SH320240C ( 320 DOTS X 240 DOTS )
■
FEATURES
◆
BUILT-IN CONTROLLER (SED1335 OR EQUIVALENT)
◆
+5 V POWER SUPPLY
◆
1/240 DUTY CYCLE
◆
EDGE LIGHTING TYPE CCFL BACKLIGHT
■
MECHANICAL DATA
ITEM
Module Size (W x H x T)
Viewing Area ( W x H )
Active Area ( W x H )
Dot Size ( W x H )
Dot Pitch ( W x H )
DIMENSIONS
148.0 x 120.2 x 20.5
120.14 x 92.14
115.17 x 86.37
0.33 x 0.33
0.36 x 0.36
UNIT
mm
mm
mm
mm
mm
■
INTERFACE PIN CONNECTIONS
NO.
1
2
3
4
5
6
7~14
15
16
17
18
19
20
■
ABSOLUTE MAXIMUM RATINGS
ITEM
Supply Voltage For Logic
Supply Voltage For LCD Drive
Input Voltage
SYMBOL LEVEL
V
SS
V
DD
V
O
/RD
/WR
A
o
DB0~DB7
/CS
/RES
Vout
FG
NC
NC
0V
5V
FUNCTION
Power Supply Ground
Power Supply Voltage
Contrast Adjustment Voltage
Read Signal
Write Signal
Data Type Select
Data Bus Line
Chip Signal
Reset Signal
Power Supply Voltage For LCD
For GND
No Connection
No Connection
SYMBOL
V
DD
-V
SS
V
DD
-V
o
V
I
MIN.
0
0
Vss
TYP.
-
-
-
MAX.
7
30
V
DD
UNIT
V
V
V
-
L
L
H/L
H/L
L
H/L
■
ELECTRICAL CHARACTERISTICS
ITEM
Supply Voltage For Logic
LCD Supply Voltage
Supply Current
Input
Voltage
Output
Voltage
"HIGH" Level
"LOW" Level
"HIGH" Level
"LOW" Level
SYMBOL
V
DD
-V
SS
V
DD
-V
o
I
DD
V
IH
V
IL
V
OH
V
OL
CONDITION
-
V
DD
=5V Ta=25℃
V
DD
=5V
MIN.
4.5
22.4
-
2.2
-
2.4
-
TYP.
5
23.5
16
-
-
-
-
MAX. UNIT
5.5
24.3
25
VDD
0.6
-
0.4
V
V
mA
V
V
V
V
-
-
-
-
-
-
-
-
■
EXTERNAL DIMENSIONS
