Series YB2
Toggles
22mm Panel Seal Pushbuttons
General
Specifications
Electrical Capacity (Resistive Load)
Power Level (silver):
Logic Level (gold):
3A @ 125V AC or 3A @ 250V AC or 3A @ 30V DC
0.4VA maximum @ 28V AC/DC maximum
(Applicable Range 0.1mA ~ 0.1A @ 20mV ~ 28V)
Pushbuttons
Rockers
Other Ratings
Programmable
Illuminated PB
D
Contact Resistance:
Insulation Resistance:
Dielectric Strength:
Mechanical Life:
Electrical Life:
Nominal Operating Force:
Contact Timing:
Travel:
Keylocks
50 milliohms maximum for silver; 100 milliohms maximum for gold
200 megohms minimum @ 500V DC
1,000V AC minimum between contacts for 1 minute minimum;
1,500V AC minimum between contacts & case for 1 minute minimum
1,000,000 operations minimum for momentary circuit
200,000 operations minimum for maintained circuit
100,000 operations minimum
Single pole: 1.5N
Double pole: 3.0N
Nonshorting (break-before-make)
Pretravel .059” (1.5mm); Overtravel .059” (1.5mm); Total Travel .118” (3.0mm)
Materials & Finishes
Rotaries
Bezel:
Housing:
Base:
Movable Contactor:
Movable Contacts:
Stationary Contacts:
Switch Terminals:
Lamp Terminals:
Black: Glass fiber reinforced polyamide (UL94V-0); Silver: Polycarbonate
Glass fiber reinforced polyamide (UL94V-0)
Diallyl phthalate resin (UL94V-0)
Phosphor bronze with silver or gold plating
Phosphor bronze & silver alloy
Silver alloy or copper with gold plating
Phosphor bronze with tin plating
Phosphor bronze with tin plating
Slides
Tactiles
Environmental Data
Operating Temperature Range:
Humidity:
Vibration:
Shock:
Sealing:
–25°C through +50°C (–13°F through +122°F) for Illuminated
–25°C through +70°C (–13°F through +158°F) for Nonilluminated
90 ~ 95% humidity for 96 hours @ 40°C (104°F)
10 ~ 55Hz with peak-to-peak amplitude of 1.5mm traversing the frequency range & returning
in 1 minute; 3 right angled directions for 2 hours
50G (490m/s
2
) acceleration (tested in 6 right angled directions, with 5 shocks in each direction)
IP65 of IEC60529 standard
Touch
Tilt
Installation
Mounting Torque:
Soldering Time & Temperature:
0.785Nm (6.95 lb
•
in) maximum
Manual Soldering: 390°C maximum for 4 seconds maximum
Indicators
Standards & Certifications
Supplement
Accessories
Flammability Standards:
UL:
UL94V-0 housing, base & black or metallic silver bezel
File No. E44145
All solder lug models recognized at 3A @ 125/250V AC or 0.4VA @ 28V AC/DC maximum.
Add “/CUL” to end of part number to order cULus mark on switch.
D114
www.nkk.com
22mm Panel Seal Pushbuttons
Series YB2
Toggles
Distinctive
Characteristics
22mm pushbutton with the shortest above-panel dimension (1.8mm) in the industry
for splashproof design.
Meets IP65 of IEC60529 standards (similar to NEMA 4 and 13), providing
dust tight and splashproof panel seal protection.
Tamper resistant 19mm diameter actuator.
Short body of .965” (24.5mm) conserves behind-panel
space.
Distinctive long stroke and light touch actuation for clear
indication of circuit status.
Choice of cap colors includes clear, red, green, amber,
or metallic silver for enhanced panel appearance.
Metallic silver cap option has bright ring illumination.
Brilliant illumination with multiple LED colors.
Bezel color options in silver or black.
Available in momentary and alternate action with latchdown.
Crisp actuation and clear circuit status provided by snap-action
contact mechanism. Arc barrier protects against crossover.
Combination solder lug and .110” quick connect terminals. Terminals
are epoxy sealed to lock out flux, dust, solvents, and other contaminants,
as well as to secure terminals and improve contact stability.
Custom legends on actuator available.
D
www.nkk.com
D115
Supplement
Accessories
Indicators
Touch
Actual Size
Tilt
Tactiles
Slides
Rotaries
Keylocks
Programmable
Illuminated PB
Pushbuttons
Rockers
Series YB2
Toggles
22mm Panel Seal Pushbuttons
TYPICAL SWITCH ORDERING EXAMPLE
Toggles
YB2
1
5
C
W
C
K
W
01
6 F
JB
Rockers
Pushbuttons
Programmable
Illuminated PB
D
Poles
1
2
SPDT
DPDT
C
Contact Point
Normally Open and
Normally Closed
C
Shape
Round
01
Terminals
Solder Lug/.110”
(2.8mm) Quick Connect*
LED Colors
5C
5D
5F
Red
Amber
Green
LEDS
Bright LED
Resistor
No
Code
05
12
24
No Resistor
(not for
Green)
5-volt
12-volt
24-volt
JB
JS
CB
EB
FB
Cap Types & Colors
Lens/Diffuser Colors
Clear/White
Metallic Silver Cap/Clear Ring
Red/White
Yellow/White
Green/White
D
Keylocks
Circuits
5
6
ON
ON
(ON)
ON
W
( ) = Momentary
Panel Seal
With Panel Seal
K
S
Bezel
Black
Metallic Silver
W
G
Contact Materials
& Ratings
Silver
Rated 3A @ 125V AC
Gold
Rated 0.4VA maximum @
28V AC/DC maximum
Rotaries
Alternate Action
with Latchdown
Super Bright LED
6B
White
Green
Blue
Nonilluminated
N
No Lamp
S
JB
CB
JB
JS
6F
6G
Lens/Diffuser Cap Colors
Metallic Silver Cap/Clear Ring
Slides
Slides
Clear/White
IMPORTANT:
Switches are supplied without
cULus marking unless specified.
Specific models & ratings noted
on General Specifications page.
Tactiles
*
Wire harness & cable assemblies
offered only in Americas
Cap Color
Metallic Silver
Clear/White
Yellow/White
Green/White
Red/White
Tilt
DESCRIPTION FOR TYPICAL ORDERING EXAMPLE
EB
FB
YB215CWCKW01-6F-JB
Touch
Indicators
Black Bezel
Round Black Housing
SPDT
ON-(ON) Circuit
With Panel Seal
Silver Contacts with
3 Amp Rating
Solder Lug/.110” (2.8mm)
Quick Connect Terminals
Accessories
Supplement
D116
www.nkk.com
www.nkk.com
D117
Supplement
Accessories
Indicators
Green, Super Bright LED
LED Cap with Clear Lens
& White Diffuser
Touch
Tilt
Tactiles
Rotaries
LED & cap need to be the same color.
Yellow cap pairs with amber LED to achieve
amber illumination. Codes JB & JS may
be combined with all LED colors.
Keylocks
Programmable
Illuminated PB
Pushbuttons
Rockers
Series YB2
Toggles
22mm Panel Seal Pushbuttons
POLES & CIRCUITS
Rockers
Plunger Position
( ) = Momentary
Normal
Down
Connected Terminals
Normal
Down
Throw & Switch/Lamp Schematics
Notes: Switch is marked with NC, NO, COM, L+, L–.
Lamp circuit is isolated and requires an
external power source.
1 (COM)
Pole
Model
Pushbuttons
SP
YB215
YB216
YB225
YB226
ON
ON
ON
ON
(ON)
ON
(ON)
ON
1-3
1-2
SPDT
L (+)
3 NC
1
3 NC
2 NO
(COM)
6 NC
2 NO
4
L (+)
5 NO
(-) L
Programmable
Illuminated PB
D
DP
1-3 4-6
1-2 4-5
DPDT
(-) L
CONTACT POINT
C
Normally Open and Normally Closed
Contact points are both Normally Open and
Normally Closed.
PANEL SEAL
W
Panel Seal
Two o-rings provide
panel seal protection
meeting IP65 of
IEC60529 standards.
Rotaries
Keylocks
SHAPE
Slides
BEZEL
K
S
Black
Metallic Silver
C
Round
Tilt
Tactiles
CONTACT MATERIALS & RATINGS
Touch
W
Silver Contacts
Power Level: 3A @ 125/250V AC
G
Gold Contacts
Logic Level: 0.4VA max. @ 28V AC/DC max.
Switch base is red
Indicators
Switch base is green
Accessories
TERMINALS
01
Solder Lug/
.110” (2.8mm) Quick Connect
Epoxy Seal
(7.3)
.288
Supplement
(2.0)
(2.8)
.079
.110
(1.2)
.047
Thk = (0.5)
.020
D118
www.nkk.com
22mm Panel Seal Pushbuttons
BRIGHT & SUPER BRIGHT LEDS
Series YB2
Toggles
Electrical Specifications for Bright LED without Resistor
Bright
AT628
Colors
Available:
Forward Peak Current
Continuous Forward Current
T-1 Bi-pin
5C
LED Colors
I
FM
I
F
V
F
V
RM
∆I
F
Red
40
26
1.9
4
0.50
–25 ~ +50
Amber
40
26
2.0
4
mA
mA
V
V
mA/°C
°C
Forward Voltage
Reverse Peak Voltage
Current Reduction Rate Above 25°C
Ambient Temperature Range
D
(+)
(-)
Electrical Specifications for Bright Red & Amber LED with Resistor
Bright
AT634
Colors
Available:
Forward Peak Current
Continuous Forward Current
Forward Voltage
T-1
1
⁄
4
Bi-pin
5C
Red
5D
Amber
I
FM
I
F
V
F
V
RM
∆I
F
05
—
25
5
4
—
12
—
20
12
8
—
–25 ~ +50
AT634
(+)
24-volt,
4-element
with Resistor
24
—
10
24
16
—
Unit
mA
mA
V
V
mA/°C
°C
Slides
(-)
Reverse Peak Voltage
Current Reduction Rate Above 25°C
Ambient Temperature Range
AT634
12-volt,
4-element
with Resistor
AT634
5-volt,
(+)
2-element
with Resistor
Bright
AT636
Colors
Available:
(-)
(+)
(-)
ELECTROSTATIC
SENSITIVE DEVICES
ATTENTION
5F
Green
I
FM
I
F
V
F
V
RM
∆I
F
05
—
11
5
5
—
12
—
9.5
12
5
—
–25 ~ +50
24
—
8.7
24
5
—
Unit
mA
V
V
°C
mA/°C
mA
Forward Peak Current
T-1
1
⁄
4
Bi-pin
(+)
(-)
Forward Voltage
Reverse Peak Voltage
Current Reduction Rate Above 25°C
Ambient Temperature Range
5V
(+)
(-)
12V & 24V
Electrical Specifications for Super Bright LED
Super Bright
AT625G Blue
AT631B White
AT632F Green
ELECTROSTATIC
SENSITIVE DEVICES
ATTENTION
(+)
(-)
6B
Colors:
I
FM
I
F
V
F
V
RM
∆I
F
White
30
20
3.6
5
6F
Green
30
20
3.5
5
0.50
–25 ~ +50
6G
Blue
30
20
3.6
5
Unit
mA
mA
V
V
mA/°C
°C
D119
Continuous Forward Current
Forward Voltage
Reverse Peak Voltage
T-1 Bi-pin
Current Reduction Rate Above 25°C
Ambient Temperature Range
www.nkk.com
Supplement
Accessories
Forward Peak Current
Indicators
Touch
Tilt
Continuous Forward Current
Tactiles
Electrical Specifications for Bright Green LED with Resistor
Rotaries
Keylocks
Programmable
Illuminated PB
Pushbuttons
Red
5D
Amber
No Code
No Resistor
Unit
Rockers
The electrical specifications shown are determined at a basic temperature of 25°C. LED circuit is isolated and
requires an external power source. If the source voltage exceeds the rated voltage, a ballast resistor is required.
Base of AT634 and AT636 is Black for 5V, Light Blue for 12V and Gray for 24V.
