BT131W-600

Description
Triacs logic level
CategoryAnalog mixed-signal IC    Trigger device
File Size40KB,7 Pages
ManufacturerPhilips Semiconductors (NXP Semiconductors N.V.)
Websitehttps://www.nxp.com/
Environmental Compliance
Download Datasheet Parametric Compare View All

BT131W-600 Overview

Triacs logic level

BT131W-600 Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
MakerPhilips Semiconductors (NXP Semiconductors N.V.)
package instruction,
Reach Compliance Codeunknow
Maximum DC gate trigger current7 mA
Maximum holding current5 mA
JESD-609 codee3
Maximum leakage current0.5 mA
Maximum on-state voltage1.5 V
Maximum operating temperature125 °C
Minimum operating temperature-40 °C
Maximum rms on-state current1 A
Off-state repetitive peak voltage600 V
surface mountYES
Terminal surfaceMatte Tin (Sn)
Trigger device typeTRIAC
Philips Semiconductors
Product specification
Triacs
logic level
GENERAL DESCRIPTION
Glass passivated, sensitive gate triacs
in a plastic envelope suitable for
surface mounting, intended for use in
general
purpose
bidirectional
switching
and
phase
control
applications. These devices are
intended to be interfaced directly to
microcontrollers, logic integrated
circuits and other low power gate
trigger circuits.
BT131W series
QUICK REFERENCE DATA
SYMBOL
V
DRM
I
T(RMS)
I
TSM
PARAMETER
BT131W-
Repetitive peak off-state voltages
RMS on-state current
Non-repetitive peak on-state current
MAX. MAX. UNIT
500
500
1
10
600
600
1
10
V
A
A
PINNING - SOT223
PIN
1
2
3
tab
DESCRIPTION
main terminal 1
PIN CONFIGURATION
4
SYMBOL
T2
main terminal 2
gate
main terminal 2
1
2
3
T1
G
LIMITING VALUES
Limiting values in accordance with the Absolute Maximum System (IEC 134).
SYMBOL
V
DRM
I
T(RMS)
I
TSM
PARAMETER
Repetitive peak off-state
voltages
RMS on-state current
Non-repetitive peak
on-state current
I
2
t for fusing
Repetitive rate of rise of
on-state current after
triggering
full sine wave; T
sp
108 ˚C
full sine wave; T
j
= 25 ˚C prior to
surge
t = 20 ms
t = 16.7 ms
t = 10 ms
I
TM
= 1.5 A; I
G
= 0.2 A;
dI
G
/dt = 0.2 A/µs
T2+ G+
T2+ G-
T2- G-
T2- G+
CONDITIONS
MIN.
-
-
-
-
-
-
-
-
-
-
-
-
-
-40
-
-500
500
1
1
10
11
0.5
50
50
50
10
2
5
5
0.5
150
125
MAX.
-600
600
1
UNIT
V
A
A
A
A
2
s
A/µs
A/µs
A/µs
A/µs
A
V
W
W
˚C
˚C
I
2
t
dI
T
/dt
I
GM
V
GM
P
GM
P
G(AV)
T
stg
T
j
Peak gate current
Peak gate voltage
Peak gate power
Average gate power
Storage temperature
Operating junction
temperature
over any 20 ms period
1
Although not recommended, off-state voltages up to 800V may be applied without damage, but the triac may
switch to the on-state. The rate of rise of current should not exceed 3 A/µs.
July 1998
1
Rev 1.000

BT131W-600 Related Products

BT131W-600 BT131W-500 BT131W
Description Triacs logic level Triacs logic level Triacs logic level
Is it Rohs certified? conform to incompatible -
Maker Philips Semiconductors (NXP Semiconductors N.V.) Philips Semiconductors (NXP Semiconductors N.V.) -
Reach Compliance Code unknow unknow -
Maximum DC gate trigger current 7 mA 7 mA -
Maximum holding current 5 mA 5 mA -
JESD-609 code e3 e0 -
Maximum leakage current 0.5 mA 0.5 mA -
Maximum on-state voltage 1.5 V 1.5 V -
Maximum operating temperature 125 °C 125 °C -
Minimum operating temperature -40 °C -40 °C -
Maximum rms on-state current 1 A 1 A -
Off-state repetitive peak voltage 600 V 500 V -
surface mount YES YES -
Terminal surface Matte Tin (Sn) Tin/Lead (Sn/Pb) -
Trigger device type TRIAC TRIAC -
