High Current Power Chokes
R*
Actual Size
Physical Parameters
Inches
Millimeters
A
1.020 to 1.080
25.91 to 27.44
B
0.480 to 0.510
12.20 to 12.96
C
0.520 Maximum
13.21 Maximum
D
0.240 Minimum
6.10 Minimum
E
0.120 to 0.160
3.05 to 4.07
F
0.500 (Ref. Only)
12.70 (Ref. Only)
G
0.250 (Ref. Only)
6.35 (Ref. Only)
Dimensions
"A" and "C" and "G" are over the terminals.
Operating Temperature Range
-55°C to +130°C
Current Rating at 85°C Ambient
45°C Temperature Rise
Maximum Power Dissipation
at +85°C: 1.166 Watts Maximum
Inductance
Measured @ 1 kHz with 0 ADC on Wayne Kerr
3245A, or equivalent.
Incremental Current
The amount of DC that decreases the
Inductance by 5% maximum relative to the 0 ADC.
Dielectric Withstanding Voltage
Meets MIL-STD-202,
Method 301, 1000 Vrms Minimum
Marking
DELEVAN, INDUCTANCE VALUE and DATE CODE/LOT
SYMBOL (YYWWL). Note: An "R" before the date code/lot
symbol indicates a RoHS Compliant choke.
DELEVAN
3.9uH
R YYWWL
Thermal Shock
Meets MIL-STD-202, Method 107,
Test Condition A-1 (-55°C to +130°C).
Mechanical Shock
Meets MIL-STD-202, Method 213,
Test Condition I.
Vibration
Meets MIL-STD-202, Method 204, Test Condition D
Solderability
Meets MIL-STD-202, Method 208
Terminal Material and Final Finish
Series 5500R: (Tin - Silver - Copper) Sn96.5Ag3.0Cu0.5 over Copper (Cu)
Series 5500: (Tin - Lead) Sn63Pb37 over Copper (Cu)
Weight
13 Grams Maximum
Packaging
Tape and Reel (44mm): 13” reel,
200 pieces max: 7” reel not available
Made In The U.S.A.
-392K
-472K
-562K
-682K
-822K
-103K
-123K
-153K
-183K
-223K
-273K
-333K
-393K
-473K
-563K
-683K
-823K
-104K
-124K
-154K
-184K
-224K
-274K
-334K
-394K
-474K
-564K
-684K
-824K
-105K
-125K
-155K
-185K
-225K
-275K
-335K
-395K
-475K
-565K
-685K
-825K
-106K
-126K
-156K
-186K
-226K
-276K
-336K
-396K
-476K
-566K
-686K
-826K
-107K
SERIES 5500R AND 5500
3.9
0.007
11.91
4.7
0.008
11.14
5.6
0.011
9.50
6.8
0.012
9.10
8.2
0.013
8.74
10
0.016
7.88
12
0.018
7.43
15
0.020
7.05
18
0.022
6.72
22
0.024
6.43
27
0.025
6.30
33
0.028
5.96
39
0.031
5.66
47
0.034
5.41
56
0.043
4.81
68
0.060
4.08
82
0.066
3.88
100
0.084
3.44
120
0.113
2.96
150
0.129
2.78
180
0.150
2.57
220
0.162
2.48
270
0.226
2.10
330
0.257
1.97
390
0.288
1.86
470
0.393
1.59
560
0.504
1.40
680
0.570
1.32
820
0.643
1.24
1,000
0.844
1.08
1,200
0.977
1.01
1,500
1.18
0.92
1,800
1.50
0.81
2,200
1.76
0.75
2,700
2.13
0.68
3,300
2.53
0.63
3,900
2.84
0.59
4,700
3.79
0.51
5,600
4.24
0.48
6,800
5.75
0.42
8,200
6.44
0.39
10,000
7.30
0.37
12,000
9.34
0.33
15,000
10.7
0.30
18,000
14.8
0.26
22,000
18.0
0.23
27,000
22.7
0.21
33,000
25.7
0.20
39,000
29.7
0.18
47,000
33.7
0.17
56,000
38.0
0.16
68,000
52.8
0.14
82,000
67.3
0.12
100,000
76.0
0.11
9.13
8.30
7.61
7.02
6.52
5.71
5.07
4.57
4.15
3.65
3.38
3.04
2.85
2.61
2.34
2.12
1.94
1.76
1.60
1.43
1.30
1.19
1.07
0.96
0.88
0.81
0.74
0.68
0.63
0.56
0.51
0.45
0.41
0.37
0.32
0.30
0.28
0.25
0.23
0.21
0.19
0.17
0.16
0.14
0.13
0.12
0.10
0.09
0.09
0.08
0.07
0.07
0.06
0.05
OPTIONAL TOLERANCES: J = +/- 5% L = +/- 15%
The Suffix (Optional Tolerance “J” or “L”) should replace the “K”, in the dash number.
*Complete part # must include series # PLUS the dash #
