1x2,2x2 Polarization
Maintaining Coupler
(patent pending)
Product Description
Agiltron’s 1x2, 2x2 Polarization Maintaining (PM) Coupler is used for
monitoring or splitting optical signals in Polarization Maintaining fiber. The
component is available in any coupling ratio from 1% to 50%. Employing
Agiltron’s proven advanced micro-optic design, it features low insertion loss,
epoxy-free optical path, high extinction ratio, compact package, high
reliability, and high stability. These high quality components have excellent
characteristics, making them an ideal choice for application in fiber
amplifier systems, pump lasers, and optical fiber sensors.
Features
·
·
·
·
·
·
Low Insertion Loss
Epoxy –Free Optical Path
High Extinction Ratio
Compact Package
High Reliability
&
Stability
Cost Effective
Performance Specifications
Parameter
Operating Wavelength
1
Excess Loss
2
Extinction Ratio
2
(ER)
Uniformity
Wavelength Dependent Loss
Directivity
Return Loss
2
Polarization Alignment
Optical Power Handling
Operating Temperature Range
Storage Temperature
Fiber Type
Package Dimension
1
2
Min
Max
Unit
nm
dB
dB
dB
dB
dB
dB
mW
o
C
o
C
mm
Applications
· Optical Fiber Amplifier
· Fiber Optic Sensor
· Instrumentation
1310±40, 1550±40
0.4
0.9
18
22
0.7
< 0.2
> 50
> 50
Slow Axis or Fast Axis
< 500
0 ~ 70
-40 ~ 85
Panda PM Fiber
Φ5.5x
34;
Φ3.2x
28
Other wavelength available
Excluding connectors
LASER COMPONENTS GmbH
Werner-von-Siemens-Str. 15, 82140 Olching, Germany, Phone: +49 8142 2864 0, Fax: +49 8142 2864 11, info@lasercomponents.com
1x2, 2x2 Polarization
Maintaining Coupler
Mechanical Dimensions (mm)
Ordering Information
MOPC-
Type
1x2 =12
2x2 = 22
Special = 0
Wavelength Coupling Ratio Package
1310 = 3
1550 = 5
C band = C
L Band = L
*C+L = 2
*Special = 0
1% = 1
2% = 2
3% = 3
5% = 5
10% = A
20% = B
30% = C
40% = D
50% = E
Special = 0
Fiber
Bare fiber
=1
Tight
buffer = 2
900um
loose tube
=3
Fiber Length Connector
0.25m= 1
0.5m = 2
1.0 m= 3
1.5m = 4
2.0m = 5
Special =0
None = 1
FC/PC = 2
FC/APC = 3
SC/PC = 4
SC/APC = 5
ST/PC = 6
LC = 7
Special = 0
∅3.2x28
=3 Panda
∅3.8x30
=2 250um = 2
∅5.5x34
=1 Panda
400um = 4
Panda
Special =0
RC80 = 8
Special=0
* Excess Loss higher than standard
www.lasercomponents.com
0 /0 / V1 /
/
/
.pdf
LASER COMPONENTS GmbH
Werner-von-Siemens-Str. 15, 82140 Olching, Germany, Phone: +49 8142 2864 0, Fax: +49 8142 2864 11, info@lasercomponents.com
