WRA_ZP-6W & WRB_ZP-6W Series
6W, WIDE INPUT, ISOLATED & REGULATED
DUAL/ SINGLE OUTPUT DIP DC-DC CONVERTER
multi-country patent protection
FEATURES
Efficiency up to 86%
Wide (2:1) Input Range
1.5KVDC Input/Output Isolation
Short circuit protection(automatic recovery)
Operating Temperature: -40°C to +85°C
Internal SMD construction
Metal Shielding Package
No Heat Sink Required
Industry-Standard Pinout
MTBF>1,000,000 hours
RoHS Compliance
RoHS
PRODUCT PROGRAM
Part
Number
WRA0505ZP-6W
WRA0512ZP-6W
WRA0515ZP-6W
WRB0505ZP-6W
WRB0512ZP-6W
WRB0515ZP-6W
WRB0524ZP-6W
WRA1205ZP-6W
WRA1212ZP-6W
WRA1215ZP-6W
WRB1203ZP-6W
WRB1205ZP-6W
WRB1212ZP-6W
WRB1215ZP-6W
WRB1224ZP-6W
WRA2405ZP-6W
WRA2412ZP-6W
WRA2415ZP-6W
WRB2403ZP-6W
WRB2405ZP-6W
WRB2412ZP-6W
WRB2415ZP-6W
WRB2424ZP-6W
WRA4805ZP-6W
WRA4812ZP-6W
WRA4815ZP-6W
WRB4805ZP-6W
WRB4812ZP-6W
48
36-72
80
24
18-36
40
12
9-18
20
5
4.5-9
11
Input
Voltage (VDC)
Nominal Range
Max*
Voltage
(VDC)
±5
±12
±15
5
12
15
24
±5
±12
±15
3.3
5
12
15
24
±5
±12
±15
3.3
5
12
15
24
±5
±12
±15
5
12
15
24
Output
Current (mA)
Max
±600
±250
±200
1200
500
400
250
±600
±250
±200
1500
1200
500
400
250
±600
±250
±200
1500
1200
500
400
250
±600
±250
±200
1200
500
400
250
Min
±60
±25
±20
120
50
40
25
±60
±25
±20
150
120
50
40
25
±60
±25
±20
150
120
50
40
25
±60
±25
±20
120
50
40
25
76
80
82
76
80
82
83
78
82
84
77
78
82
84
83
80
84
86
79
80
84
86
85
80
84
86
80
84
86
85
Efficiency
(%, Typ)
APPLICATIONS
The WRA_ZP-6W & WRB_ZP-6W Series are
specially designed for applications where a wide
range input voltage power supplies are isolated
from the input power supply in a distributed
power supply system on a circuit board.
These products apply to:
1) Where the voltage of the input power supply is
wide range (voltage range≤2:1);
2) Where isolation is necessary between input
and output(Isolation Voltage≤1500VDC);
3) Where the regulation of the output voltage and
the output ripple noise are demanded.
MODEL SELECTION
WRB2405ZP-6W
Rated Power
Package Style
Output Voltage
Input Voltage
Product Series
WRB4815ZP-6W
WRB4824ZP-6W
* Input voltage can’t exceed this value, or will cause the permanent damage.
Note: The load shouldn't be less than 10%, otherwise ripple will increase dramatically.
Operation under 10% load will not damage the converter; However, they may not meet all specification listed.
OUTPUT SPECIFICATIONS
Item
Output Power
Positive Voltage Accuracy
Negative Voltage Accuracy
Test Conditions
See below products program
Refer to recommended circuit
Refer to recommended circuit
From 10% To 100% load
Refer to recommended circuit
20MHz bandwidth
20MHz bandwidth
100% load, nominal Input voltage
Min
0.6
±1
±3
±0.5
±0.2
0.02
20
50
300
50
100
Typ
Max
6
±3
±5
±1*
±0.5
%/°C
mVp-p
KHz
%
Units
W
MORNSUN Science & Technology co.,Ltd.
Address: 2th floor 6th building, Huangzhou
Industrial District, Guangzhou, China
Tel: 86-20-38601850
Fax: 86-20-38601272
Http://www.mornsun-power.com
Load Regulation
Temperature Drift(Vout)
Ripple**
Noise**
Switching Frequency
Line Regulation(at full load) Input voltage from low to high
*Dual output models unbalanced load:
±5%.
**Test ripple and noise by
“parallel
cable” method. See detailed operation instructions at Testing of Power
Converter section, application notes.
MORNSUN reserves the copyright
Specifications subject to change without notice.
WRA_ZP-6W & WRB_ZP-6W
A/2-2008
Page 1 of 2
COMMON SPECIFICATION
Item
Storage humidity
Operating temperature
Storage temperature
Temp. rise at full load
Lead temperature
Cooling
Short circuit protection
Case material
Isolation voltage
Isolation resistance
No-load power consumption
MTBF
Weight
1000
17
Test at 500VDC
1.5mm from case for 10 seconds
-40
-55
40
300
Free air convection
Continuous, automatic recovery
Copper, Nickel Plated
Tested for 1 minute and 1 mA max 1500
1000
500
VDC
MΩ
mW
K hours
g
Test Conditions
Min
Typ
Max
95
85
125
°C
Units
%
Recommended Circuit
All the WRA_ZP-6W&WRB_ZP-6W
recommended testing circuit
Series
have been tested according to the following
before leaving
factory. This series should be tested under load.
Never be tested under no load (see Figure 1).
Dual Output
Vin
Ci n
+Vout
DC
DC
0V
-Vout
GND
Single Output
Vin
C in
+Vout
DC
DC
0V
GND
Note:
1.All specifications measured at T
A
=25°C, humidity<75%, nominal input voltage and rated output load unless
otherwise specified.
2.See below recommended circuits for more details.
(Figure 1)
If you want to further decrease the input/output
ripple, you can increase capacitance properly or
choose capacitors with low ESR. However, the
capacitance of the output filter capacitor must be
proper. If the capacitance is too big, a startup
problem might arise. For every channel of output,
provided the safe and reliable operation is
ensured, the greatest capacitance of its filter
capacitor sees (Table 1). General:
Cin:
5V&12V
100μF
24V&48V 10μF-47μF
Cout:10μF/100mA
TYPICAL CHARECTERISTICS
Temperature Derating Graph
Safe Operating Area
Operating T
emp.(
C
)
OUTLINE DIMENSIONS & PIN CONNECTIONS
First Angle Projection
RECOMMENDED FOOTPRINT
Top
view,grid:2.54mm(0.1inch)
diameter:1.00mm(0.039inch)
Dual Output
20.00(0.787)
23
9
(Bottom View)
32.00(1.260)
15.24(0.600)
Output External Capacitor Table(Table 1)
Single Vout
Cout
Dual Vout
Cout
(VDC)
(uF)
(VDC)
(uF)
3.3
2200
±5
680
5
1000
±9
470
9
680
±12
330
12
470
±15
220
15
330
24
220
Input Current
When it is used in unregulated power supply,
be sure that the fluctuating range of the power
supply and the rippled voltage do not exceed the
module standard. Input current of power supply
11
23 22
16 14
23 22
16 14
2 3
Single Output
23 22
9
11
15.24(0.600)
22.86(0.900)
16 14
should afford the startup current of this kind of
DC/DC module (See figure 2), General:
Ip
≤1.4*Iin-max
Input Current(A)
(0.394)
10.00
(Side Vie w)
2 3
11
Note:
Unit:mm(inch)
Pin diameter:0.50mm(0.020inch)
Pin diameter tolerances: 0.05mm( 0.002inch)
General tolerances: 0.25mm( 0.010inch)
FOOTPRINT DETAILS
Pin
Single
Dual
2
、
3
GND
GND
No Pin
0V
9
11
-Vo
NC
14
+Vo
+Vo
16
0V
0V
22
、
23
Vin
Vin
NC:No Connection
0.50
(0.020)
Ip
Input Voltage
Range
Input Voltage (V)
APPLICATION NOTE
Requirement On Output Load
In order to ensure the product operate efficiently and reliably, in addition to a max load
(namely full load), a minimum load is specified for this kind of DC/DC converter. Make sure the
specified range of input voltage is not exceeded, the minimum output load
no less than 10%
load.
If the actual load is less than the specified minimum load, the output ripple may increase
sharply while its efficiency and reliability will reduce greatly. If the actual output power is very
small, please add an appropriate resistor as extra loading, or contact our company for other
lower output power products.
MORNSUN reserves the copyright
Specifications subject to change without notice.
No parallel connection or plug and play.
WRA_ZP-6W & WRB_ZP-6W
A/2-2008
Page 2 of 2
