EX
Series
Miniature
Long Life
Low Impedance
Solvent Proof
105 C or 125 C
Maximum
Temperature
Actual
Size
MINIATURE -105 C
EX
The EX series capacitors have a low impedance and are designed for use over two temperature
ranges, 55 C to 105 C and 55 C to 125 C. This series is available with two types of sleeving,
PVC for use up to 105 C and PET (polyester) for use up to 125 C. Please note that the life of the
capacitor will be reduced if used at the higher temperature of 125 C.
The EX series capacitors were developed to withstand HCFC cleaning agents for five minutes
by ultrasonic, vapor or immersion. This solvent proof design allows all circuit board components
to be cleaned together, at the same time, without resorting to more expensive epoxy end-sealed
capacitors. Refer to the Mini-Glossary for recommended cleaning conditions.
Summary of Specifications
Radial lead terminals.
Capacitance range: 0.1 to 10,000µF.
Voltage range: 10 to 63VDC.
Operating temperature range: 55 C to 105 C for PVC sleeve; 55 C to 125 C
for PET sleeve.
Leakage current: 0.01CV or 3µA, whichever is greater, after 2 minutes at 20 C.
Standard capacitance tolerance: 20%
Nominal case size (D L): 5 11mm to 18 40mm.
Rated lifetime: 2,000 to 5,000 hours at 105 C or 500 to 1,250 hours at 125 C with
the rated ripple current applied, depending on case size.
238
United Chemi-Con, Inc. 9801 W. Higgins Road, Rosemont, IL 60018 Tel 847-696-2000 Fax 847-696-9278 www.chemi-con.com
EX Series
EX Specifications
Item
Operating Temperature Range
Rated Voltage Range
Capacitance Range
Capacitance Tolerance
Leakage Current
I
55 to 105 C for PVC sleeve;
10 to 63VDC
0.1 to 10,000 F
20% ( M ) at
20 C, 120Hz
20 C.
Characteristics
55 to 125 C for PET sleeve
0.01CV or 3 A, whichever is greater, after 2 minutes at
Where I = Leakage current ( A ), C = Nominal capacitance ( F ) and V = Rated voltage ( V )
Dissipation Factor ( Tan )
At
20 C, 120Hz
MINIATURE -105 C
Rated Voltage ( V )
Tan
( DF )
10
0.38
16
0.32
25
0.28
35
0.24
50
0.20
63
0.16
When nominal capacitance exceeds 1,000 F, add 0.02 to the values above for each 1,000 F increase.
EX
Equivalent Series Resistance
(ESR )
Low Temperature
Characteristics
Ripple Current Multipliers
Refer to Section 4 of the
Mini-Glossary for explanation
of Ripple Current Multipliers.
At 100kHz,
40 C,
20 C, refer to the Ratings Tables.
40 C value and
20 C value shall not be less than
At 120Hz, capacitance ratio between the
70% of the specified value at 20 C.
Frequency (Hz )
Rated Voltage ( V )
10V
Case Diameter (Capacitance Range)
Ø
5,
Ø
6.3,
Ø
8
Ø
10,
Ø
12.5,
Ø
16,
Ø
18
Ø
5,
Ø
6.3,
Ø
8
Ø
10,
Ø
12.5,
Ø
16,
Ø
18
Ø
5 (
≤
1.0 F )
120Hz
0.70
0.85
0.50
0.70
0.20
0.40
0.60
1kHz
0.86
0.95
0.80
0.88
0.66
0.76
0.84
10kHz
0.96
0.98
0.94
0.97
0.90
0.93
0.96
100kHz
1.00
1.00
1.00
1.00
1.00
1.00
1.00
16- 35V
50V, 63V
Ø
5 ( 2.2 F ),
Ø
6.3,
Ø
8
Ø
10,
Ø
12.5,
Ø
16,
Ø
18
Load Life
The following specifications shall be satisfied when the capacitors are restored to 20 C
after subjecting them to the DC rated voltage for the specified test time at 105 C or 125 C
with the rated ripple current applied. The sum of DC voltage and peak AC voltage must not
exceed the full rated voltage of the capacitors.
Case Diameter
Ø
5 &
Ø
6.3mm
Ø
8 &
Ø
10mm
Ø
12.5mm & above
Test Time at 105 C
2,000 hours
3,000 hours
5,000 hours
Test Time at 125 C
500 hours
750 hours
1,250 hours
Capacitance change:
≤
20% of initial measured value
Tan ( DF )
:
≤
200% of initial specified value
Leakage current
:
≤
initial specified value
ESR
: Refer to Ratings Tables. ESR test results apply to case diameters
≥12.5.
Shelf Life
The following specifications shall be satisfied when the capacitors are restored to 20 C after
exposing them for 1,000 hours at 105 C without voltage applied. The rated voltage shall be
applied to the capacitors for a minimum of 30 minutes, at least 24 hours and not more than
48 hours before the measurements.
Capacitance change:
≤
20% of initial measured value
Tan ( DF )
:
≤
200% of initial specified value
Leakage current
:
≤
initial specified value
ESR
: Refer to Ratings Tables. ESR test results apply to case diameters
≥12.5.
Others
Satisfies characteristic W of JIS C5141
United Chemi-Con, Inc. 9801 W. Higgins Road, Rosemont, IL 60018 Tel 847-696-2000 Fax 847-696-9278 www.chemi-con.com
239
EX Series
Diagram of Dimensions
VB/Radial Lead
*
Sleeve
d
D
'
D
F
F
F
F
Unit: mm
L
Vent
(Except 5)
L
'
15
MIN.
4
MIN.
5~ 8
10
12.5 ~ 18
MINIATURE -105 C
*
PET sleeve for 125 C applications.
Gas escape end seal for all case diameters.
Ø
D
Ø
D
'
max.
For optional lead configurations and tape and ammo
packaging, refer to the beginning of the Miniature section.
5
6.3
8
10, 12.5
16, 18
0.5
0.5
Ø
D 0.5
Ø
D 0.5
Ø
D 0.5
Ø
D
Ø
D
L
'
max.
L 2.0
L 2.0
L 2.0
L 2.0
L 2.0
Ø
d
0.5
0.5
0.6
0.6
0.8
F 0.5
2.0
2.5
3.5
5.0
7.5
EX
Part Numbering System for EX Series
EX
10
VB
331
M
8X11
LL
When ordering, always specify complete catalog number for EX Series.
P
Optional Sleeve Type: P = PET Sleeve. Specify if required.
Lead Length: LL is Standard.
Case Code: See Case Sizes in Tables.
Capacitance Tolerance: M = 20%
Capacitance Value: Expressed in Microfarads. The first two digits are
significant figures, and the third digit indicates the number of zeros
for capacitance of 100 F or more. R indicates the decimal point for
capacitance less than 100 F (e.g. R33 = .33 F; 3R3 = 3.3 F;
33R = 33 F; 331 = 330 F; 332 = 3,300 F; 333 = 33,000 F ).
Lead Configuration: VB = Radial Lead Terminals.
DC Rated Voltage: Expressed in Volts (e.g. 10 = 10WVDC).
Series Name: Indicates Basic Capacitor Design.
Standard Voltage Ratings - VB/Radial Lead
Rated
Voltage
(WVDC)
Capacitance
(µF )
Catalog
Part Number
Nominal
Case Size*
D L ( mm )
Maximum ESR (
Ω
) at 100kHz
Initial Value
End of Life
20 C
2.7
1.2
0.58
0.58
0.28
0.12
0.089
0.065
0.05
0.04
2.7
1.2
0.58
0.58
40 C
41
18
8.7
8.7
4.2
1.8
1.4
0.98
0.75
0.6
41
18
8.7
8.7
20 C
–
–
–
–
–
0.24
0.18
0.13
0.10
0.08
–
–
–
–
40 C
–
–
–
–
–
3.6
2.8
2.0
1.5
1.2
–
–
–
–
Maximum Ripple
Current ( mA rms)
at 105 C
120Hz
100kHz
60
102
169
169
385
706
892
1,160
1,420
1,690
43
74
121
121
86
147
242
242
453
832
1,050
1,360
1,670
1,990
86
147
242
242
10 Volts
13 Volts Surge
100
220
330
470
1,000
2,200
3,300
4,700
6,800
10,000
47
100
220
330
EX10VB101M5X11LL
EX10VB221M6X11LL
EX10VB331M8X11LL
EX10VB471M8X11LL
EX10VB102M10X16LL
EX10VB222M12X20LL
EX10VB332M12X25LL
EX10VB472M16X25LL
EX10VB682M16X31LL
EX10VB103M18X35LL
EX16VB47RM5X11LL
EX16VB101M6X11LL
EX16VB221M8X11LL
EX16VB331M8X11LL
5
6.3
8
8
10
12.5
12.5
16
16
18
5
6.3
8
8
11
11
11.5
11.5
16
20
25
25
31.5
35.5
11
11
11.5
11.5
16 Volts
20 Volts Surge
*
The case sizes in table are with no sleeve, refer to diagram for case sizes with sleeve.
