Coaxial
50Ω
High Power Amplifier
100W
20 to 500 MHz
New Product Announcement!
ZHL-100W-GAN+
The Big Deal
•
•
•
•
•
Click
here for
data sheet
High Efficiency, 50% typ.
High Output Power, 100W
GaN Output Stage
High Output IP2, +84 dBm typ.
High Output IP3, +60 dBm typ.
ZHL-100W-GAN+
Price $2395.00 (Qty. 1-9)
ZHL-100W-GANX+
Price $2320.00 (Qty. 1-9)
Product Overview
The Mini-Circuits ZHL-100W-GAN+ utilizes high power Galium Nitride (GaN) output stage, which results in
higher efficiency (50% typ.) as compared to GaAs, LDMOS and VDMOS counterparts. GaN FET’s boast a
maximum junction temperature of 250°C translating into higher operating temperatures without adversely
affecting the MTBF.
Key Features
Feature
High Efficiency
Advantages
Higher PAE results in significant cost savings over the operating life of amplifier.
Rugged Design
Extreme load mismatch such as open/short at output are tolerated without damaging the amplifiers.
Range of Protections
Over temperature, over voltage and reverse polarity protection add to the ruggedness of amplifier.
ISO 9001 ISO 14001 AS 9100
CERTIFIED
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
The Design Engineers Search Engine
IF/RF MICROWAVE COMPONENTS
Mini-Circuits
®
For detailed performance specs
& shopping online see web site
®
Provides ACTUAL Data Instantly at
minicircuits.com
Notes: 1.
Performance and quality attributes and conditions not expressly stated in this specification sheet are intended to be excluded and do not form a part of this specification sheet.
2.
Electrical specifications
and performance data contained herein are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.
3.
The parts covered by this specification sheet are subject to
Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled to the rights and benefits contained therein. For a full statement of the Standard
Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp.
