10/100 BASE –T MAGNETICS MODULES
Page : 1/1
P/N:TN0023 DATA SHEET
Feature
single port designs for maximum layout flexibility.
Compatible with Intel, TDK, QSI, and ICS.
24-PIN SMD package, pick and place compatible.
Operating Temperature range: 0°C to +70°C.
Storage temperature range: -25°C to +125°C.
Electrical Specifications @ 25°C
Part
Number
TN0023
TX
1CT:1CT
Turns Ratio
(±5%)
RX
1CT:1CT
Voltage Isolation
(Vrms)
1500
Continue
Insertion
Part
Number
Loss
(dB Max)
Return Loss
(dB Min @ 100
Ω)
Cross talk Attenuation
(dB Min)
DCMR
(dB Min)
1–100MHz 1-30MHz 40MHz 50MHz 60-80MHz 100MHz 30MHz 60MHz
100MHz
30MHz 60MHz 100MHz
TN0023
-1.0
-18
-14.4
-13.1
-12
-10
-45
-40
-35
-43
-37
-33
Schematic
Mechanical
