SMS1546-001: DescriptionSILICON, LOW BARRIER SCHOTTKY, X BAND, MIXER DIODE; Categorysemiconductor Discrete semiconductor; File Size165KB，3 Pages; ManufacturerAlpha Industries; Websitehttp://www.alphaind.com

Download Datasheet Compare View All

SMS1546-001 Overview

SILICON, LOW BARRIER SCHOTTKY, X BAND, MIXER DIODE

Preview

Download Datasheet

View All

Surface Mount Mixer and

Detector Schottky Diodes

Features

s

Tight Parameter Distribution

s

Available as Singles and Pairs

s

100% DC Tested

s

Designed for High Volume Commercial

Applications

s

Available in Tape and Reel Packaging

Description

These low cost, surface mountable plastic packaged silicon

mixer Schottky diodes are designed for RF and microwave

mixers and detectors.They include low barrier diodes and zero

bias detectors, combining Alpha’s advanced semiconductor

technology with low cost packaging techniques. All diodes are

100% DC tested and deliver tight parameter distribution,

minimizing performance variability.They are available in SC-

70, SC-79, SOD-323, SOT-23 and SOT-143 packages.Wiring

configurations include singles, common cathode, series pairs

and unconnected pairs. Applications include low noise

receivers used in high sensitivity ID tags, wireless systems,

radio designs and may be used at frequencies to 10 GHz.

SPICE model parameters are included as a design tool.

Absolute Maximum Ratings

Characteristic

Reverse Voltage (V

R

)

Forward Current - Steady State (I

F

)

Power Dissipation (P

D

)

Storage Temperature (T

ST

)

Operating Temperature (T

OP

)

Junction Temperature (T

J

)

Soldering Temperature

Value

Rated V

B

50 mA

75 mW

-65°C to +150°C

150°C

260°C for 5 Seconds

Single

Common

Cathode

Series Pair

Reverse

Series Pair

SOT-23

Unconnected

Pair

SOT-143

o

SMS1546-015

Marking: SG7

Reverse

Unconnected

Pair

SOT-143

SC-79

SOD-323

o

SMS1546-011

Cathode Mark

SOT-23

o

SMS1546-001

Marking: SG1

o

SMS7621-001

Marking: SH1

o

SMS7630-001

Marking: SD1

L

S

= 1.5 nH

SC-70

Marking: SH3

SOT-23

o

SMS1546-005

Marking: SG2

Marking: SH2

Marking: SD2

L

S

= 1.5 nH

SC-70

Marking: SH2

Marking: SD2

L

S

= 1.4 nH

L

S

= 1.4 nH

o

SMS7621-079

Cathode Mark

o

SMS7630-079

o

SMS7621-011

Cathode Mark

o

SMS7630-011

Cathode Mark

L

S

= 1.5 nH

o

SMS7621-005

o

SMS7621-006

o

SMS7621-015

Marking: SH8

Marking: SD8

L

S

= 1.5 nH

SC-70

Marking: SH8

Marking: SD8

L

S

= 1.4 nH

Marking: SH7

L

S

= 1.5 nH

o

SMS7630-020

Marking: SD0

L

S

= 1.5 nH

o

SMS7630-005

o

SMS7630-006

Anode Mark

L

S

= 0.7 nH

o

SMS7621-074

o

SMS7621-075

o

SMS7621-076

o

SMS7630-075

o

SMS7630-076

o

Available through distribution.

Alpha Industries, Inc.

[781] 935-5150

•

Fax

[617] 824-4579

•

Email

sales@alphaind.com

•

www.alphaind.com

Specifications subject to change without notice. 1/01A

1
