MCC
DESCRIPTION (300 watt)
omponents
21201 Itasca Street Chatsworth
!"#
$
% !"#
SMDA03C-4-2
THRU
SMDA24C-4-2
TVSarray™ Series
™
This TRANSIENT VOLTAGE SUPPRESSOR (TVS) array is packaged
in a SO-8 configuration giving protection to 4 Bidirectional data or
interface lines. It is designed for use in applications where protection
is required at the board level from voltage transients caused by
electrostatic discharge (ESD) as defined in IEC 1000-4-2, electrical
fast transients (EFT) per IEC 1000-4-4 and effects of secondary
lighting.
These TVS arrays have a peak power rating of 300 watts for an 8/20µsec pulse. This array is suitable for
protection of sensitive circuitry consisting of TTL, CMOS DRAM’s, SRAM’s, HCMOS, HSIC
microprocessors, and I/O transceivers. The SMDAXXC-4-2 product provides board level protection from
static electricity and other induced voltage surges that can damage sensitive circuitry.
FEATURES
•
•
•
Protects up to 4 Bidirectional lines
Surge protection Per IEC 1000-4-2, 1000-4-4
SO-8 Packaging
MECHANICAL
•
•
•
•
Molded SO-8 Surface Mount
Weight: 0.066 grams (approximate)
Marking: Logo, device number, date code
Pin #1 defined by DOT on top of package
MAXIMUM RATINGS
•
•
•
•
Operating Temperatures: -55 C to +150 C
Storage Temperature: -55
0
C to +150
0
C
Peak Pulse Power: 300 Watts (8/20
µsec,
Figure 1)
Pulse Repetition Rate: <.01%
0
0
PACKAGING
•
•
•
Tape & Reel EIA Standard 481-1-A
13 inch reel 2,500 pieces (OPTIONAL)
Carrier tubes 95 pcs per (STANDARD)
ELECTRICAL CHARACTERISTICS PER LINE @ 25
0
C Unless otherwise specified
STAND
OFF
VOLTAGE
V
WM
VOLTS
SMDA03C-4-2
SMDA05C-4-2
SMDA12C-4-2
SMDA15C-4-2
SMDA24C-4-2
RFA
RFB
RFC
RFD
RFE
3.3
5.0
12.0
15.0
24.0
BREAKDOWN
VOLTAGE
V
BR
@1 mA
VOLTS
MIN
4
6.0
13.3
16.7
26.7
CLAMPING
VOLTAGE
V
C
@ 1 Amp
(FIGURE 2)
VOLTS
MAX
7.0
9.8
19.0
24.0
43.0
CLAMPING
VOLTAGE
V
C
@ 5 Amp
(FIGURE 2)
VOLTS
MAX
9.0
11
24
30
55
LEAKAGE
CURRENT
I
D
@ V
WM
µA
MAX
200
40
1
1
1
CAPACITANCE
(f=1 MHz)
@0V
C
pF
TYP
300
200
75
50
35
TEMPERATURE
COEFFICIENT
OF V
BR
á
VBR
mV/°C
MAX
-5
1
8
13
28
PART
NUMBER
DEVICE
MARKING
NOTE:
TVS product is normally selected based on its stand off Voltage V
WM
. Product selected voltage
should be equal to or greater than the continuous peak operating voltage of the circuit to be protected.
Application:
The SMDAXXC-4-2 product is designed for transient voltage suppression protection of ESD
sensitive components at the board level. It is an ideal product to be used for protection of I/O Transceivers.
www.mccsemi.com
