LARGE CAPACITANCE ALUMINUM ELECTROLYTIC CAPACITORS
Inverter-use screw terminal, 85C
RWF
@Rated
voltage range : 350 to 550V
dc
@Endurance
with ripple current : 85C 2000 hours
longer life
RWE
?SPECIFICATIONS
Items
Category
Temperature Range
Rated Voltage Range
Capacitance Tolerance
Leakage Current
Dissipation Factor
(tane)
Low Temperature
Characteristics
Insulation Resistance
Insulation
Withstanding Voltage
Endurance
-25 to +85C
350 to 550V
dc
P20%
(M)
I=0.02CV or 5mA, whichever is smaller.
Where, I : Max. leakage current (MA), C : Nominal capacitance (MF), V : Rated voltage (V)
0.25 max.
Capacitance change
Characteristics
(at 20C, 120Hz)
(at 20C after 5 minutes)
(at 20C, 120Hz)
Shelf Life
Rated Voltage (V
dc
)
350 to 450V 500 & 550V
C(-25C)/C(+20C)
]0.7
]0.6
(at 120Hz)
When measured between the terminals shorted each other and the mounting clamp on the insulating sleeve covering the case by using
an insulation resistance meter of 500Vdc, the insulation resistance shall not be less than 100MO.
When a voltage of 2000Vac is applied for 1 minute between the terminals shorted each other and the mounting clamp on the insulating
sleeve covering the case, there shall not be electrical damage.
The following specifications shall be satisfied when the capacitors are restored to 20C after subjected to DC voltage with the rated
ripple current is applied for 2000 hours at 85C.
Capacitance change
[P20%
of the initial value
D.F. (tanE)
[300%
of the initial specified value
Leakage current
[The
initial specified value
The following specifications shall be satisfied when the capacitors are restored to 20C after exposing them for 500 hours at 85C
without voltage applied.
Capacitance change
[P20%
of the initial value
D.F. (tanE)
[300%
of the initial specified value
Leakage current
[The
initial specified value
?DIMENSIONS
(Terminal Type=LGSN) [mm]
@B
Type of Mounting Clamp
Sleeve
AP1
WP1
@C
Type of Mounting Clamp
360°
3
FD+1.8max.
FP1
H
BP1
45°P5°
KP1
EP1
30°P5°
6
L+4max.
GP1
fD
35
50
63.5
76
A
58
78
90
104.5
B
44
64
76
90
W
48
68
80
93.5
H
3.5
4.5
4.5
4.5
F
12.7
22.4
28.0
31.5
fD
50
63.5
76
89
8
J
4.5
F35
to
F63.5
: G=6
F76
&
F89
: G=5
E
32.5
38.1
44.5
50.8
K
37.0
43.5
50.0
56.5
F
22.4
28.0
31.5
31.5
J
14.0
14.0
14.0
16.0
<Screw specifications>
Plus hexagon-headed screw:
M5B0.8B10
Maximum screw tightening torque:
3.23Nm
* The screw and the mounting clamp are separately supplied and not attached to the product.
?PART
NUMBERING SYSTEM
RWE 550 LGSN 820
M
C
C13
Case code
Type of mounting clamp, if required
Capacitance tolerance (P20%)
Nominal capacitance in
MF
Screw terminal type
Rated voltage in volts
Series name
(1/2)
CAT. No. E1001D
LARGE CAPACITANCE ALUMINUM ELECTROLYTIC CAPACITORS
Inverter-use screw terminal, 85C
?STANDARD
RATINGS
mF
V
dc
100
120
180
270
330
390
470
560
680
820
1,000
1,200
1,500
1,800
2,200
2,700
3,300
3,900
4,700
5,600
6,800
8,200
10,000
12,000
F15
22.5
C13
D11
D13
E11
E13
E15
E9
D9
8.8
8.8
C9
6.3
A10
A12
C7
3.8
4.2
4.7
C9
C13
D9
D11
D13
E11
E13
E15
E9
5.7
7.2
7.9
9.5
10.9
10.6
A8
2.9
A10
A12
C7
3.4
3.9
4.2
A8
2.7
A10
A12
C7
C9
C11
C13
D9
D11
D13
E11
E13
E15
E9
3.1
3.5
3.9
4.7
5.6
6.5
7.2
8.6
10.0
11.5
13.3
15.7
9.8
F15
10.1
D11
D13
E11
E15
E9
4.5
5.2
6.1
7.7
F15
9.3
4.6
C9
C11
C13
D9
3.4
2.5
2.9
3.4
E9
E11
E13
E15
4.2
5.0
5.8
7.0
A5
1.9
A8
2.4
A5
1.7
Case code
Rated ripple current (Arms) at 85C, 120Hz
A5
1.6
A8
A10
A12
C7
1.2
1.4
1.7
1.8
C9
C11
C13
D9
D11
D13
2.1
2.7
3.1
2.5
3.0
3.5
A5
0.7
A8
A10
A12
C7
1.0
1.3
1.6
1.7
350
400
450
500
A5
550
0.6
10.3
12.0
11.7
12.6
14.5
17.3
12.6
15.9
19.0
F15
F15
20.5
18.6
?CASE
CODE
fD
(mm)
L (mm)
35
50
63.5
76
89
50
A5
-
-
-
-
75
-
C7
-
-
-
80
A8
-
-
-
-
96
-
C9
D9
E9
-
100
A10
-
-
-
-
115
-
C11
D11
E11
-
120
A12
-
-
-
-
130
-
C13
D13
E13
-
155
-
-
-
E15
F15
?RATED
RIPPLE CURRENT MULTIPLIERS
@Frequency
Multipliers
50
0.8
120
1.0
Frequency (Hz)
Coefficient
300
1.1
1k
1.3
3k
1.4
Note : The endurance of capacitors is shorted with internal heating produced by ripple current at the rate of halving the lifetime with every 5 to
10C rise. When long life performance is required in actual use, the rms ripple current has to be reduced. Also, for the RWE series
capacitors, using them at operating voltage less than their rated voltage can extend their lifetime. For the details, please contact a
representative of Nippon Chemi-Con.
(2/2)
CAT. No. E1001D
