WTE
POWER SEMICONDUCTORS
BZT52-C2V4S – BZT52-C39S
200mW SURFACE MOUNT ZENER DIODE
Features
!
!
!
!
!
!
Planar Die Construction
A
SOD-323
Dim
Min
2.30
1.75
1.15
0.25
0.05
0.70
0.30
Max
2.70
1.95
1.35
0.35
0.15
0.95
—
A
B
C
D
200mW Power Dissipation
2.4 – 39V Nominal Zener Voltage
5% Standard Vz Tolerance
Designed for Surface Mount Application
C
Plastic Material – UL Recognition Flammability
Classification 94V-O
E
D
B
G
Mechanical Data
!
!
!
!
!
Case: SOD-323, Molded Plastic
Terminals: Plated Leads Solderable per
MIL-STD-202, Method 208
Polarity: Cathode Band
Weight: 0.004 grams (approx.)
Marking: Device Code (See Table Next Page)
@T
A
=25°C unless otherwise specified
E
G
H
All Dimensions in mm
H
Maximum Ratings
Characteristic
Peak Pulse Power Dissipation at T
A
= 25°C (Note 1)
Forward Voltage @ I
F
= 10mA
Thermal Resistance Junction to Ambient (Note 1)
Operating and Storage Temperature Range
Note: 1. Valid provided that device terminals are kept at ambient temperature.
Symbol
P
d
V
F
R
JA
T
j
, T
STG
Value
200
0.9
625
-65 to +150
Unit
mW
V
°C/W
°C
BZT52-C2V4S – BZT52-C39S
1 of 4
© 2002 Won-Top Electronics
Electrical Characteristics
@T
A
=25°C unless otherwise specified
Type
Number
(Note 1)
Device
Marking
Code
Zener Voltage Range
(Note 2)
V
Z
@ I
ZT
Nom (V)
Min (V)
2.28
2.5
2.8
3.1
3.4
3.7
4.0
4.4
4.8
5.2
5.8
6.4
7.0
7.7
8.5
9.4
10.4
11.4
12.4
13.8
15.3
16.8
18.8
20.8
22.8
25.1
28
31
34
37
Max (V)
2.56
2.9
3.2
3.5
3.8
4.1
4.6
5.0
5.4
6.0
6.6
7.2
7.9
8.7
9.6
10.6
11.6
12.7
14.1
15.6
17.1
19.1
21.2
23.3
25.6
28.9
32
35
38
41
Maximum Zener Impedance
(Note 3)
Z
ZT
@ I
ZT
()
100
100
95
95
90
90
90
80
60
40
10
15
15
15
15
20
20
25
30
30
40
45
55
55
70
80
80
80
90
130
(mA)
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
2.0
2.0
2.0
2.0
2.0
Z
ZK
@ I
ZK
()
600
600
600
600
600
600
600
500
480
400
150
80
80
80
100
150
150
150
170
200
200
225
225
250
250
300
300
325
350
350
(mA)
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
0.5
0.5
0.5
0.5
0.5
Max Reverse
Leakage Current
I
R
(µA)
50
20
10
5.0
5.0
3.0
3.0
3.0
2.0
1.0
3.0
2.0
1.0
0.7
0.5
0.2
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
@ V
R
(V)
1.0
1.0
1.0
1.0
1.0
1.0
1.0
2.0
2.0
2.0
4.0
4.0
5.0
5.0
6.0
7.0
8.0
8.0
8.0
10.5
11.2
12.6
14
15.4
16.8
18.9
21
23.1
25.2
27.3
Temp. Coeffi-
cient of Zener
Voltage @ I
ZT
mV / °C
Min
-3.5
-3.5
-3.5
-3.5
-3.5
-3.5
-3.5
-3.5
-2.7
-2.0
0.4
1.2
2.5
3.2
3.8
4.5
5.4
6.0
7.0
9.2
10.4
12.4
14.4
16.4
18.4
21.4
24.4
27.4
30.4
33.4
Max
0
0
0
0
0
0
0
0.2
1.2
2.5
3.7
4.5
5.3
6.2
7.0
8.0
9.0
10
11
13
14
16
18
20
22
25.3
29.4
33.4
37.4
41.2
BZT52-C2V4S
BZT52-C2V7S
BZT52-C3S
BZT52-C3V3S
BZT52-C3V6S
BZT52-C3V9S
BZT52-C4V3S
BZT52-C4V7S
BZT52-C5V1S
BZT52-C5V6S
BZT52-C6V2S
BZT52-C6V8S
BZT52-C7V5S
BZT52-C8V2S
BZT52-C9V1S
BZT52-C10S
BZT52-C11S
BZT52-C12S
BZT52-C13S
BZT52-C15S
BZT52-C16S
BZT52-C18S
BZT52-C20S
BZT52-C22S
BZT52-C24S
BZT52-C27S
BZT52-C30S
BZT52-C33S
BZT52-C36S
BZT52-C39S
W1
W2
W3
W4
W5
W6
W7
W8
W9
WA
WB
WC
WD
WE
WF
WG
WH
WI
WK
WL
WM
WN
WO
WP
WR
WS
WT
WU
WW
WX
2.4
2.7
3.0
3.3
3.6
3.9
4.3
4.7
5.1
5.6
6.2
6.8
7.5
8.2
9.1
10
11
12
13
15
16
18
20
22
24
27
30
33
36
39
Note: 1. Type numbers listed have standard tolerance on the nominal zener voltage of ±5%.
2. Measured with pulses t
p
= 5ms.
3. f = 1KHz
BZT52-C2V4S – BZT52-C39S
2 of 4
© 2002 Won-Top Electronics
500
See Note 1
50
T
j
= 25°C
C2V7
C3V9
C5V6
C6V8
C8V2
C3V3
P
d
, POWER DISSIPATION (mW)
I
Z
, ZENER CURRENT (mA)
400
40
C4V7
300
30
200
20
100
10
Test Current I
Z
5.0mA
0
0
100
200
0
0
1
3
4
5
6
8
9
7
V
Z
, ZENER VOLTAGE (V)
Fig. 2 Zener Breakdown Characteristics
2
10
T
A
, AMBIENT TEMPERATURE, (°C)
Fig. 1 Power Derating Curve
30
T
j
= 25°C
C10
C12
1000
T
j
= 25 °C
C
j
, JUNCTION CAPACITANCE (pF)
V
R
= 1V
V
R
= 2V
I
Z
, ZENER CURRENT (mA)
20
C15
100
V
R
= 1V
C18
Test current I
Z
2mA
C27
C33
C36
10
C22
Test current I
Z
5mA
V
R
= 2V
10
1
10
100
0
0
10
20
30
V
Z
, ZENER VOLTAGE (V)
Fig. 3 Zener Breakdown Characteristics
40
V
Z
, NOMINAL ZENER VOLTAGE (V)
Fig. 4 Junction Capacitance vs Nominal Zener Voltage
BZT52-C2V4S – BZT52-C39S
3
of 4
© 2002 Won-Top Electronics
ORDERING INFORMATION
Product No.
!
BZT52-CxxS-T1
BZT52-CxxS-T3
Package Type
SOD-323
SOD-323
Shipping Quantity
5000/Tape
& Reel
10000/Tape & Reel
Products listed in
bold
are WTE
Preferred
devices.
!
T1 suffix refers to a 7” reel. T3 suffix refers to a 13” reel.
Shipping quantity given is for minimum packing quantity only. For minimum order
quantity, please consult the Sales Department.
RECOMMENDED FOOTPRINT
0.062
(1.60)
0.047
(1.20)
0.055
(1.40)
inches(mm)
Won-Top Electronics Co., Ltd (WTE) has checked all information carefully and believes it to be correct and accurate. However, WTE cannot assume any
responsibility for inaccuracies. Furthermore, this information does not give the purchaser of semiconductor devices any license under patent rights to
manufacturer. WTE reserves the right to change any or all information herein without further notice.
WARNING:
DO NOT USE IN LIFE SUPPORT EQUIPMENT. WTE power semiconductor products are not authorized for use as critical components in life
support devices or systems without the express written approval.
Won-Top Electronics Co., Ltd.
No. 44 Yu Kang North 3rd Road, Chine Chen Dist., Kaohsiung, Taiwan
Phone:
886-7-822-5408 or 886-7-822-5410
Fax:
886-7-822-5417
Email:
sales@wontop.com
Internet:
http://www.wontop.com
We power your everyday.
© 2002 Won-Top Electronics
BZT52-C2V4S – BZT52-C39S
4 of 4
