85/86 – 5/8 ˝ Square Single-Turn Panel Control with Rotary Switch
Potentiometer Specifications
Standard Resistance Range
Linear Tapers (A, B, E, & H)......................................................................... (B & E) 1 K ohms to 1 megohm ................. (A & H) 100 ohms to 1 megohm
Audio Tapers (C, D, F, G, S, & T) ................................................................ (D, G, S, & T) 1 K ohms to 1 megohm ....... (C & F) 1 K ohms to 1 megohm
Total Resistance Tolerance................................................................................. ±20 % or 10 %............................................ ±10 % or 5 %
Operating Temperature Range ........................................................................... -40 °C to +125 °C ....................................... -40 °C to +125 °C
Storage Temperature Range .............................................................................. -55 °C to +125 °C ....................................... -55 °C to +125 °C
Temperature Coefficient Over Storage Temperature Range .............................. ±1,000 ppm/°C ........................................... ±150 ppm/°C
Vibration (Single Section) ................................................................................... 15 G ........................................................... 15 G
Total Resistance Shift .................................................................................. ±2 % maximum .......................................... ±2 % maximum
Voltage Ratio Shift ....................................................................................... ±5 % maximum .......................................... ±5 % maximum
Shock (Single Section) ....................................................................................... 30 G ........................................................... 30 G
Total Resistance Shift .................................................................................. ±2 % maximum .......................................... ±2 % maximum
Voltage Ratio Shift ....................................................................................... ±5 % maximum .......................................... ±5 % maximum
Load Life ............................................................................................................. 1,000 hours ................................................ 1,000 hours
Total Resistance Shift .................................................................................. ±10 % maximum ........................................ ±5 % maximum
Rotational Life (No Load).................................................................................... 100,000 cycles ........................................... 100,000 cycles
Total Resistance Shift .................................................................................. (Linear taper) 10 ohms or .......................... (All tapers) ±5 % TRS maximum
Moisture Resistance (MIL-STD-202, Method 103, Condition B)
Total Resistance Shift .................................................................................. (B & E tapers) ±10 % maximum ................ ±5 % maximum (all tapers)
Starting and Running Torque (Non-Locking Bushings)
Single Section..................................................................................................................................................................................0.14 to 1.06 N-cm (0.2 to 1.5 oz.-in.)
Dual Section ....................................................................................................................................................................................0.14 to 1.06 N-cm (0.2 to 1.5 oz.-in.)
Triple Section ...................................................................................................................................................................................0.35 to 1.41 N-cm (0.5 to 2.0 oz.-in.)
Quadruple Section ...........................................................................................................................................................................0.35 to 1.41 N-cm (0.5 to 2.0 oz.-in.)
Starting and Running Torque (Locking Bushings) ....................................................................................................................0.14 to 2.82 N-cm (0.2 to 4.0 oz.-in.)
Shaft Locking Torque with Locknut @ 10 in-lb. (B & E Bushings) .......................................................................................................................14 N-cm (20 oz-in.)
Mounting ...................................................................................................................................................................................1.7-2.0 N-m (15-18 lb.-in.) maximum
Weight (Single Section) ............................................................................................................................................................................................. 21 grams maximum
(Each Additional Section)...................................................................................................................................................................................... 6 grams maximum
Terminals ...........................................................................................................................................................................................Printed circuit terminals or J-Hooks
Soldering Condition .................................................................................. Recommended hand soldering using Sn95/Ag5 no clean solder, 0.025 ˝ wire diameter.
Maximum temperature 399 °C (750 °F) for 3 seconds. No wash process to be used with no clean flux.
Marking ...........................................................................................Manufacturer’s trademark, wiring diagram, date code and resistance, manufacturer’s part number
Ganging (multiple section potentiometers) ...................................................................................................................................................................... 4 cup maximum
Hardware ...............One lockwasher and one mounting nut is shipped with each potentiometer; locking bushing versions are shipped with one additional locking nut
For dimensional drawings see pages 3 & 4. For ordering information see page 5.
NOTE: Model 81/82 performance specifications do not apply to units subjected to printed circuit board cleaning procedures.
1
Electrical specifications tested at 250 RPM, at room ambient: +25 °C nominal.
Initial Electrical Characteristics
1
Conductive Plastic Element
Cermet Element
Environmental Characteristics
1
Mechanical Characteristics
WARNING
Cancer and Reproductive Harm
www.P65Warnings.ca.gov
*RoHS Directive 2015/863, Mar 31, 2015 and Annex.
Specifications are subject to change without notice. Users should verify actual device performance in their specific
applications. The products described herein and this document are subject to specific legal disclaimers as set forth on the
last page of this document, and at www.bourns.com/docs/legal/disclaimer.pdf.
81/82 – 5/8 ˝ Square Single-Turn Panel Control
85/86 – 5/8 ˝ Square Single-Turn Panel Control with Rotary Switch
Rotary Switch Specifications
Initial Electrical Characteristics
1
Contacts:
DPST ............................................................................................................................................................................. N.O/N.O.,N.C./N.C. or N.O./N.C.
Power Rating (Resistive Load):
DPST ..........................................................................................................2 A @ 125 volts RMS-60 Hz or 2 A @ 28 VDC, 1 A @ 250 volts RMS-60 Hz
Operating Temperature Range ...................................................................................................................................................................... -40 °C to +70 °C
Storage Temperature Range ....................................................................................................................................................................... -65 °C to +125 °C
Vibration (Dual Section)......................................................................................................................................................................................................8 G
(Triple Section) ..................................................................................................................................................................................................5 G
(Quadruple Section) ..........................................................................................................................................................................................3 G
Contact Resistance .......................................................................................................................................................................10 milliohms maximum
Contact Bounce ......................................................................................................................................................................... 0.1 millisecond maximum
Shock (Dual Section) ........................................................................................................................................................................................................20 G
(Triple Section) ....................................................................................................................................................................................................15 G
(Quadruple Section) ............................................................................................................................................................................................10 G
Contact Resistance .......................................................................................................................................................................10 milliohms maximum
Contact Bounce ......................................................................................................................................................................... 0.1 millisecond maximum
Switch Actuating Torque (50% Duty cycle @ Rated Power Load) .................................................................................1.41 to 4.94 N-cm (2 to 7 oz.-in.)
Contact Resistance .....................................................................................................................................................................100 milliohms maximum
Moisture Resistance (MIL-STD-202, Method 106, Condition B)
Contact Resistance (0.1 VDC-10 mA) ..........................................................................................................................................10 milliohms maximum
Switch Housing Material ................................................................................................................. High temperature, flame retardant, thermosetting plastic
Mechanical Characteristics
1
Actuating Torque (Each Section, Switch Module Only) ......................................................................................................3.53 to 10.6 N-cm (5 to 15 oz.-in.)
Running Torque (Out of Detent, 2-4 Module Assembly) ....................................................................................................0.21 to 1.41 N-cm (0.3 to 2 oz.-in.)
Detent ....................................................................................................................................................................................................CW or CCW standard
Contact Materials......................................................................................................................................................................... Fine silver with gold overlay
Terminal Styles .................................................................................................................................................................................................Solder lug only
Standard Orientation .............................................................................................................................................................In-line with control terminals
Optional .........................................................................................................................................................................Rotated 90 ° CCW from standard
Terminal Strength (Before and After Soldering Heat Exposure) ........................................................................................................ 0.9 Kg (2 lbs.) minimum
1
NOTE: Model 81/82 performance specifications do not apply to units subjected to printed circuit board cleaning procedures.
Electrical specifications tested at 250 RPM, at room ambient: +25 °C nominal.
Specifications are subject to change without notice.
Users should verify actual device performance in their specific applications.
The products described herein and this document are subject to specific legal disclaimers as set forth on the last page of this document, and at www.bourns.com/docs/legal/disclaimer.pdf.
Specifications are subject to change without notice.
Users should verify actual device performance in their specific applications.
The products described herein and this document are subject to specific legal disclaimers as set forth on the last page of this document, and at www.bourns.com/docs/legal/disclaimer.pdf.
Terminal outlines shown as solid lines represent PC Pins, available
on Model 81. Dashed line terminal outline represents "J" Hook,
available on Model 82.
5.97 ± .38
(.235 ± .015)
5.08 ± .38
(.200 ± .015)
12.7
(.50)
5.33 ± .76
(.210 ± .03)
10.16 ± .13
(.400 ± .005)
Note: For units with dual concentric shaft styles, a
2.54 (.100) spacer is added between the module(s) driven
by the outer shaft and those driven by the inner shaft.
For G, K, or V shafts, add the spacer between
modules 1 and 2. For L or M shafts, add the spacer
between modules 2 and 3. For N or P shafts, add the
spacer between modules 3 and 4.
SLOTTED SHAFT
*EXCLUDES MODELS 83 AND 84
DIMENSIONS:
MM
(INCHES)
Suggested Panel Layout
B
C
BUSHING
A, B & J
E
DIM A
9.91
(.39)
ANTI-ROTATION LUG
A
B
C
E
F
J
K
DIM B
7.75
(.305)
7.75
(.305)
N/A
13.49
(.531)
N/A
9.53
(.375)
9.53
(.375)
DIM C
N/A
7.75
(.305)
7.75
(.305)
N/A
N/A
N/A
9.53
(.375)
DIM D
N/A
N/A
N/A
N/A
7.75
(.305)
N/A
N/A
DIM E
2.49
(.098)
2.49
(.098)
2.49
(.098)
3.45
(.136)
2.54
(.100)
2.54
(.100)
2.54
(.100)
D
A
C, E & N
R&S
U
6.73
(.265)
10.5
(.413)
7.5
(.295)
DIMENSIONS:
MM
(INCHES)
Specifications are subject to change without notice.
Users should verify actual device performance in their specific applications.
The products described herein and this document are subject to specific legal disclaimers as set forth on the last page of this document, and at www.bourns.com/docs/legal/disclaimer.pdf.
85/86 – 5/8 ˝ Square Single-Turn Panel Control with Rotary Switch
Product Dimensions
Primary Potentiometer Module
Model 85/86
14.53
(.572)
9.58 ± .38
(.377 ± .015)
Secondary Potentiometer Module
Model 85/86
10.16
(.400)
15.88
(.625)
15.88
(.625)
Shaft Flat Orientation*
120 ° ± 5 ° CCW END
30 ° ± 5 °
12.7
(.50)
5.97
(.235)
8.56
(.337)
1.60
(.063)
FLATTED SHAFT
5.08
(.200)
SLOTTED SHAFT
*EXCLUDES MODELS 83 AND 84
5.08
(.200) 8.56
(.337)
5.08
(.200)
Switch Module
Model 85/86
REAR
PLATE
COVER
2.77
(.109)
1.35
(.053)
2.29
(.090)
TYP.
6 PLACES
Assembly Sequence
Model 85/86
Secondary Potentiometer Module
Switch Module Terminal Orientation
3
1
4
2
3
1
18.42
(.725)
2.41
1.14
(.095)L X (.045)W
SLOT TYP. 6 PLACES
4
2
HORIZONTAL ORIENTATION
(Types R56, R57, R58 & R59)
VERTICAL ORIENTATION
(Types R50, R51, R52 & R53)
2.92
(.115)
9.53
(.375)
REAR
COVER
PLATE
SWITCH
MODULE
PRIMARY
POTENTIOMETER
MODULE
4
2
3
1
3
1
4
2
DPST (NO/NC)
(TYPES 50, 51, 56, 57)
DPST (NO/NO)
(TYPES 52, 53, 58, 59)
Switch contacts shown in detent position.
Locating Lug Options - All Model 80 Series
A
.46
(.018)
7.75
(.305)
E
13.49
(.531)
J
9.53
(.375)
.79 ± .41
(.031 ± .016)
E = 2.36 ± .76
(.093 ± .03)
H & J = 1.98 ± .41
(.078 ± .016)
2.31
(.091)
3.18
(.125)
.46
(.018)
2.36
(.093)
7.75
(.305)
A
C
7.75
(.305)
.46
(.018)
.79 ± .41
(.031 ± .016)
MOUNTING
SURFACE
TOLERANCES EXCEPT AS SHOWN: DECIMAL .XXX ±
RECOMMENDED
PANEL LAYOUT
7.75
#40 DRILL
(.305)
2.49
DIA.
(.098)
9.91
DIA.
(.390)
.127
(.005)
.XX ± .38
(.015)
ANGLE ± 5 %
2.31
(.091)
DIMENSIONS:
MM
(INCHES)
NOTE: "D" OPTION - NO A/R LUG. OTHER LOCATING LUG OPTIONS AVAILABLE. CONSULT FACTORY FOR DETAILS.
Specifications are subject to change without notice.
Users should verify actual device performance in their specific applications.
The products described herein and this document are subject to specific legal disclaimers as set forth on the last page of this document, and at www.bourns.com/docs/legal/disclaimer.pdf.
:) I applied for the DK-LM3S8962 board from TI for free. I played with it for a long time. I feel that the built-in Ethernet is quite good, and there is also CAN, but there is no USB, and there is no ...
[i=s]This post was last edited by chrisrh on 2021-3-10 10:05[/i]Learn about timers. The timers of FM33LC046N are divided into four categories:
Advanced timer ATIM, general timer GPTIM, basic timer BST...
This design is a solution for 76GHz to 81GHz radar sensor modules. The onboard power supply converts the car battery input to the power rails required for the radar AFE, processor, and CAN-FD transcei...
I bought a Puyuan DS5102CA oscilloscope ten years ago. Suddenly, no matter what waveform I measure, as long as there is a signal, it is a 50HZ sine wave. However, the 1KHZ 1V signal that comes with th...
Many routines in zstack use the serial port. If beginners want to modify the baud rate of the serial port, they can refer to the method I gave.Here we take SerialApp as an example. The modification me...
1 Introduction
The high temperature tester is mainly used for temperature tracking measurement and data acquisition during the heating process. By systematically analyzing the test data, the...[Details]
When the WDP500-2A plane grating monochromator is used to test the emission wavelength of a high-power laser diode at different currents, the matching of the laser diode has the disadvantages of lo...[Details]
At present, the traffic congestion in cities is quite serious. According to relevant news reports: In China, the traffic congestion has expanded from megacities such as Beijing, Shanghai, and Guang...[Details]
1. Introduction
Since the 1980s, with the continuous development of automotive electronic technology, there are more and more electronic control units in automobiles, such as electronic fuel i...[Details]
To differentiate their products in a crowded and competitive market, manufacturers of handheld devices often consider battery life and power management as key selling points for cell phones, PDAs, ...[Details]
July 11, 2012, Beijing - Altera Corporation (NASDAQ: ALTR) today announced the launch of 40-Gbps Ethernet (40GbE) and 100-Gbps Ethernet (100GbE) intellectual property (IP) core products. These core...[Details]
0 Introduction
With the development of society, people pay more and more attention to security work. Monitoring products have been used in various fields instead of being used only in importan...[Details]
LED lamps and bulbs are now rapidly replacing incandescent, halogen and CFL (compact fluorescent lamp) light sources in many general lighting applications. Flyback DC/DC converters are the power su...[Details]
0 Introduction
With the rise and continuous improvement of the solid-state lighting industry, light-emitting diodes (LEDs) have become an alternative lighting technology and are gr...[Details]
In the single-chip microcomputer system, in addition to display devices, sound devices are often used, and the most common sound device is the buzzer. Buzzers are generally used for some low-demand...[Details]
Experimental tasks
A DS18B20 is used to form a temperature measurement system. The temperature measurement accuracy reaches 0.1 degrees. The temperature range is between -20 degrees and +50 de...[Details]
In 2012, more than half of the cars in the European, Japanese and American car markets will be equipped with color displays, navigation systems, satellite communications and other in-vehicle infota...[Details]
At present, the traffic congestion in cities is quite serious. According to relevant news reports: In China, the traffic congestion has expanded from megacities such as Beijing, Shanghai, and Guangzho...[Details]
Today, with energy becoming increasingly scarce, the utilization of natural energy has become the focus of people's attention. Among various natural energies, the endless solar energy is highly fav...[Details]
At present, how various communication technologies will evolve after 3G is a focus of great concern in the industry. Especially for TD-SCDMA, whether it can achieve smooth evolution to the next gen...[Details]
Microcontroller MCU
京公网安备 11010802033920号
EEWORLD
