Switch and Attenuator
Plastic Packaged PIN Diodes
SMP1302 Series
Features
s
Low Distortion Design
s
Frequency Range from HF to > 2 GHz
s
Designed for Base Station and Handset
Applications
Description
The SMP1302 series of plastic packaged, surface
mountable, low capacitance (0.3 pF) silicon PIN diodes
are designed for high volume switch and attenuator
applications from 10 MHz to beyond 2 GHz. These diodes
are designed for use in low distortion PI and TEE
attenuators with low drive current (maximum resistance
at 1 mA is 10
Ω)
commonly used in TV distribution and
cellular base station applications. The nominal 50
µm
I region width combined with a maximum resistance of
3
Ω
at 10 mA, make these diodes useful in large signal
switch applications. Available as single and dual diodes
in a selection of plastic packages including SOT-23,
SOD-323, small footprint SC-79 and miniature
SC-70. Available in a SOT-5 (SMP1302-027) package as
a four diode array designed for insertion in the commonly
used 4 diode PI attenuator circuit.
Absolute Maximum Ratings
Characteristic
Reverse Voltage (V
R
)
Power Dissipation @ 25°C Lead
Temperature (P
D
)
Storage Temperature (T
ST
)
Operating Temperature (T
OP
)
ESD Human Body Model
Value
200 V
250 mW
-65°C to +150°C
-65°C to +150°C
Class 1C
Single
Marking: PF1
SOT-23
o
SMP1302-001
L
S
= 1.5 nH
Common
Anode
Marking: PF9
SOT-23
o
SMP1302-003
L
S
= 1.5 nH
SC-70
o
SMP1302-073
L
S
= 1.4 nH
Common
Cathode
Marking: PF3
SOT-23
o
SMP1302-004
L
S
= 1.5 nH
SC-70
o
SMP1302-074
L
S
= 1.4 nH
Series
Pair
Marking: PF2
SOT-23
o
SMP1302-005
L
S
= 1.5 nH
SC-70
o
SMP1302-075
L
S
= 1.4 nH
Single
PI
Marking: PFM
Single
SOD-323
o
SMP1302-011
L
S
= 1.5 nH
SOT-5
o
SMP1302-027
SC-79
o
SMP1302-079
L
S
= 0.7 nH
o
Available through distribution.
Alpha Industries, Inc.
[781] 935-5150
•
Fax
[617] 824-4579
•
Email
sales@alphaind.com
•
www.alphaind.com
Specifications subject to change without notice. 1/01A
1
Switch and Attenuator Plastic Packaged PIN Diodes
SMP1302 Series
Electrical Specifications at 25°C
Parameter
Reverse Current (I
R
)
Capacitance (C
T
)
Resistance (R
S
)
Resistance (R
S
)
Resistance (R
S
)
Forward Voltage (V
F
)
Carrier Lifetime (TI )
I Region Width
Condition
V
R
= 200 V
F = 1 MHz, V = 30 V
F = 100 MHz, I = 1 mA
F = 100 MHz, I = 10 mA
F = 100 MHz, I = 100 mA
IF = 10 mA
IF = 10 mA
0.8
0.7
50
15
Typ.
Max.
10
0.30
20
3.0
1.5
Unit
µA
pF
Ω
Ω
Ω
V
µS
µm
Typical Performance Data
1000
100
Series Resistance (Ω)
Forward Current (mA)
0.1
1
10
100
100
10
10
1
1
0.1
0.1
0.01
0.01
400
500
600
700
800
900
1000
Forward Current (mA)
Forward Voltage (mV)
Series Resistance vs. Current @ 100 MHz
0.8
0.7
300
250
DC Characteristic
Capacitance (pF)
Conductance (µS)
0.6
0.5
0.4
0.3
0.2
0.1
0
0
1 MHz
200
150
100
50
0V
10 V
100 MHz
1 GHz
40 V
0
1
2
5
10
20
50
100
0
500
1000
1500
2000
Reverse Voltage (V)
Frequency (MHz)
Capacitance vs. Reverse Voltage
Conductance vs. Frequency
and Reverse Voltage
2
Alpha Industries, Inc.
[781] 935-5150
•
Fax
[617] 824-4579
•
Email
sales@alphaind.com
•
www.alphaind.com
Specifications subject to change without notice. 1/01A
Switch and Attenuator Plastic Packaged PIN Diodes
SMP1302 Series
Resistance vs. Temperature @ 100 MHz
I
F
(mA)
0.02
0.10
0.30
1.00
10.00
20.00
100.00
R
-55°C
Ω
(Ω)
-55.00
599.00
123.00
42.20
13.50
2.00
1.34
0.60
R
-15°C
Ω
(Ω)
-15.00
653.00
135.00
46.60
15.00
2.30
1.50
0.74
R
+25°C
Ω
(Ω)
25.0
692.0
143.0
49.7
16.2
2.6
1.7
1.0
R
+65°C
Ω
(Ω)
65.0
715.0
154.0
54.3
17.9
2.9.0
2.0
1.1
R
+100°C
Ω
(Ω)
100.00
722.00
161.00
56.80
18.80
3.00
2.00
1.10
SOT-23
0.110 (2.80 mm) MIN.
0.120 (3.04 mm) MAX.
3
0.012 (0.30 mm) MIN.
0.020 (0.50 mm) MAX.
0.047 (1.20 mm) MIN.
0.055 (1.40 mm) MAX.
1
2
0.083 (2.10 mm) MIN.
0.104 (2.64 mm) MAX.
0.037 (0.95 mm) REF.
0.020 (0.51 mm) REF.
0.076 (1.92 mm) REF.
0.003 (0.080 mm) MIN.
0.008 (0.20 mm) MAX.
8˚ MAX.
0.035 (0.89 mm) MIN.
0.044 (1.12 mm) MAX.
SC-70
0.022 (0.55 mm) REF.
0.071 (1.80 mm) MIN.
0.087 (2.20 mm) MAX.
0.010 (0.25 mm) MIN.
0.016 (0.40 mm) MAX.
0.071 (1.80 mm) MIN.
0.094 (2.40 mm) MAX.
0.0005 (0.01 mm) MIN.
0.004 (0.10 mm) MAX.
3
0.045 (1.15 mm) MIN.
0.053 (1.35 mm) MAX.
SOD-323
0.090 (2.30 mm) MIN.
0.108 (2.74 mm) MAX.
0.010
(0.25 mm) MIN.
0.016
(0.40 mm) MAX.
0.063 (1.60 mm) MIN.
0.071 (1.80 mm) MAX.
1
0.014 (0.35 mm) REF.
2
0.026 (0.65 mm) REF.
0.045 (1.15 mm) MIN.
0.053 (1.35 mm) MAX.
1
0.051 (1.30 mm) REF.
0.004 (0.10 mm) MIN.
0.007 (0.18 mm) MAX.
0.031 (0.80 mm) MIN.
0.039 (1.00 mm) MAX.
2
CATHODE
INDICATOR
0.008 (0.20 mm) NOM.
0.004 (0.10 mm) MIN.
0.012 (0.30 mm) MAX.
0.000 (0.00 mm) MIN.
0.004 (0.10 mm) MAX.
0.006
(0.15 mm) TYP.
0.050
(1.25 mm) MAX.
0.004 (0.10 mm) MAX.
SC-79
CATHODE 0.006 (0.15 mm) MIN.
INDICATOR
0.010
(0.25 mm) MIN.
0.014
(0.35 mm) MAX.
1
2
0.010 (0.25 mm) MIN.
0.028
(0.70 mm) MIN.
0.035
(0.90 mm) MAX.
SOT-5
0.074
(1.90 mm)
REF.
5
4
0.069
(1.75 mm)
0.052
(1.30 mm)
3
0.037 (0.95 mm) REF.
0.012 (0.30 mm) TYP.
0.024
(0.61 mm)
0.004
(0.10 mm)
0.060 (1.50 mm) MIN.
0.067 (1.70 mm) MAX.
0.043 (1.10 mm) MIN.
0.051 (1.30 mm) MAX.
0.020
(0.50 mm) MIN.
0.028
(0.70 mm) MAX.
10˚ MAX.
0.020 (0.51 mm)
0.014 (0.35 mm)
0.012
(0.30 mm)
0.000
(0.00 mm)
MIN.
0.064 (1.63 mm)
0.035 (0.90 mm)
1
2
0.118
(3.00 mm)
0.087
(2.20 mm)
10˚ MAX.
0.003
(0.07 mm) MIN.
0.008
(0.20 mm) MAX.
0.122 (3.10 mm)
0.106 (2.70 mm)
0.0104 (0.26 mm)
0.0035 (0.09 mm) MIN.
Alpha Industries, Inc.
[781] 935-5150
•
Fax
[617] 824-4579
•
Email
sales@alphaind.com
•
www.alphaind.com
Specifications subject to change without notice. 1/01A
3
