23EXA103MMF20N

Description
RESISTOR, POTENTIOMETER, CARBON FILM, 1 TURN(S), 0.4W, 10000ohm, ROHS COMPLIANT
CategoryPassive components    The resistor
File Size116KB,1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Environmental Compliance
Download Datasheet Parametric Compare View All

23EXA103MMF20N Overview

RESISTOR, POTENTIOMETER, CARBON FILM, 1 TURN(S), 0.4W, 10000ohm, ROHS COMPLIANT

23EXA103MMF20N Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
Objectid1666314620
package instructionROHS COMPLIANT
Reach Compliance Codeunknown
ECCN codeEAR99
Actuator directionHORIZONTAL
Actuator typeSHAFT
gang number1
Manufacturer's serial number23
Installation featuresTHROUGH HOLE MOUNT
Number of terminals3
number of turns1
Package shapeCIRCULAR PACKAGE
Rated power dissipation(P)0.4 W
resistance10000 Ω
resistance lawLINEAR
Resistor typePOTENTIOMETER
surface mountNO
technologyCARBON FILM
Terminal shapeFLAT
Tolerance20%
C orporate Hom e
|
Electronic Components
|
Se gm e nts
|
W ho W e Are
My Account
Searc h
Products
Documentation
Resources
My Account
Customer Support
Home
>
Products
>
By Type
>
Resistors
>
Product Feature Selector
> Product Details
23EXA103MMF20N Product Details
Live Product Chat
Variable Resistors
Always EU R oHS/ELV C om plia nt
(
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
23EXA103MMF20N
(1624165-1)
T E I nternal N umber: 1 6 2 4 1 6 5 - 1
Product Highlights:
l
Variable Resistor
l
Resistor Type = Potentiometer
l
Resistance Selection = K ?
l
Resistance = 10K ?
l
Power Rating = .40 W
View all Features
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Active
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
Spindle Operated Potentiometers - Type 23 series - T...
(PDF, English)
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type = Variable Resistor
l
Resistor Type
= Potentiometer
l
Resistance (?)
= 10K
l
Element
= C arbon
l
Sealed
= No
l
Termination Type
= Eyelet
Electrical Characteristics:
l
Resistance Selection (?) = K
l
Power Rating (W)
= 0.40
l
Tolerance (%)
= 20
Termination Related Features:
l
Termination Post Orientation
= In Line
Body Related Features:
l
Series
= 23
l
Shaft Style
= Full, 6.35mm, Special Angle
l
Package, C omponent Size
= 25mm Dia.
Configuration Related Features:
l
Sections
= Single
l
Adjustment Location
= Side
l
Adjustment Style
= Spindle
l
Operating Function
= Single Turn
Industry Standards:
l
RoHS/ELV C ompliance
= RoHS compliant, ELV compliant
l
Lead Free Solder Processes
= Wave solder capable to 240?C , Wave
solder capable to 260?C , Wave solder capable to 265?C
l
RoHS/ELV C ompliance History = Always was RoHS compliant
Other:
l
Brand = C itec
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Provide Website Feedback
|
Need Help?
Home
|
C ustomer Support
|
Suppliers
|
Site Map
|
Privacy Policy
|
Browser Support
©
2009 Tyco Electronics C orporation All Rights Reserved

23EXA103MMF20N Related Products

23EXA103MMF20N 1624165-1
Description RESISTOR, POTENTIOMETER, CARBON FILM, 1 TURN(S), 0.4W, 10000ohm, ROHS COMPLIANT RESISTOR, POTENTIOMETER, CARBON FILM, 1 TURN(S), 0.4W, 10000ohm, ROHS COMPLIANT
Is it Rohs certified? conform to conform to
Objectid 1666314620 1666314278
Reach Compliance Code unknown unknown
ECCN code EAR99 EAR99
Actuator direction HORIZONTAL HORIZONTAL
Actuator type SHAFT SHAFT
gang number 1 1
Manufacturer's serial number 23 23
Installation features THROUGH HOLE MOUNT THROUGH HOLE MOUNT
Number of terminals 3 3
number of turns 1 1
Package shape CIRCULAR PACKAGE CIRCULAR PACKAGE
Rated power dissipation(P) 0.4 W 0.4 W
resistance 10000 Ω 10000 Ω
resistance law LINEAR LINEAR
Resistor type POTENTIOMETER POTENTIOMETER
surface mount NO NO
technology CARBON FILM CARBON FILM
Terminal shape FLAT FLAT
Tolerance 20% 20%
