% Min. Coverage
(1) No evidence of damage
(2) Inductance change ±5% of initial value
Resistance to Soldering Heat
(3) Q factor within ±10% of initial value
(±20% for 0402 & 0603 case sizes)
Humidity
Low Frequency Vibration
Thermal Shock
Low Temperature Storage
High Temperature Load Life
(1) No evidence of damage
(2) Inductance change ±5% of initial value
(±10% for 0402 case size)
(3) Q factor within ±10% of initial value
(±20% for 0402 & 0603 case sizes)
(1) No evidence of damage
(2) Inductance change ±10% of initial value
(±20% for 0402 case size)
(3) Q factor within ±10% of initial value
(±20% for 0402 & 0603 case sizes)
No evidence of short or open circuit
Test
Solderability
Test Method & Condition
After 3 sec. dip in +230°C soldering pot (post
fl
ux)
After 5 seconds at +260°C (with pre-conditioning)
After 500 hours at 60°C and 90 ~ 95% RH
(0402 case size - after 96 hours 50°C and 90 ~ 95% RH)
After 2 hrs per axis, 10 ~ 55Hz, 1.5mm amplitude
After 100 cycles (10 cycles 0402) at -40°C and +125°C
(30 minutes at each temperature)
After 500 hrs at -40°C
After 500 hrs at +125°C with rated DC current
(0402 case size - after 1,000 hrs at +85°C)
After 500 hrs at 60°C with 90 ~ 95% RH with rated DC current
(0402 case size- 1,000 hrs at +40°C)
Humidity Load Life
COMPONENT DIMENSIONS (mm):
Type
NIN-HK
NIN-HJ
NIN-HD
NIN-HC
NIN-HE
NIN-HA
NIN-HB
Case Size
0402
0603
0805
1008
1206
1210
1812
A max.
1.19
1.80
2.29
2.92
3.56
3.65
4.95
B max.
0.64
1.12
1.68
2.79
2.16
2.95
3.81
C max.
0.66
1.02
1.55
2.29
1.52
2.70
3.43
D typ.
0.20
0.38
0.51
0.51
0.51
0.51
1.78
E typ.
0.523
0.76
1.27
2.10
1.60
2.10
2.90
F typ.
0.215
0.33
0.50
0.50
0.50
.050
.058
RECOMMEND LAND PATTERN
DIMENSIONS (mm)
Type
NIN-HK
NIN-HJ
NIN-HD
NIN-HC
NIN-HE
NIN-HA
NIN-HB
H typ.
0.65
1.02
1.78
2.54
1.93
3.02
3.05
I typ.
0.35
0.36
1.02
1.02
1.02
1.02
1.14
J typ.
0.50
0.46
0.76
1.27
1.78
1.78
3.00
I
D
B
C
E
H
A
F
F
J
®
14
