XC6217
Series
200mA High Speed "Green Operation" LDO Voltage Regulators
ETR03022_016
The XC6217 series are precise, low noise, high speed, low dropout regulators with green operation (GO) function. They are
fabricated using Torex’s CMOS process. Performance features of the series include high ripple rejection and low dropout voltage,
and the series include a reference voltage source, an error amplifier, a current limiter, and a phase compensation circuit.
GO provides high speed operation, low power consumption and high efficiencies by automatically switching between a high
speed mode (HS) and a power save mode (PS) depending upon the load current level. The switching point of the GO to the
output current is being fixed inside the IC. When only high-speed operation is required, it can be fixed by inputting a high level
signal to the GO pin, thus providing operating conditions with the most suitable level of supply current for the application.
The CE function enables the output to be turned off resulting in greatly reduced power consumption. In this state, with the XC6217
series B/D Type, the IC turns on the internal switch located between the V
OUT
and V
SS
pins. This short enables the electric charge
at the output capacitor (C
L
) to be discharged via the internal auto-discharge resistance, and as a result the V
OUT
pin quickly
returns to the V
SS
level. The series' output stabilization capacitor (C
L
) is also compatible with low ESR ceramic capacitors.
Output voltage is selectable in 0.05V increments within a range of 0.80V~4.00V, using laser trimming technologies.
The current limiter's foldback circuit also operates as a short circuit protection for the output current limiter and the output pin.
■GENERAL
DESCRIPTION
☆GreenOperation
Compatible
■APPLICATIONS
●Smart
phones / Mobile phones
●Portable
game consoles
●Digital
still cameras / Camcorders
●Digital
audio equipments
■FEATURES
: 200mA <Limit: 250mA
TYP.>
: 80mV@ I
OUT
=100mA, V
OUT
=3.0V
: 1.6V ~ 6.0V (0.8V≦V
OUT
≦1.55V
1.8V ~ 6.0V (1.6V≦V
OUT
≦4.0V
Output Voltage Range
: 0.80V~4.00V (0.05V increments)
Accuracy
: +2% (HS: V
OUT
>2.00V) (Standard)
+30mV (HS: V
OUT
≦1.95V)
(Standard)
+2.5%, -3.5% (PS: V
OUT
>2.60V) (Standard)
+3.5%, -4.5% (PS:1.60≦V
OUT
≦2.55V)
(Standard)
+70mV, -90mV (PS:0.80≦V
OUT
≦1.55V)
(Standard)
+1% (HS: V
OUT
>2.00V) (High Accuracy)
+20mV (HS: V
OUT
≦1.95V)
(High Accuracy)
+1.5%, -2.5% (PS: V
OUT
>2.60V) (High Accuracy)
+2.5%, -3.5% (PS:1.60≦V
OUT
≦2.55V)
(High Accuracy)
+50mV, -70mV (PS:0.80≦V
OUT
≦1.55V)
(High Accuracy)
Low Power Consumption
: TYP.4.5μA when PS mode
TYP.25μA when HS mode
Standby Current
: Less than 0.1μA
High Ripple Rejection
: 70dB @ 1kHz (When HS mode)
Low ESR Capacitor
: 1.0μF Ceramic capacitor
Regulators with Green Operation (GO) Function
C
L
High-Speed-Discharge (XC6217B/D)
Operating Ambient Temperature
:-40℃~+85℃
Packages
: USP-4D, SOT-25(XC6217 Series A/B Type)
SSOT-24,USPN-4(XC6217 Series C/D Type)
Environmentally Friendly
: EU RoHS Compliant, Pb Free
Output Current
Dropout Voltage
Operating Voltage Range
■TYPICAL
APPLICATION CIRCUIT
■
TYPICAL PERFORMANCE
CHARACTERISTICS
XC6217B281MR
2.9
2.85
V
IN
=3.8V,Tr=Tf=5usec, Ta=25℃
C
IN
=C
L
=1.0uF(Ceramic)
3
2.95
V
IN
V
OUT
VOUT_HSmode(V)
2.8
2.75
2.7
2.65
2.6
2.55
2.5
2.45
2.4
I
OUT
=0.1mA
V
OUT
_HSmode
2.9
V
OUT
_GOmode
2.8
2.75
2.7
2.65
CE
C
IN
1.0μF
(ceramic)
GO
V
SS
C
L
1.0μF
(ceramic)
Output Current I
OUT
=50mA
I
OUT
=0.1mA
2.6
2.55
2.5
Time (500usec/div)
VOUT_GOmode(V)
2.85
1/34
XC6217
Series
■PRODUCT
CLASSIFICATION
●Ordering
Information
XC6217①②③④⑤⑥-⑦
(
*1
)
DESIGNATOR
①
②③
DESCRIPTION
Type of Regulator
Output Voltage
SYMBOL
A
B
C
D
08 ~ 40
DESCRIPTION
CE High Active, no C
L
discharge resistor
CE High Active, with C
L
discharge resistor
CE High Active, no C
L
discharge resistor, no GO pin
CE High Active, with C
L
discharge resistor, no GO pin
ex.) V
OUT(T)
= 3.00V
→
②
= 3,
③
= 0
0.1V increments (Standard)
V
OUT(*2)
HS mode
V
OUT(T)
±30mV
V
OUT(T)
±30mV
V
OUT(T
)
±2%
V
OUT(T)
±2%
PS mode
V
OUT(T)
+70mV,V
OUT(T)
-90mV
V
OUT(T)
+3.5%,V
OUT(T)
-4.5%
V
OUT(T
)
+3.5%,V
OUT(T)
-4.5%
V
OUT(T
)
+2.5%,V
OUT(T
)
-3.5%
0.80V
½
1.50V
1.60V
½
1.90V
2.00V
½
2.50V
2.60V
½
4.00V
2
ex.) 2.00V Standard
→ ②=2, ③=0, ④=2
0.05V increments (Standard)
V
OUT(*2)
HS mode
V
OUT(T
)
±30mV
V
OUT(T
)
±30mV
V
OUT(T)
±2%
V
OUT(T
)
±2%
PS mode
V
OUT(T)
+70mV,V
OUT(T)
-90mV
V
OUT(T)
+3.5%,V
OUT(T)
-4.5%
V
OUT(T)
+3.5%,V
OUT(T)
-4.5%
V
OUT(T
)
+2.5%,V
OUT(T)
-3.5%
0.85V
½
1.55V
1.65V
½
1.95V
2.05V
½
2.55V
2.65V
½
3.95V
A
④
Output Accuracy
ex.) 2.05V Standard
→
②=2, ③=0, ④=A
0.1V increments (High Accuracy)
V
OUT(*2)
HS mode
V
OUT(T)
±20mV
V
OUT(T)
±20mV
V
OUT(T)
±1%
V
OUT(T)
±1%
PS mode
V
OUT(T)
+50mV,V
OUT(T)
-70mV
V
OUT(T)
+2.5%,V
OUT(T)
-3.5%
V
OUT(T
)
+2.5%,V
OUT(T)
-3.5%
V
OUT(T
)
+1.5%,V
OUT(T)
-2.5%
0.80V
½
1.50V
1.60V
½
1.90V
2.00V
½
2.50V
2.60V
½
4.00V
1
ex.) 2.00V High Accuracy
→
②=2, ③=0, ④=1
0.05V increments (High Accuracy)
V
OUT(*2)
HS mode
V
OUT(T)
±20mV
V
OUT(T
)
±20mV
V
OUT(T)
±1%
V
OUT(T)
±1%
PS mode
V
OUT(T)
+50mV,V
OUT(T)
-70mV
V
OUT(T
)
+2.5%,V
OUT(T)
-3.5%
V
OUT(T
)
+2.5%,V
OUT(T
)
-3.5%
V
OUT(T)
+1.5%,V
OUT(T
)
-2.5%
0.85V
½
1.55V
1.65V
½
1.95V
2.05V
½
2.55V
2.65V
½
3.95V
B
⑤⑥-⑦
Packages
(Order Unit)
GR
GR-G
MR
MR-G
NR
NR-G
7R-G
ex.) 2.05V High Accuracy
→ ②=2, ③=0, ④=B
USP-4D (XC6217 Series A/B type) (3,000pcs/Reel)
USP-4D (XC6217 Series A/B type)
(3,000pcs/Reel)
SOT-25 (XC6217 Series A/B type)
(3,000pcs/Reel)
SOT-25 (XC6217 Series A/B type)
(3,000pcs/Reel)
SSOT-24 (XC6217 Series C/D type) (3,000pcs/Reel)
SSOT-24 (XC6217 Series C/D type) (3,000pcs/Reel)
USPN-4 (XC6217 Series C/D type)
(*2)
(5,000pcs/Reel)
(*1)
(*2)
The “-G” suffix denotes Halogen and Antimony free as well as being fully EU RoHS compliant.
Output Range of USPN-4 1.6V≦V
OUT
≦4.00V
●Selection
Guide
Type
A
B
C
D
GO Pin
YES
YES
NO
NO
C
L
Discharge
NO
YES
NO
YES
3/34
XC6217
Series
■PIN
CONFIGURATION
V
OUT
5
GO
GO
V
OUT
V
OUT
2
1
5
V
SS
V
SS
3
4
GO
4
V
IN
4
V
OUT
3
V
SS
V
OUT
2
1
3
4
CE
CE
V
IN
V
IN
CE
V
IN
1
V
IN
USP-4D
(BOTTOM VIEW)
2
V
SS
3
CE
1
CE
2
V
SS
USPN-4
(BOTTOM VIEW)
SOT-25
(TOP VIEW)
SSOT-24
(TOP VIEW)
The USP-4D, USPN-4 heat dissipation pad is recommended to solder in use of the reference
mount pattern and metal mask pattern for the mounting strength and heat dissipation.
■PIN
ASSIGNMENT
PIN NUMBER
USP-4D
4
1
2
5
3
SOT-25
1
5
4
2
3
SSOT-24
4
3
-
2
1
USPN-4
4
1
-
2
3
PIN NAME
V
IN
V
OUT
GO
V
SS
CE
FUNCTION
Power Input
Output
Green Operation Mode Switch
Ground
ON/OFF Control
* XC6217 Series A/B type: USP-4D package
XC6217 Series A/B type: SOT-25 package
XC6217 Series C/D type: SSOT-24 package
XC6217 Series C/D type: USPN-4 package
■FUNCTION
CHART
PIN NAME
CE
LOGIC
L
H
OPEN
L
GO
(*1)
H
OPEN
(*1)
(*2)
IC CONDITION
OFF
ON
Undefined operation
GO Mode
(*2)
HS Mode
Undefined operation
Since there is no GO pin about SSOT-24 and USPN-4, they always operate by GO Mode.
GO mode = PS/HS auto switching
PowerSave(PS) mode：Low supply current
HighSpeed(HS) mode：High Speed
(*3)
CE pin and GO pin should not be left open. Each should have a certain voltage.
4/34
XC6217
Series
■ABSOLUTE
MAXIMUM RATINGS
Ta=25℃
PARAMETER
Input Voltage
Output Current
Output Voltage
CE/GO Input Voltage
USP-4D
SOT-25
Power Dissipation
SSOT-24
USPN-4
Operating Ambient Temperature
Storage Temperature
(*1)
:
(*2)
:
SYMBOL
V
IN
I
OUT
V
OUT
V
CE
/V
GO
RATINGS
V
SS
-0.3 ~ +6.5
400
(*1)
V
SS
– 0.3 ~ V
IN
+ 0.3
V
SS
– 0.3 ~ +6.5
120
650 (40mmx40mm Standard board)
(*2)
250
600 (40mmx40mm Standard board)
(*2)
150
500 (40mmx40mm Standard board)
(*2)
100
600 (40mmx40mm Standard board)
(*2)
- 40 ~ + 85
- 55 ~ +125
UNITS
V
mA
V
V
Pd
mW
Topr
Tstg
℃
℃
I
OUT
≦
Pd / (V
IN
-V
OUT
)
The power dissipation figure shown is PCB mounted and is for reference only.
Please see the power dissipation page for the mounting condition.
5/34
