EHV220M2ERGT3: DescriptionAluminum Electrolytic Capacitor, Polarized, Aluminum (wet), 250V, 20% +Tol, 20% -Tol, 22uF, Surface Mount, 5151; CategoryPassive components capacitor; File Size141KB，2 Pages; ManufacturerHitano Enterprise Corp; Environmental Compliance

Download Datasheet Parametric View All

EHV220M2ERGT3 Overview

Aluminum Electrolytic Capacitor, Polarized, Aluminum (wet), 250V, 20% +Tol, 20% -Tol, 22uF, Surface Mount, 5151

EHV220M2ERGT3 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Objectid	1240378498
package instruction	, 5151
Reach Compliance Code	compliant
ECCN code	EAR99
capacitance	22 µF
Capacitor type	ALUMINUM ELECTROLYTIC CAPACITOR
dielectric materials	ALUMINUM (WET)
leakage current	0.32 mA
Installation features	SURFACE MOUNT
negative tolerance	20%
Number of terminals	2
Maximum operating temperature	105 °C
Minimum operating temperature	-40 °C
Package shape	CYLINDRICAL PACKAGE
method of packing	TR
polarity	POLARIZED
positive tolerance	20%
Rated (DC) voltage (URdc)	250 V
ripple current	105 mA
size code	5151
surface mount	YES
Delta tangent	0.2
Terminal surface	NOT SPECIFIED
Terminal shape	FLAT

Preview

Download Datasheet

View All

EHV

SERIES

SMD TYPE Reflow Soldering is available

Life 2000 hours at 105℃

Available For High Density Mounting

Characteristics

Category Temperature Range

Capacitance Tolerance

Leakage Current

6.3 ~ 100V

-55

℃

~ +105℃

160 ~ 450V

-40

℃

~ +105℃

+20% -20% (at 20

℃

, 120Hz)

SIZE A~F: I≤0.01CV or 3uA, whichever is greater 2 minutes after Rated Voltage applied

SIZE G~J(6.3V~100V): I≤0.03CV whichever is greater 2 minutes after Rated Voltage applied

SIZE G~J (160V~450V): I≤0.04CV +100uA whichever is greater 5 minutes after rated voltage applied

160~

400~

Dissipation Factor

Voltage (V)

6.3

100

250

450

( tanδ)Max

(at 20

℃

, 120Hz)

SIZE A~F

0.45

0.35

0.28

0.18

0.16

0.14

0.12

SIZE G~J

0.45

0.38

6.3

0.34

0.26

0.22

0.18

0.14

0.10

0.20

100

160~

250

0.25

400~

450

Stability at Low Temperature

(

at 120Hz)

Voltage (V)

Load Life

Shelf Life

Z -25

℃

SIZE A~F

/Z +20

℃

SIZE G~J

SIZE A~F

Z-40

℃

SIZE G~J

/Z 20℃

After the rated voltage

Capacitance change Within

±25%

of initial value(SIZE G~I:

±20%)

has been applied for 2000 D.F. tanδ

Less than

±300%

of specified value(SIZE D~I:

±200%)

hours at 105

℃

Leakage current

Less than Initial specified value

After storage for 1000 hours at 105

℃

, with no voltage applied and being stabilized at +20

℃

, Capacitor

shall meet the limit specified in load life.(Refer to JIS C5101-4 4.1)

Diagram of dimensions

SIZE Dφ

6.3

12.5

5.5

5.7

7.7

6.5

10.5

13.5

16.0

16.5

4.3

5.3

6.6

8.4

8.34

10.4

13.0

17.0

19.0

5.1

6.1

7.4

9.2

11.2

15.0

19.0

21.0

4.3

5.3

6.6

8.4

8.34

10.4

13.0

17.0

19.0

P±0.2

0.5~0.8 1.0

0.5~0.8 1.5

0.5~0.8 2.0

0.7~1.1 3.1

0.7~1.1 4.7

1.1~1.4 4.4

1.1~1.4 6.4

Size A~F refer to Fig. 1

Size G~J refer to Fig. 2
