2417SJ-08-PHD datasheet, PDF - EEWORLD Datasheet

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > The connector> The connector> 2417SJ-08-PHD

Preview

2417SJ-08-PHD: DescriptionBoard Connector, 8 Contact(s), 2 Row(s), Male, Straight, Solder Terminal,; CategoryThe connector The connector; File Size117KB，1 Pages; ManufacturerNeltron Industrial Company Ltd; Environmental Compliance

Download Datasheet Parametric View All

2417SJ-08-PHD Overview

Board Connector, 8 Contact(s), 2 Row(s), Male, Straight, Solder Terminal,

2417SJ-08-PHD Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Objectid	8351926433
Reach Compliance Code	compliant
ECCN code	EAR99
body width	0.197 inch
subject depth	0.256 inch
body length	0.394 inch
Connector type	BOARD CONNECTOR
Contactor design	PREASSEM CONN
Contact point gender	MALE
contact mode	RECTANGULAR
Contact resistance	20 mΩ
Contact style	SQ PIN-SKT
DIN compliance	NO
Dielectric withstand voltage	500VAC V
Filter function	NO
IEC compliance	NO
Insulation resistance	1000000000 Ω
insulator material	NYLON66
MIL compliance	NO
Plug contact pitch	0.079 inch
Match contact row spacing	0.079 inch
Mixed contacts	NO
Installation option 1	LOCKING
Installation method	STRAIGHT
Installation type	BOARD
Number of connectors	ONE
PCB row number	2
Number of rows loaded	2
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Options	GENERAL PURPOSE
PCB contact pattern	RECTANGULAR
PCB contact row spacing	2 mm
Rated current (signal)	2 A
Guideline	UL,CSA,TUV
Terminal length	0.122 inch
Terminal pitch	2 mm
Termination type	SOLDER
Total number of contacts	8
UL Flammability Code	94V-0

2417SJ-08-PHD Preview

Neltron

Connectors

RoHS Compliant

2417 & 2418 Series

2.0mm Wire to Board

Connectors

TUV

SUD

TUV

SUD

TUV

SUD

Specifications

Current rating:2.0A AC/DC

Voltage rating:125V AC/DC

Contact resistance:20m ohm. max.

Insulation resistance:1000M ohm. Min.

Withstanding voltage:500V AC for one minute

Operating temperature range:-40

℃

to +85

℃

Application: Wire Awg 24 to 28

X-

PH

D

24

18

HJ

-X

17

SJ

-X

Material and Finish

A. Housing Insulator: Nylon 66(UL94V-0)

B. Crimp Terminal: Phosphor Bronze Tin Plated

C. Wafer Insulator: Nylon 66(UL94V-0)

Contact Pin: Copper Alloy Tin Plated

X-

PH

D

24

17

RJ

-X

X-

PH

D

Connection

2418HJ-XX-PHD Mates With 2417SJ(RJ)-XX-PHD

6.50

9.50±0.25

9.50

2.0

2.0±0.05

Dim A

Dim B

5.0

3.1

2.0±0.25

P/N:2417RJ-XX-PHD

3.1

6.5

A

5.0

4.2

2.0

5.0

B

1.35

Sections:A-A

A

B

1.50±0.25

2.0

1.6±0.25

6.7±0.25

0.7±0.20

1.04±0.3

0.16

0.4±0.10

Sections:B-B

3.40±0.10

7.3

P/N:2417SJ-XX-PHD

P/N:2418HJ-XX-PHD

P/N:2418 T J-PHD

P/N:2417SJ(RJ)-XX-PHD

Circuits Dim. A Dim. B

4.00

8.00

6

6.00

10.00

8

8.00

12.00

10

10.00

14.00

12

12.00

16.00

14

14.00

18.00

16

16.00

20.00

18

Circuits

20

22

24

26

28

30

32

Dim. A

18.00

20.00

22.00

24.00

26.00

28.00

30.00

Dim. B

22.00

24.00

26.00

28.00

30.00

32.00

34.00

P/N:2418HJ-XX-PHD

Circuits Dim. A Dim. B

4.00

8.00

6

6.00

10.00

8

8.00

12.00

10

10.00

14.00

12

12.00

16.00

14

14.00

18.00

16

16.00

20.00

18

Dim A

Circuits

20

22

24

26

28

30

32

Dim. A

18.00

20.00

22.00

24.00

26.00

28.00

30.00

Dim. B

22.00

24.00

26.00

28.00

30.00

32.00

34.00

P/N:2417SJ (RJ) -XX-PHD

2417 SJ - XX - PHD

SJ:Straight Type

RJ:Right Angle Type

No. Of Contacts

2418 HJ - XX - PHD

No. Of Contacts

2017-2026

2.50±0.25

2.0

2.0±0.05

Dim A

Dim B

More (Only the first 5 pages are displayed. Please Download Datasheet to view the full content.) >
