UNISONIC TECHNOLOGIES CO., LTD
LR1116/B
LOW DROP POSITIVE
VOLTAGE REGULATORS
DESCRIPTION
LINEAR INTEGRATED CIRCUIT
The UTC
LR1116/B
is a low drop voltage regulator able to provide
up to 0.8/0.5A of output current. Output consists of PNP power
transistor. So that dropout voltage can be extremely low.
FEATURES
* 2.85V Device are Suitable for SCSI-2 Active Termination
* Output Current up to 0.8/0.5A
* Internal Current and Thermal Limit
ORDERING INFORMATION
Ordering Number
Lead Free
-
-
LR1116
L-xx-TA3-
-
LR1116
L-xx-TN3-
-
LR1116
L-xx-TQ2-
-
Halogen Free
LR1116
G-xx-AA3-
-
LR1116
G-xx-AB3-
-
LR1116
G-xx-TA3-
-
LR1116
G-xx-TN3-
-
LR1116
G-xx-TQ2-
-
Package
SOT-223
SOT-89
TO-220
TO-252
TO-263
SOP-8
Pin Assignment
Pin Code
A
B
C
D
1
G
O
G
I
2 3
O I
G I
I O
G O
Packing
T: Tube
R: Tape Reel
LR1116
G-xx-S08-R
-
B: 0.5A
Notes: 1.
: Current code: Blank: 0.8A
2. Pin Assignment: I: V
IN
O: V
OUT
G: GND x: NC
3. xx: Output Voltage, Refer to Marking Information.
LR1116 1 G-xx-AA3- 2 - 3
(1) Packing Type
(2) Pin Assignment
(3) Package Type
(4) Output Voltage Code
(5) Green Package
(6) Current Code
GOOIxOOx
(1) T: Tube, R: Tape Reel
(2) Refer to Pin Assignment
(3) AA3: SOT-223, AB3: SOT-89, TA3: TO-220
TN3: TO-252, TQ2: TO-263, S08: SOP-8
(4) xx: Refer to Marking Information
(5) G: Halogen Free and Lead Free, L: Lead Free
(6) Blank: 0.8A, B: 0.5A
www.unisonic.com.tw
Copyright © 2015 Unisonic Technologies Co., Ltd
1 of 9
QW-R102-022.S
LR1116/B
ABSOLUTE MAXIMUM RATINGS
PARAMETER
LINEAR INTEGRATED CIRCUIT
SYMBOL
RATINGS
UNIT
DC Input Voltage
V
IN
15
V
Operating Junction Temperature
T
OPR
-40 ~ +85
°C
Storage Temperature
T
STG
-40 ~ +150
°C
Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.
Absolute maximum ratings are stress ratings only and functional device operation is not implied.
THERMAL DATA
SYMBOL
θ
JC
RATINGS
15
20
8
4
UNIT
°C/W
°C/W
°C/W
°C/W
PARAMETER
SOT-223/SOT-89
SOP-8
Junction to Case
TO-252
TO-220/TO-263
ELECTRICAL CHARACTERISTICS
(T
A
=25°C, refer to the test circuits, T
J
=-0 ~ 125°C, C
O
=10μF, unless otherwise specified).
For LR1116/B-1.2V
PARAMETER
SYMBOL
TEST CONDITIONS
Output Voltage
V
OUT
V
IN
=V
OUT
+1.5V, I
OUT
=10mA, T
J
=25°C
V
IN
=(V
OUT
+2V)~15V
LR1116 : I
OUT
=0 to 800mA
Output Voltage
V
OUT
LR1116B : I
OUT
=0 to 500mA
Line Regulation
V
OUT
V
IN
=(V
OUT
+2V)~15V, I
OUT
=0mA
V
IN
=V
OUT
+2V
LR1116 : I
OUT
=0 to 800mA
Load Regulation
V
OUT
LR1116B : I
OUT
=0 to 500mA
Temperature Stability
V
OUT
Long Term Stability
V
OUT
1000 hrs, T
J
=125C
Operating Input Voltage
V
IN
I
OUT
=100mA
Quiescent Current
I
D
V
IN
10V
LR1116
Output Current
I
OUT
V
IN
=V
OUT
+4.5V, T
J
=25°C
LR1116B
Output Noise Voltage
e
N
B=10Hz~10KHz, T
J
=25°C
I
OUT
=40mA, f=120Hz, T
J
=25°C
Supply Voltage Rejection
SVR
V
IN
=V
OUT
+2.5V, V
RIPPLE
=1V
PP
I
OUT
= 100mA
Dropout Voltage
V
D
I
OUT
= 500mA
I
OUT
= 800mA(only for LR1116)
Thermal Regulation
T
A
=25°C, 30ms Pulse
MIN. TYP. MAX. UNIT
1.176 1.2 1.224 V
1.176
1.2
0.1
2
0.5
0.3
5
950
650
100
75
0.9
1.1
1.2
0.01
1.0
1.3
1.4
0.10
15
10
1.224
0.6
3
V
%
%
%
%
V
mA
mA
mA
μV
dB
V
V
V
%/W
800
500
60
UNISONIC TECHNOLOGIES CO., LTD
www.unisonic.com.tw
4 of 9
QW-R102-022.S
LR1116/B
ELECTRICAL CHARACTERISTICS (Cont.)
SYMBOL
V
OUT
V
OUT
V
OUT
V
OUT
V
OUT
V
OUT
V
IN
I
D
I
OUT
e
N
SVR
V
D
For LR1116/B-1.5V
PARAMETER
Output Voltage
Output Voltage
Line Regulation
Load Regulation
Temperature Stability
Long Term Stability
Operating Input Voltage
Quiescent Current
Output Current
Output Noise Voltage
Supply Voltage Rejection
Dropout Voltage
Thermal Regulation
For LR1116/B-1.8V
PARAMETER
Output Voltage
Output Voltage
Line Regulation
Load Regulation
Temperature Stability
Long Term Stability
Operating Input Voltage
Quiescent Current
Output Current
Output Noise Voltage
Supply Voltage Rejection
Dropout Voltage
Thermal Regulation
SYMBOL
V
OUT
V
OUT
V
OUT
V
OUT
V
OUT
V
OUT
V
IN
I
D
I
OUT
e
N
SVR
V
D
LINEAR INTEGRATED CIRCUIT
TEST CONDITIONS
V
IN
=V
OUT
+1.5V, I
OUT
=10mA, T
J
=25°C
V
IN
=(V
OUT
+2V)~15V
LR1116 : I
OUT
=0 to 800mA
LR1116B : I
OUT
=0 to 500mA
V
IN
=(V
OUT
+2V)~15V, I
OUT
=0mA
V
IN
=V
OUT
+2V
LR1116 : I
OUT
=0 to 800mA
LR1116B : I
OUT
=0 to 500mA
1000 hrs, T
J
=125°C
I
OUT
=100mA
V
IN
10V
V
IN
=V
OUT
+4.5V, T
J
=25°C
LR1116
LR1116B
MIN. TYP. MAX. UNIT
1.470 1.5 1.530 V
1.470
1.5
0.1
2
0.5
0.3
5
950
650
100
75
0.6
0.80
0.95
0.01
0.75
0.95
1.1
0.10
15
10
1.530
0.6
3
V
%
%
%
%
V
mA
mA
mA
μV
dB
V
V
V
%/W
800
500
60
B=10Hz~10KHz, T
J
=25°C
I
OUT
=40mA, f=120Hz, T
J
=25°C
V
IN
=V
OUT
+2.5V, V
RIPPLE
=1V
PP
I
OUT
= 100mA
I
OUT
= 500mA
I
OUT
= 800mA(only for LR1116)
T
A
=25°C, 30ms Pulse
TEST CONDITIONS
V
IN
=V
OUT
+1.5V, I
OUT
=10mA, T
J
=25°C
V
IN
=(V
OUT
+2V)~15V
LR1116 : I
OUT
=0 to 800mA
LR1116B : I
OUT
=0 to 500mA
V
IN
=(V
OUT
+2V)~15V, I
OUT
=0mA
V
IN
=V
OUT
+2V
LR1116 : I
OUT
=0 to 800mA
LR1116B : I
OUT
=0 to 500mA
1000 hrs, T
J
=125°C
I
OUT
=100mA
V
IN
10V
V
IN
=V
OUT
+4.5V, T
J
=25°C
LR1116
LR1116B
MIN. TYP. MAX. UNIT
1.764 1.8 1.836 V
1.764
1.8
0.1
2
0.5
0.3
5
950
650
100
75
0.4
0.6
0.8
0.01
0.5
0.8
0.95
0.10
15
10
1.836
0.6
3
V
%
%
%
%
V
mA
mA
mA
μV
dB
V
V
V
%/W
800
500
60
B=10Hz~10KHz, T
J
=25°C
I
OUT
=40mA, f=120Hz, T
J
=25°C
V
IN
=V
OUT
+2.5V, V
RIPPLE
=1V
PP
I
OUT
= 100mA
I
OUT
= 500mA
I
OUT
= 800mA(only for LR1116)
T
A
=25°C, 30ms Pulse
UNISONIC TECHNOLOGIES CO., LTD
www.unisonic.com.tw
5 of 9
QW-R102-022.S
