ICM-0805
www.vishay.com
Vishay Dale
Surface Mount Common Mode Choke
FEATURES
• Operating temperature -40 °C to +85 °C
• Excellent solderability and resistance to
soldering heat
• Suitable for flow and reflow soldering
• High reliability and easy surface mount assembly
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
APPLICATIONS
•
•
•
•
USB 2.0 and IEEE1394
Notebook and personal computer
Digital camera
Scanner
STANDARD ELECTRICAL SPECIFICATIONS
COMMON MODE IMPEDANCE
AT 100 MHz, ± 20 %
()
(1)
30
67
90
120
160
180
260
370
RATED
VOLTAGE
(V
DC
)
50
50
50
50
50
50
50
50
WITHSTANDING
VOLTAGE
(V
DC
)
125
125
125
125
125
125
125
125
RATED CURRENT
MAX.
(mA)
(2)
450
400
330
370
350
330
300
280
DC RESISTANCE
MAX.
()
0.20
0.25
0.35
0.30
0.35
0.35
0.40
0.45
INSULATION
RESISTANCE MIN.
(M)
10
10
10
10
10
10
10
10
Notes
(1)
Impedance is measured in HP4287A at a frequency of 100 MHz.
(2)
For a 15 °C rise.
DIMENSIONS
in inches [millimeters]
0.047 ± 0.010
[1.2 ± 0.25]
0.079 ± 0.010
[2.0 ± 0.25]
0.047 ± 0.010
[1.2 ± 0.25]
(1)
(2)
(1)
(2)
0.016 [0.4]
0.016 [0.4]
0.016 [0.4]
0.102
[2.60]
0.046 [1.20]
(4)
(3)
(4)
0.018 [0.45]
(3)
0.018 [0.45]
0.035
[0.90]
0.031
[0.80]
0.035
[0.90]
TYPICAL PAD LAYOUT
DESCRIPTION
ICM-0805
MODEL
120
IMPEDANCE VALUE
± 20 %
INDUCTANCE TOLERANCE
ER
PACKAGE CODE
e3
JEDEC
®
LEAD (Pb)-FREE STANDARD
GLOBAL PART NUMBER
I
C
PRODUCT
FAMILY
Revision: 06-Nov-15
M
0
8
SIZE
0
5
E
R
1
2
IMPEDANCE
1
M
TOL.
PACKAGE
CODE
Document Number: 34159
1
For technical questions, contact:
magnetics@vishay.com
