DUAL ROW STRAIGHT HEADER
2582 SERIE
2.54x 2.54 mm. (0.100 x 0.100”). For PCB solder
Features
Available in 4 through 80 circuits
Mates with dual row 2.54 mm
Material : PBT UL 94V-0
0.64 mm square pin
Gold or phosphor bronze terminal with different plating
Without polarisation
For other options consult
Dimensional information:
Ordering and dimensional information:
DIMENSIONS
A
2,54(0,100)
5,08(0,200)
7,62(0,300)
10,16(0,400)
12,70(0,500)
15,24(0,600)
17,78(0,700)
20,32(0,800)
22,86(0,900)
25,40(1,000)
27,94(1,100)
30,48(1,200)
33,02(1,300)
35,56(1,400)
38,10(1,500)
40,64(1,600)
43,18(1,700)
45,72(1,800)
48,26(1,900)
50,80(2,000)
53,34(2,100)
55,88(2,200)
58,42(2,300)
60,96(2,400)
63,50(2,500)
66,04(2,600)
68,58(2,700)
71,12(2,800)
73,66(2,900)
76,20(3,000)
78,74(3,100)
81,28(3,200)
83,82(3,300)
86,36(3,400)
88,90(3,500)
91,44(3,600)
93,98(3,700)
96,52(3,800)
99,06(3,900)
B
5,08(0,200)
7,62(0,150)
10,16(0,200)
12,70(0,250)
15,24(0,300)
17,78(0,350)
20,32(0,400)
22,86(0,450)
25,40(0,500)
27,94(0,550)
30,48(0,600)
33,02(0,650)
35,56(0,700)
38,10(0,750)
40,64(0,800)
43,18(0,850)
45,72(0,900)
48,26(0,950)
50,80(1,000)
53,34(1,050)
55,88(1,100)
58,42(1,150)
60,96(1,200)
63,50(1,250)
66,04(1,300)
68,58(1,350)
71,12(1,400)
73,66(1,450)
76,20(1,500)
78,74(1,550)
81,28(1,600)
83,82(1,650)
86,36(1,700)
88,90(1,750)
91,44(1,800)
93,98(1,850)
96,52(1,900)
99,06(1,950)
101,60(2,000)
CIRCUIT SIZE
04
06
08
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
42
44
46
48
50
52
54
56
58
60
62
64
66
68
70
72
74
76
78
80
PART NUMBER
2582-T04C
2582-T06C
2582-T08C
2582-T10C
2582-T12C
2582-T14C
2582-T16C
2582-T18C
2582-T20C
2582-T22C
2582-T24C
2582-T26C
2582-T28C
2582-T30C
2582-T32C
2582-T34C
2582-T36C
2582-T38C
2582-T40C
2582-T42C
2582-T44C
2582-T46C
2582-T48C
2582-T50C
2582-T52C
2582-T54C
2582-T56C
2582-T58C
2582-T60C
2582-T62C
2582-T64C
2582-T66C
2582-T68C
2582-T70C
2582-T72C
2582-T74C
2582-T76C
2582-T78C
2582-T80C
B
A
2.54
0.64mm.
0.64 mm.
5.80
H(6.0)
4.30
F(3.0)
2.54
T = Contact Plating
T =
2.
Tin-plated.
T =
3.
Gold flash over 1.27 µ Ni.
T =
4.
0.25 µ Gold over 1.27 µ Ni.
T =
5.
0.38 µ Gold over 1.27 µ Ni.
T =
6.
0.75 µ Gold over 1.27 µ Ni.
MECANIZADO RECOMENDADO
2.54±0.05
.100±.002
C = Pin Dimension
C =
1.
Dim.
H
= 6.00 mm. Dim.
F
= 3.00 mm.
1.02±0.05
.040±.002
2.54±0.05
.100±.002
CATÁLOGO GENERAL
E-19
