MIL-55310/17-Series Specifications
0.887L x 0.540W x 0.200H (in)
PDI
MIL-PRF-55310/17
Oscillators are available in both standard and custom
frequencies to provide precision timing in a hermetically sealed package for
military and avionics applications.
ex)
M55310/17—B—11—A—12M00000
MILITARY SLASH SHEET
PRODUCT LEVEL
B
= Hi-Rel
C
= Commercial
DASH NUMBER
See Chart Below
OPERATING TEMPERATURE
A
= -55°C to +125°C
B
= -55°C to +105°C
C
= -20°C to +70°C
XXXXXXXX
Specified
Nominal
Frequency
Dash
No.
11
14
21
24
Frequency
Range
12 MHz to
20 MHz
20 MHz to
50 MHz
Rise/Fall
Times
5.25 V ±1%
Max
55 mA
55 mA
Max
15 nS
5 nS
Input
Current
(1)
Duty
Cycle
@ 1.4 Vdc
40 to 60%
40 to 60%
Load
(2)
Max
10 TTL
10 TTL
Initial
Accuracy
@ 23°C
ppm Max
±15
±25
±15
±25
Operating Temperature
Aging
Per Year
ppm Max
±5
±10
±5
±10
(A)
±50
±100
±50
±100
(B)
±40
±40
±40
±40
(C)
±25
±25
±25
±25
Aging Per Year (Max)
Per 30 Days
Per 90 Days
(Measurements shall be taken @+70°C ±0.2°C at intervals of not
more than every 72 hours for 30 days minimum)
±5 ppm
±0.7 ppm
±1.5 ppm
±10 ppm
±1.5 ppm
±3.0 ppm
NOTES:
(1)
Maximum input current for no load condition. Actual configuration of TTL loads must be added to determine power supply requirements.
(2)
A TTL unit load is defined as: 1.60 mA sink, 0.04 mA source, and 2.0 pF capacitance.
Environmental Specifications
Terminal Strength
Vibration, sinusoidal
Ambient Pressure
MIL-STD-202 , Method 211 , Condition C
Applied Force:
2 pounds each terminal for 10 seconds ,
Bends:
5 at 45 degrees each
IAW MIL-PRF-55310 and MIL-STD-202 , Method 204
Non-operating:
Test Condition D,
Operating:
Not Required
Non-operating:
IAW MIL-PRF-55310 ,
Operating:
MIL-STD-202 , Method 105 , Condition C
The product described in this spec. consist of this specification and MIL-PRF-55310.
Decimal
XXX = ± .005, XX = ± .020
Metric
[XXX = ± .13], [XX = ± .50]
REV:
NA
SIZE:
A
CAGE:
A
1
of
3
MIL-55310/17-Series
0.887 x 0.540 x 0.200
(in)
Parameter
vs Temperature (Max)
-20 to +70°C (Type C)
-55 to +105°C (Type B)
-55 to +125°C (Type A)
Frequency Stability
Frequency Range
12MHz to 50MHz
Per Chart
Per Chart
Per Chart
Units
(Measurements taken at reference
temperature and operating temperature
range end points)
Tolerance (@ +23°C ± 1.0°C) (Max)
Within 30 Days of Shipment
vs Supply Voltage (Max. for a 10% change)
ppm
±2.0
Per Chart
Per Chart
-62 to +125
+5.0
TTL
2.4
0.5
80 Min
20 Max
°C
Vdc
Vdc
%Vcc
%Vcc
Temperature Range
Supply Voltage
Output
Logic Levels
Enable Gate Function
Disable Gate Function
Operating
Storage
±10.0 %
High (Min)
Low (Max)
Pin 9 Logic ‘1’ Output Enable
Pin 9 Logic ‘0’ Output Disable
Test Inspection
Internal Visual
Stabization bake (prior to seal) 1/
Temperature Cycling
Constant Acceleration
Seal (Fine and Gross Leak) 2/
Burn-In (Load)
Electrical Test:
Input Current Power
Output Waveform
Output Voltage-Power
As Specified
Product Level B
Method Condition
MIL-STD-883, Method 2017 and 2032
MIL-STD-883, Method 1011,
Condition C (+150°C) 48 hours min.
MIL-STD-883, Method 1010
Condition B
MIL-STD-883, Method 2001.
Condition A, Y1 only (5000 g’s)
MIL-STD-883, Method 1014
+125C, nominal supply voltage and
burn-in load, 160 hours minimum
Nominal supply voltages, specified
load, +23°C and verify frequency
at the temperature extremes
4.8.5 of MIL-PRF-55310
4.8.20 of MIL-PRF-55310
4.8.21 of MIL-PRF-55310
3.1 of MIL-PRF-55310
REV:
NA
SIZE:
A
CAGE:
A
2
of
3
MIL-55310/17-Series
0.887 x 0.540 x 0.200
(in)
PA C K A G E D I M E N S I O N S
PIN
1-6
7
8
9
10-13
14
CONNECTION
No Connect
Ground/Case
Output
Gate Input
No Connect
Supply Voltage
J M55310/17-X
XXB XXXXXXXX
0S4G1 YYWW
S/N XXXXX
Pin 1 ID
Date Code
.200 Max.
[5.08 Max.]
.200 Min.
[5.08 Min.]
.100 Typ.
Non-Accumulative
[2.54 Typ.]
.887 Max.
[22.53 Max.]
.440 Max.
[11.17 Max.]
.270 Max.
[6.86 Max.]
.540 Max.
[13.71 Max.]
.300 ±.005
[7.62 ±.13]
.600 ±.005
[15.24 ±.13]
.150 ±.005
[3.81 ±.13]
.300 ±.005
[7.62 ±.13]
Ø.018 ±.002
[Ø.43 ±.05]
REV:
NA
SIZE:
A
CAGE:
A
3
of
3
