C6-Series Specifications
6.00L
x 3.50W x 1.20H
(mm)
PDI
C6-Series
is a hermetically sealed quartz crystal in a seam-welded ceramic
SMT package. This crystal, designed to meet your most demanding specification,
is available in standard or custom frequencies and/or with customized parameters.
PDI provides quick-turn sampling for your proto-typing needs, mass production
capability, and competitive pricing.
ex)
C6—25000X—F—C—D—08—R—X
*
FREQUENCY
09000X – 99999X
=
9.000MHz – 99.999MHz
C10000 – C15000
=
100.000MHz – 150.000MHz
MODE
F
= Fundamental
3
= 3rd Overtone
TOTAL
TOLERANCE
B
= +/-25
(Temp A & B)
C
= +/-50
D
= +/-100
S
= Special
OPERATING
TEMPERATURE
A
= 0 to +70°C
B
= -20 to +70°C
D
= -40 to +85°C
E
= -55 to +125°C
S
= Special
LOAD
08-99
= pF
SE =
Series
PACKAGE
R
= Tape & Reel
*(X) for standard or assigned for custimization.
Frequency Range – MHz
9.000000 to 10.999999
11.000000 to 11.999999
12.000000 to 15.999999
16.000000 to 80.000000
40.000000 to 150.000000
Operating
Mode
(CL)-Load
Capacitance
ESR
Ω (Max)
100
(C0)-Shunt
Capacitance
pF (Max)
Drive Level
uW (Typ)
Insulation
Resistance
Fundamental
8.0 pF
to
Series
80
60
40
100
7.0
100.0
500 MΩ
Minimum
at 100 Vdc
3rd Overtone
Parameter
Storage Temperature
Aging
Conditions
Per Year (±3.0 ppm Option)
Min
-55
-5.0
Typ
Max
+125
+5.0
Unit
°C
ppm
GR
EE
N
P
ROD
U
Compliant
EU 2002/95/EC
e
c
,
i
s
i
o
n
D
e
v
i
c
e
s
RoHS
NOTES:
Terminals are Au.
Other options are available, please consult factory.
All product is supplied
RoHS
and
REACH
compliant.
Product can be supplied on Tape and Reel, on reels of 1,000 units.
Not all Frequency/Temperature combinations are available.
Specifications subject to change without notice, last updated 4/1/13.
REV:
NA
SIZE:
A
CAGE:
A
I
n
c
.
CT
P
r
1
of
3
C6-Series
6.00 x 3.50 x 1.20
(mm)
PDI
C6-Series
is a hermetically sealed quartz crystal in a seam-welded
ceramic SMT package. This crystal, designed to meet your most demanding
specification, is available in standard or custom frequencies and/or
with customized parameters. PDI provides quick-turn sampling for your
proto-typing needs, mass production capability, and competitive pricing.
PIN
1
2
3
4
CONNECTION
Crystal
Ground/Cover
Crystal
Ground/Cover
Top View
.236±.008
[6.00±.20]
Last 7 digits of
PDI P/N
.138±.008
[3.50±.20]
PDI P/N
Frequency
Date Code
Recommended Land Pattern
.076
[1.95]
#4
Metal
.095
[2.40]
#3
Pin #1
.047±.008
[1.20±.20]
Traceability Code
.055
[1.40]
.044
[1.10]
#1
#2
.038
[0.97]
.112±.010
[2.84±.25]
Ceramic
.056
[1.42]
#2
#1
#4
#3
4 Places
.008R
[.20R]
.038
[0.97]
Bottom View
REV:
NA
SIZE:
A
CAGE:
A
2
of
3
C6-Series
6.00 x 3.50 x 1.20
(mm)
1.
Material: Black Conductive Polystyrene or equivalent.
2.
10 Sprocket Hole pitch cumulative tolerance of ±.008
3.
Camber in compliance with EIA 481
4.
Empty pockets: Trailing end (Minimum) 200 mm. and Leading end (Minimum) 400 mm.
5.
Pocket position relative to sprocket hole measured as true position of pocket, not pocket hole.
.012±.002
[0.30±.05]
Ø.059
[Ø1.50]
.079
[2.00]
.157 Typ.
[4.00 Typ.]
A
.069
[1.75]
.295
[7.50]
D/C P
P FKA
.530 ±.012
[16.00 ±.30]
D/C P
P FKA
D/C P
Section A-A
.315 Typ.
[8.00 Typ.]
A
.538
[16.20]
120°
Ø7.09
[Ø180.00]
3.15
[80.00]
REV:
NA
SIZE:
A
CAGE:
A
3
of
3
