• over current, over voltage, and short circuit protections
• UL/cUL and TUV 60950-1 safety approvals
• efficiency up to 82%
RoHS
MODEL
VOF-25-3.3
VOF-25-5
VOF-25-7.5
VOF-25-9
VOF-25-12
VOF-25-15
VOF-25-24
Notes:
output
voltage
(Vdc)
output
current
max
(A)
output
power
max
(W)
ripple
1
and noise
max
(mVp-p)
efficiency
typ
(%)
3.3
5
7.5
9
12
15
24
4.4
4.4
3.0
2.7
2.0
1.6
1.0
15
22
23
24
24
24
24
50
50
75
90
120
150
240
70
73
73
77
80
80
82
1. Ripple & noise are measured at 20 MHz BW with 0.1
μF
ceramic cap and a 10
μF
electrolytic capacitors on the output and the two
earth ground pads are connected to input earth ground.
PART NUMBER KEY
VOF-25 -
XX
Base Number
Output Voltage
cui.com
CUI Inc
│
SERIES:
VOF-25
│
DESCRIPTION:
AC-DC POWER SUPPLY
date
08/17/2012
│
page
2 of 5
INPUT
parameter
voltage
frequency
current
inrush current
input fuse
at 110 Vac
at 220 Vac
at 110 Vac, full load, cold start
at 220 Vac, full load, cold start
built-in, non-user serviceable
conditions/description
min
85
120
47
0.7
0.35
20
40
typ
max
264
375
63
units
Vac
Vdc
Hz
A
A
A
A
OUTPUT
parameter
line regulation
load regulation
temperature coefficient
hold-up time
adjustability
switching frequency
115 Vac at full load
adjustable with built-in trim pot
16
-5
45
50
+5
55
conditions/description
high line to low line at full load
full load to 10% load
min
typ
±0.5
±1
±0.05
max
units
%
%
%/°C
ms
%
kHz
PROTECTIONS
parameter
over voltage protection
over current protection
short circuit protection
conditions/description
clamped by TVS
automatically recovers
protected, long term short circuit may reduce
reliability
105
min
typ
max
115
units
%
%Io
SAFETY & COMPLIANCE
parameter
isolation voltage
isolation resistance
safety approvals
EMI/EMC
leakage current
RoHS compliant
MTBF
yes
according to MIL-HDBK-217F
250,000
hours
conditions/description
primary to secondary for 1 minute
primary to transformer core for 1 minute
primary to ground for 1 minute
input to output at 500 Vdc at 25°C
TUV EN 60950, CE, UL/cUL 60950-1
FCC class B, EN 55022 class B
1.5
mA
min
3,000
1,500
1,500
50
nom
max
units
Vac
Vac
Vac
MΩ
ENVIRONMENTAL
parameter
operating temperature
storage temperature
operating humidity
storage humidity
operating altitude
storage altitude
non-condensing
non-condensing
conditions/description
see derating curve
min
0
-20
20
20
10,000
3,000
30,000
9,000
nom
max
60
85
90
95
units
°C
°C
%
%
ft
m
ft
m
cui.com
CUI Inc
│
SERIES:
VOF-25
│
DESCRIPTION:
AC-DC POWER SUPPLY
date
08/17/2012
│
page
3 of 5
MECHANICAL
parameter
dimensions
weight
cooling method
free air convection or forced air
(see derating curves below)
conditions/description
3.500 x 2.008 x 0.9803 (88.9 x 51 x 24.9 mm)
0.09
min
typ
max
units
inch
kg
DERATING CURVES
1. output power vs. ambient temperature
a. 3.3, 5 V models
Load factor
( %)
Load factor
( %)
100
80
60
40
20
0
0
10
20
30
40
50
60
2
1
b. all other models
80
60
40
20
0
0
10
20
30
40
50
60
2. output power vs. input voltage
all models
Load factor
( %)
100
80
60
40
20
0
0
85
90
110
220
264
100
Ambient temperature (°C)
1
2
Ambient temperature (°C)
1
Input Voltage Vac
Convection
3
Forced air (0.5m /min) (18 CFM)
Forced air (0.5m /min) (18 CFM)
3
MATING CONNECTORS
parameter
ac input (CN1)
dc output (CN2)
conditions/description
mates with Molex housing 09-50-3031 with Molex 2878 series crimp contact
mates with Molex housing 09-50-3041 with Molex 2878 series crimp contact
MOUNTING METHOD
(performance evaluations conducted under this mounting method)
Horizontal
cui.com
CUI Inc
│
SERIES:
VOF-25
│
DESCRIPTION:
AC-DC POWER SUPPLY
date
08/17/2012
│
page
4 of 5
MECHANICAL DRAWING
units: mm [inches]
tolerance: ±0.3 [±0.01]
90.0 3.54
81.7 3.22
CN1
1
2
3
L
no pin
N
51.0 2.01
3
2
1
CN1
CN2
4
3
CN2
2
1
1
2
3
4
-Vo
-Vo
+Vo
+Vo
42.5 1.67
VADJ
3.5 (4 PLCS)
MOUNTING HOLE
C
1.6 0.06
20.32 0.80
3.0 MAX
(LEAD)
cui.com
CUI Inc
│
SERIES:
VOF-25
│
DESCRIPTION:
AC-DC POWER SUPPLY
date
08/17/2012
│
page
5 of 5
REVISION HISTORY
rev.
1.0
1.01
1.02
1.03
1.04
1.05
description
initial release
corrected CN1 connector designation on mech drawing
dimension added to drawing
new template applied
added MTBF data
V-Infinity branding removed
date
04/03/2009
02/16/2010
05/02/2011
05/13/2011
09/20/2011
08/17/2012
The revision history provided is for informational purposes only and is believed to be accurate.
