Datasheet> All Categories > semiconductor> Discrete semiconductor> SM4004

Preview

SM4004: Description1 A, 400 V, SILICON, SIGNAL DIODE; Categorysemiconductor Discrete semiconductor; File Size139KB，2 Pages; ManufacturerSHANGHAI SHANGLANG ELECTRONIC TECHNOLOGY CO., LTD.

Download Datasheet Parametric Compare View All

SM4004 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	SM4004	-	-	View	Buy Now

SM4004 Overview

1 A, 400 V, SILICON, SIGNAL DIODE

SM4004 Parametric

Parameter Name	Attribute value
Number of terminals	2
Number of components	1
state	DISCONTINUED
packaging shape	Rectangle
Package Size	SMALL OUTLINE
surface mount	Yes
Terminal form	C BEND
Terminal location	pair
Packaging Materials	Plastic/Epoxy
structure	single
Diode component materials	silicon
Diode type	Signal diode
Maximum repetitive peak reverse voltage	400 V
Maximum average forward current	1 A

Preview

Download Datasheet

View All

CE

CHENYI ELECTRONICS

SM4001 THRU SM4007

SURFACE MOUNT GALSS PASSIVATED JUNCTION RECTIFIER

Reverse Voltage - 50 to 1000 Volts

Forward Current - 1.0Ampere

FEATURES

. The plasitc package carries Underwrites Laboratory

Flammability Classification 94V-0

. For surface mounted applications

. Glass passivated junction

. High temperature soldering guaranteed: 250 /10 seconds, at terminals

MELF(DO-213AB)

MECHANICAL DATA

.

Case:

JEDEC SMA(DO-214AB) molded plastic

.

Terminals:

Lead solderable per MIL-STD-750,method 2026

.

Polarity:

Color band denotes cathode end

.

Mounting Position:

Any

.

Weight:

0.0041 ounce, 0.116 gram

Dimensions in inches and (millimeters)

MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS

(Ratings at 25

ambient temperature unless otherwise specified,Single phase,half wave 60Hz,resistive or inductive)

load. For capacitive load,derate current by 20%)

Symbols

Maximum Recurrent peak reverse voltage

Maximum RMS voltage

Maximum DC blocking voltage

Maximum average forward rectified current

0.375"(9.5mm) lead length at T

A

=75

Peak forward surge current (8.3ms

half sing wave superimposed on rated load

(JEDEC method)

Maximum instantaneous forward voltage at 1.0 A

Maximum reverse

current at rated DC Blocking Voltage

Typical Thermal Resistance

Typical Junction Capacitance(Note 1)

Maximum DC Blocking Voltage temperature

Operating and storage temperature range

T

A

=25

T

A

=125

(Note 2)

(Note 3)

R

C

J

T

A

T

J

T

STG

JA

JL

SM

4001

50

35

50

SM

4002

100

70

100

SM

4003

200

140

200

SM

4004

400

280

400

1.0

SM

4005

600

420

600

SM

4006

800

560

800

SM

4007

1000

700

100

Units

Volts

Amp

V

RRM

V

RMS

V

DC

I

(AV)

I

FSM

30.0

Amps

V

F

I

R

1.1

5.0

Volts

A

50.0

75.0

/W

30.0

15.0

+150.0

-65 to +175

pF

Notes:

1.Measured at 1MHz and applied reverse voltage of 4.0V DC.

1.Thermal resistance from junction to ambient, 0.24 X 0.24"(6.0 X 6.0mm) copper pads to each terminals

1.Thermal resistance from junction to terminals, 0.24 X 0.24"(6.0 X 6.0mm) copper pads to each terminals

Page 1 of 2
