PKFM10
20C-D
thru
PKFM
10
200C-D
SCHOTTKY BARRIER RECTIFIER
10 .0A Surface Mount Schottky Barrier Rectifiers - 20V-200V
DPAK
0.048(1.20)
0.031(0.80)
0.264(6.70)
0.248(6.30)
0.217(5.50)
0.201(5.10)
0.098(2.50)
0.083(2.10)
0.024(0.60)
0.016(0.40)
0.244(6.20)
0.228(5.80)
.
0.114(2.90)
0.098(2.50)
0.039(1.00)
0.031(0.80)
0.024(0.60)
0.016(0.40)
0.185(4.70)
0.169(4.30)
0.032(0.80)
0.016(0.40)
Dimensions in inches and (millimeters)
FEATURES
•
Batch process design, excellent power dissipation offers
•
•
•
•
•
•
•
•
•
better reverse leakage current and thermal resistance.
Low profile surface mounted application in order to
optimize board space.
Low power loss, high efficiency.
High current capability, low forward voltage drop.
High surge capability.
Guardring for overvoltage protection.
Ultra high-speed switching.
Silicon epitaxial planar chip, metal silicon junction.
Lead-free parts meet environmental standards of
MIL-STD-19500 /228
Suffix "-H" for Halogen-free part, ex
.
P
KFM1020C-D-H.
MECHANICAL DATA
•
Epoxy:UL94-V0 rated flame retardant
•
Case : Molded plastic, TO-252 / DPAK
•
Terminals : Solder plated, solderable per
MIL-STD-750, Method 2026
•
Mounting Position : Any
•
Weight : Approximated 0.34 gram
MAXIMUM RATIXGS AND ELECTRICAL CHARACTERISTICS
PARAMETER
Forward rectified current
Forward surge current
See Fig.1
8.3ms single half sine-wave superimposed on
rate load (JEDEC methode)
V
R
= V
RRM
T
J
= 25
O
C
V
R
= V
RRM
T
J
= 100
O
C
f=1MHz and applied 4V DC reverse voltage
CONDITIONS
AT T
A
=25
o
C unless otherwise noted)
MIN.
TYP.
MAX.
10.0
100
0.5
20
380
-65
+175
UNIT
A
A
Symbol
I
O
I
FSM
I
R
C
J
T
STG
Reverse current
Diode junction capacitance
Storage temperature
SYMBOLS
P
KFM1020C-D
P
KFM1030C-D
P
KFM1040C-D
P
KFM1045C-D
P
KFM1050C-D
P
KFM1060C-D
P
KFM1080C-D
P
KFM10100C-D
P
KFM10150C-D
P
KFM10200C-D
*1
V
RRM
(V)
20
30
40
45
50
60
80
100
150
200
V
RMS
*2
(V)
14
21
28
31.5
35
42
56
70
105
140
mA
pF
O
C
*3
V
R
(V)
20
30
40
45
50
60
80
100
150
200
*4
V
F
(V)
Operating
temperature
T
J
, (
O
C)
0.55
-55 to +125
*1 Repetitive peak reverse voltage
*2 RMS voltage
*3 Continuous reverse voltage
0.70
0.85
0.90
0.92
-55 to +150
*4 Maximum forward voltage@I
F
= 5.0A
www.paceleader.tw
1
PKFM10
20C-D
thru
PKFM
10
200C-D
SCHOTTKY BARRIER RECTIFIER
Rating and characteristic curves (PKFM1020C-D THRU PKFM10200C-D)
FIG.1-TYPICAL FORWARD CURRENT DERATING CURVE
AVERAGE FORWARD CURRENT,(A)
FIG.2-TYPICAL FORWARD
CHARACTERISTICS
12
10
PK
50
INSTANTANEOUS FORWARD CURRENT,(A)
PK
FM
10
20
PK
C-
D~
FM
PK
10
FM
50
PK
C-
10
D~
FM
45
C-
PK
10
D
FM
80
10
C-
PK
60
D~
FM
C-
PK
D
10
FM
15
10
0C
10
-D
0C
~P
-D
KF
M1
02
00
C-
D
FM
PK
105
8
6
4
2
0
0
20
40
60
102
FM
0C
-D~
PK
104
FM
5C
-D
-D~
0C
FM
PK
102
-D
00C
10
3.0
1.0
80
100
120
140
160
180
200
CASE TEMPERATURE,(°C)
T
J
=25 C
Pulse Width 300us
1% Duty Cycle
FIG.3-MAXIMUM NON-REPETITIVE FORWARD
SURGE CURRENT
120
0.1
PEAK FORWARD SURGE CURRENT,(A)
T
J
=25 C
8.3ms Single Half
Sine Wave
JEDEC method
100
.01
.1
.3
.5
.7
.9
1.1
1.3
1.5
80
FORWARD VOLTAGE,(V)
60
40
20
FIG.4 - TYPICAL REVERSE
CHARACTERISTICS
10
1
5
10
50
100
0
NUMBER OF CYCLES AT 60Hz
FIG.5-TYPICAL JUNCTION CAPACITANCE
REVERSE LEAKAGE CURRENT, (mA)
1400
1200
1000
800
600
400
200
0
1.0
T
J
=75 C
JUNCTION CAPACITANCE,(pF)
0.1
T
J
=25 C
.01
.01
.05
.1
.5
1
5
10
50
100
.001
0
20
40
60
80
100 120 140
REVERSE VOLTAGE,(V)
PERCENT OF RATED PEAK REVERSE VOLTAGE,(%)
www.paceleader.tw
2
