Continental Device India Limited
An ISO/TS 16949, ISO 9001 and ISO 14001 Certified Company
NPN POWER TRANSISTORS
BU208D
TO 3
Metal Can Package
HORIZONTAL DEFLECTION CIRCUITS IN COLOUR TV RECEIVER APPLICATIONS
ABSOLUTE MAXIMUM RATINGS (Ta=25ºC unless specified otherwise)
DESCRIPTION
Collector Emitter Voltage (V
BE
= 0)
Collector Emitter voltage (Open Base)
Emitter Base Voltage
Collector Current
Collector Current (Peak)
Base Current (Peak)
Total Power Dissipation upto Tc=25ºC
Derate Above 25ºC
Junction Temperature
Storage Temperature
THERMAL RESISTANCE
Junction to Case
SYMBOL
V
CES
V
CEO
V
EBO
I
C
I
CM
I
BM
P
tot
T
j
T
stg
R
th(j-c)
VALUE
<1500
<700
<5
<5
<7.5
<4
<60
<0.666
<200
-65 To +200
1.5
UNITS
V
V
V
A
A
A
W
W/ºC
ºC
ºC
ºC/W
ELECTRICAL CHARACTERISTICS (Ta=25ºC unless specified otherwise)
DESCRIPTION
Collector Cutoff Current
Emitter Cutoff Curren
Breakdown Voltages
V
CEO(sus)
*
V
CES
V
EBO
Saturation Voltages
V
CE(Sat)
*
V
BE(Sat)
*
DC Current Gain
Forward Voltage
h
FE
*
V
F
I
C
=4.5A,I
B
=2A
I
C
=4.5A,I
B
=2A
I
C
=4.5A,V
CE
=5V
I
F
=4A
<1
<1.5
>2.25
>2
V
V
I
C
=100mA,I
B
=0
I
C
=1mA,V
BE
=0
I
E
=10mA, I
C
=0
>700
>1500
>5
V
V
V
SYMBOL
I
CES
I
EBO
TEST CONDITION
V
BE
=0, V
CE
=1500V
I
C
=0 , V
EB
=5V
VALUE
<1.0
300
UNITS
mA
mA
V
Continental Device India Limited
Data Sheet
Page 1 of 4
Notes
BU208D
TO 3
Metal Can Package
Disclaimer
The product information and the selection guides facilitate selection of the CDIL's Discrete Semiconductor Device(s) best suited
for application in your product(s) as per your requirement. It is recommended that you completely review our Data Sheet(s) so as
to confirm that the Device(s) meet functionality parameters for your application. The information furnished in the Data Sheet and
on the CDIL Web Site/CD are believed to be accurate and reliable. CDIL however, does not assume responsibility for
inaccuracies or incomplete information. Furthermore, CDIL does not assume liability whatsoever, arising out of the application or
use of any CDIL product; neither does it convey any license under its patent rights nor rights of others. These products are not
designed for use in life saving/support appliances or systems. CDIL customers selling these products (either as individual
Discrete Semiconductor Devices or incorporated in their end products), in any life saving/support appliances or systems or
applications do so at their own risk and CDIL will not be responsible for any damages resulting from such sale(s).
CDIL strives for continuous improvement and reserves the right to change the specifications of its products without prior notice.
CDIL is a registered Trademark of
Continental Device India Limited
C-120 Naraina Industrial Area, New Delhi 110 028, India.
Telephone + 91-11-579 6150 Fax + 91-11-579 9569, 579 5290
e-mail sales@cdil.com
www.cdil.com
BU208D Rev180302D
