F-214 (Rev 28AUG14)
IPR1–06–D
T1M74-L–01–F
(2,54 mm) .100"
MRTD–06–24–L–03.2
IPR1, T1M74, MRTD, MRTDT SERIES
DISCRETE WIRE COMPONENTS & TOOLING
SPECIFICATIONS
For complete specifications
see www.samtec.com?IPR1
or www.samtec.com?T1M74
TYPE
PINS
PER ROW
D
–D
= Double
Row
TYPE
WIRE
GAUGE
PLATING
OPTION
TOOLING
• Hand Tool (20-24 AWG):
CAT-HT-174-2024-11
• Hand Tool (26-30 AWG):
CAT-HT-174-2630-11
• Mini Applicator (20-24
AWG):
CAT-MA-174-2024-XX-01
• Mini Applicator
(26-30 AWG):
CAT-MA-174-2630-XX-01
IPR1
= Body,
Loose
–02, –03, –04,
–05, –06, –08,
–10, –12, –15
(Standard sizes)
(7,62)
.300
No. of positions
x (2,54) .100
+ (3,81) .150
–01
T1M74-L
= Contact,
Loose
= 26 to 30 AWG
–F
= Gold flash
on contact
–02
= 20 to 24 AWG
–L
= 10µ" (0,25 µm)
Gold on contact
T1M74-R
(5,08)
.200
(8,38)
.330
= Contact,
Full Reel
300
(15,300 Parts
Ree
per Reel)
(19,33)
9,3 )
.761
761
(1,57
(1,57)
.062
DIA
(3,81)
.150
(3,17)
.125
(17,53)
.690
(1,91)
.075
(9,65)
.380
Insulator Material:
Nylon
Contact Material:
Phosphor Bronze
Mates with:
MMSD(T)
TYPE
SPECIFICATIONS
For complete specifications
see www.samtec.com?MRTD
or www.samtec.com?MRTDT
Insulator Material:
Nylon 66
Contact Material:
Phosphor Bronze
Plating:
Au or Sn over
50µ" (1,27 µm) Ni
Operating Temp Range:
-40°C to +105°C (PVC)
®
-55°C to +125°C (*Teflon )
Wire:
20 to 28 AWG
RoHS Compliant:
Yes
*DuPont
™
Teflon
®
is a
registered trademark of the
E.I. du Pont de Nemours
and Company or its affiliates.
PINS PER
ROW
WIRE
GAUGE
PLATING
OPTION
ASSEMBLY
LENGTH
–“XX.X”
= Assembly Length
in Inches
Single ended =
(76,2 mm) 03.0" min.
Double ended =
(82,6 mm) 03.2" min.
OPTION
MRTD
= Double Row
PVC Cable
MRTDT
= Double Row
*Teflon
®
Cable
–02,
–03, –04,
–05, –06,
–08, –10,
–12, –15
(Standard sizes)
–20
–22
–24
–24C
= Color
Coded
Cable
–L
= 10µ"
(0,25 µm)
Gold on
contact
Leave blank for single
ended cable assembly.
Double ended only.
–L1
= Plastic Transfer
Latch up, staight
–L3
= Plastic Transfer
Latch down, staight
END 1
01
(5,08)
.200
No. of positions
x (2,54) .100
+ (3,81) .150
(2,54)
.100
(7,62)
.300
(2,54)
.100
–26
–28
APPLICATION
MRTD
ALSO AVAILABLE
(MOQ Required)
• Other color coded cable
cables
(*Teflon
®
N/A)
/A)
• Other sizes/pin counts
counts.
• Other Gold platings
ther
• Metal latch op
etal
option
Contact Samte
Samtec.
Note:
Teflon
®
cable is
ot
Tef
intended for crimp only.
ende
Contact Samtec for
solderable cable applications.
(2,54)
54
.100
0
(9,14)
0
.360
(17,53)
17,53)
.690
9
MMSD
MRTD/MRTDT
END 2
Note:
Acceptable panel thickness of
(0,84 mm) .0329" to (2,28 mm) .0897"
WWW.SAMTEC.COM
Due to technical progress, all designs, specifications and components are subject to change without notice.
