EHV
SERIES
SMD TYPE Reflow Soldering is available
Life 2000 hours at 105℃
Available For High Density Mounting
Characteristics
Category Temperature Range
Capacitance Tolerance
Leakage Current
Dissipation Factor
( tanδ)Max
(at 20
℃
, 120Hz)
6.3 ~ 100V
-55
℃
~ +105
℃
160 ~ 450V
-40
℃
~ +105℃
+20% -20% (at 20
℃
, 120Hz)
SIZE A~F: I≤0.01CV or 3uA, whichever is greater 2 minutes after Rated Voltage applied
SIZE G~J(6.3V~100V): I≤0.03CV whichever is greater 2 minutes after Rated Voltage applied
SIZE G~J (160V~450V): I≤0.04CV +100uA whichever is greater 5 minutes after rated voltage applied
160~
400~
Voltage (V)
6.3
10
16
25
35
50
63
100
250
450
SIZE A~F
0.45
0.35
0.28
0.18
0.16
0.14
0.12
0.12
-
-
SIZE G~J
0.45
0.38
6.3
0.34
10
0.26
16
0.22
25
0.18
35
0.14
50
0.10
63
0.20
100
160~
250
-
3
0.25
400~
450
-
6
Stability at Low Temperature
(
at 120Hz)
Voltage (V)
Load Life
Shelf Life
Z -25
℃
SIZE A~F
4
4
3
2
2
2
2
3
/Z +20
℃
SIZE G~J
5
4
3
2
2
2
2
2
SIZE A~F
12
8
6
4
3
3
3
4
Z-40
℃
/Z 20℃
SIZE G~J
10
8
6
4
3
3
3
3
6
10
After the rated voltage
Capacitance change Within
±25%
of initial value(SIZE G~I:
±20%)
has been applied for 2000 D.F. tanδ
Less than
±300%
of specified value(SIZE D~I:
±200%)
hours at 105
℃
Leakage current
Less than Initial specified value
After storage for 1000 hours at 105
℃
, with no voltage applied and being stabilized at +20
℃
, Capacitor
shall meet the limit specified in load life.(Refer to JIS C5101-4 4.1)
Diagram of dimensions
SIZE Dφ
4
A
5
B
6.3
C
6.3
C8
8
D
8
E
10
F
12.5
G
12.5
H
16
I
18
J
L
5.5
5.5
5.7
7.7
6.5
10.5
10.5
13.5
16.0
16.5
16.5
A
4.3
5.3
6.6
6.6
8.4
8.34
10.4
13.0
13.0
17.0
19.0
C
5.1
6.1
7.4
7.4
9.2
9.2
11.2
15.0
15.0
19.0
21.0
B
4.3
5.3
6.6
6.6
8.4
8.34
10.4
13.0
13.0
17.0
19.0
W
P±0.2
0.5~0.8 1.0
0.5~0.8 1.5
0.5~0.8 2.0
0.5~0.8 2.0
0.7~1.1 2.2
0.7~1.1 3.1
0.7~1.1 4.7
1.1~1.4 4.4
1.1~1.4 4.4
1.1~1.4 6.4
1.1~1.4 6.4
Size A~F refer to Fig. 1
Size G~J refer to Fig. 2
Part Numbering System
EHV
Series
□□□
Capacitance
□
Tolerance
□□
Rated Voltage
R
Package
□
Case Size
9
