(for storage, operating, rating, soldering, mounting and handling) in this catalog to prevent smoking and/or burning, etc.
• This catalog has only typical specifications. Therefore, please approve our product specifications or transact the approval sheet for product specifications before ordering.
R44E.pdf
Mar.6,2020
EU RoHS Compliant
For
r o ur
!Note
• Please read rating and
!CAUTION
(for storage, operating, rating, soldering, mounting and handling) in this catalog to prevent smoking and/or burning, etc.
• This catalog has only typical specifications. Therefore, please approve our product specifications or transact the approval sheet for product specifications before ordering.
R44E.pdf
Mar.6,2020
1
Contents
Product specifications are as of
February 2020
.
Part Numbering
Basic Characteristics
1
Temperature Sensor and Compensation
0201 (0603) Size
2
Temperature Sensor and Compensation
0402 (1005) Size/NCP Series
Temperature Sensor and Compensation
0402 (1005) Size/NCU Series
3
Temperature Sensor and Compensation
0603 (1608) Size/NCP Series
Temperature Sensor and Compensation
0603 (1608) Size/NCU Series
Temperature Sensor and Compensation Chip Type
Standard Land Pattern Dimensions
Temperature Sensor and Compensation Chip Type
Temperature Characteristics (Center Value)
Temperature Sensor and Compensation Chip Type
!Caution/Notice
Temperature Sensor and Compensation Chip Type
Package
4
Temperature Sensor Thermo String
Cooper Wire Type
Temperature Sensor Thermo String
Nickel Copper Wire Type
Temperature Sensor Thermo String Type
Specifications and Test Methods
5
Temperature Sensor Lead Type
Temperature Sensor Lead Type
Specifications and Test Methods
6
Temperature Sensor Lead Insulation Type
Temperature Sensor Lead Insulation Type
Specifications and Test Methods
Temperature Sensor Thermo String/Lead Type
Temperature Characteristics (Center Value)
Temperature Sensor Thermo String/Lead Type
!Caution/Notice
Temperature Sensor Thermo String/Lead Type
Package
p2
p5
2
p6
p7
p9
3
p10
p12
p13
p14
p17
p21
4
5
p23
p24
p25
p27
p28
p29
p30
p31
p32
p34
6
Please check the MURATA website (https://www.murata.com/)
if you cannot find a part number in this catalog.
!Note
• Please read rating and
!CAUTION
(for storage, operating, rating, soldering, mounting and handling) in this catalog to prevent smoking and/or burning, etc.
• This catalog has only typical specifications. Therefore, please approve our product specifications or transact the approval sheet for product specifications before ordering.
R44E.pdf
Mar.6,2020
o
Part Numbering
NTC Thermistors for Temp. Sensor and Compensation Chip Type
(Part Number)
1Product
ID
Product ID
NC
2Series
Code
P
U
3Dimensions
(L x W)
Code
03
15
18
21
Dimensions (L x W)
0.60 x 0.30mm
1.00 x 0.50mm
1.60 x 0.80mm
2.00 x 1.25mm
EIA
0201
0402
0603
0805
Series
Plated Termination Series
High Reliability Series
NTC Thermistors Chip Type
NC
1
P 18 XH 103 J 03 RB
2 3
4
5
6 7
8
5Resistance
Expressed by three-digit alphanumerics. The unit is ohm (Ω).
The first and second figures are significant digits, and the third
figure expresses the number of zeros that follow the two figures.
Ex.
Code
102
103
104
6Resistance
Tolerance
Code
D
F
E
J
7Individual
Specifications
Structures and other specifications are expressed by two figures.
Ex.
Code
03/05/10/12/60
pS
8Packaging
Code
RA
RB
RC
RL
Packaging
Plastic Taping 4mm Pitch (4000 pcs.)
Paper Taping 4mm Pitch (4000 pcs.)
Paper Taping 2mm Pitch (10000 pcs.)
Paper Taping 2mm Pitch (15000 pcs.)
Individual Specifications
Standard Type
Automotive Type
Resistance Tolerance
±0.5%
±1%
±3%
±5%
Resistance
1kΩ
10kΩ
100kΩ
4Temperature
Characteristics
Code
XC
XF
XH
XM
XQ
XV
XW
WB
WD
WF
WL
WM
Temperature Characteristics
Nominal B-Constant 3100–3149K
Nominal B-Constant 3250–3299K
Nominal B-Constant 3350–3399K
Nominal B-Constant 3500–3549K
Nominal B-Constant 3650–3699K
Nominal B-Constant 3900–3949K
Nominal B-Constant 3950–3999K
Nominal B-Constant 4050–4099K
Nominal B-Constant 4150–4199K
Nominal B-Constant 4250–4299K
Nominal B-Constant 4450–4499K
Nominal B-Constant 4500–4549K
2
!Note
• Please read rating and
!CAUTION
(for storage, operating, rating, soldering, mounting and handling) in this catalog to prevent smoking and/or burning, etc.
• This catalog has only typical specifications. Therefore, please approve our product specifications or transact the approval sheet for product specifications before ordering.
R44E.pdf
Mar.6,2020
NTC Thermistor for Temperature Sensor Thermo String Type
(Part Number)
1Product
ID
Product ID
NXF
NTC Thermistors Sensor Thermo String Type
NXF
1
T
2
15
3
XH
4
103
5
F
A
2
B
025
:
7Lead
Wire Type
Code
A
E
2Individual
Specifications
Code
T
3Chip
Dimensions
Code
15
Dimensions (L x T)
1.00 x 0.50mm
EIA
0402
9Packaging
4Temperature
Characteristics
Code
XH
XM
XV
WB
WF
5Resistance
Expressed by three figures. The unit is (Ω). The first and second
figures are significant digits, and the third figure expresses the
number of zeros that follow the two figures.
Ex.
Code
103
473
104
6Resistance
Tolerance
Code
F
E
Resistance Tolerance
±1%
±3%
Resistance
10kΩ
47kΩ
100kΩ
Temperature Characteristics
Nominal B-Constant 3350–3399K
Nominal B-Constant 3500–3549K
Nominal B-Constant 3900–3949K
Nominal B-Constant 4050–4099K
Nominal B-Constant 4250–4299K
:Dimensions
(Full Length)
Code
021
025
030
035
040
045
050
060
070
080
090
100
110
120
130
140
150
Dimensions (Full Length)
21mm
25mm
30mm
35mm
40mm
45mm
50mm
60mm
70mm
80mm
90mm
100mm
110mm
120mm
130mm
140mm
150mm
Code
B
Packaging
Bulk
Individual Specifications
Commercial Type
8Shape
of the Lead Wire Kink
Code
1
2
A
Shape of the Lead Wire Kink
Twisted Lead Wire Type
Standard Type (Cooper Wire Type)
Standard Type (Nickel Copper Wire Type)
Lead Wire Type
ø0.3mm Copper Lead Wire with Polyurethane Coat
ø0.3mm Nickel Copper Lead Wire with Modified Polyester Coat
