MILITARY POWER THRU HOLE
MLP24
PART
NUMBER
MLP24-101L
MLP24-121L
MLP24-151L
MLP24-181L
MLP24-221L
MLP24-271L
MLP24-331L
MLP24-391L
MLP24-471L
MLP24-561L
MLP24-681L
MLP24-821L
MLP24-102L
MLP24-122L
MLP24-152L
MLP24-182L
MLP24-222L
MLP24-272L
MLP24-332L
MLP24-392L
MLP24-472L
MLP24-562L
MLP24-682L
MLP24-822L
MLP24-103L
MLP24-123L
MLP24-153L
MLP24-183L
MLP24-223L
MLP24-273L
MLP24-333L
MLP24-393L
MLP24-473L
MLP24-563L
MLP24-683L
MLP24-823L
MLP24-104L
MLP24-124L
MLP24-154L
MLP24-184L
MLP24-224L
MLP24-274L
MLP24-334L
MLP24-394L
MLP24-474L
MLP24-564L
MLP24-684L
MLP24-824L
MLP24-105L
MLP24-125L
MLP24-155L
MLP24-185L
MIL
DASH
No.
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
L
µH
DCR
MAX
Molded Unshielded High Current Power Inductor
MIL-PRF-27/369 Qualified
Ω
SLASH SHEET NO.
MILITARY DOCUMENT
GOWANDA SERIES
GOWANDA CAGE CODE
M27/369-XX
MLP24-XXXL
24226 YYWWL
M27/369-XX
MLP24-XXXL
24226 YYWWL
0.740 ± 0.010
(18.80 ± 0.25)
MIL DASH NO.
GOWANDA DASH NO.
TOLERANCE
YEAR/WEEK/LOT SYMBOL
1.250 (31.75)
MIN
(6.10 ± 0.25)
ø
0.032 ± 0.002
(0.813 ± 0.051)
ø
0.240 ± 0.010
in. (mm)
NOTES:
Operating Temperature Range:
-55°C to +130°C
Current Rating
is based on a 45°C temperature rise at
an ambient temperature of 85°C
Incremental Current
is the approximate value that will
cause a 5% maximum decrease in inductance at a zero
dc current
DWV
1000 Vrms @ Sea Level
500 Vrms @ 70,000 Feet
Weight Max:
2.50 grams
Marking:
Laser Mark (see diagram above)
Case:
Grade 5, encapsulated
Body color is black
Inductance is measured with no dc current at 1 kHz
When ordering, specify
tolerance:
MLP24-101L
Tolerance:
L
= 15%
Product Level:
All parts are approved to QPL Product
Level
M
When ordering by military part number, specify
Military Specification, Dash Number:
M27/369-01
Example of ordering by Military Part Number:
MLP24-101L
M27/369-01
TAPE AND REEL SPECS:
Pcs./Reel maximum:
Pitch between parts:
Tape width:
Reel diameter:
Class:
Gowanda Electronics is an Affiliate of
M27-369 FERRITE CORE
1.0
0.009
1.2
0.010
1.5
0.011
1.8
0.012
2.2
0.013
2.7
0.014
3.3
0.016
3.9
0.017
4.7
0.022
5.6
0.024
6.8
0.026
8.2
0.028
10
0.033
12
0.037
15
0.040
18
0.044
22
0.050
27
0.070
33
0.075
39
0.084
47
0.104
56
0.130
68
0.145
82
0.152
100
0.208
120
0.283
150
0.330
180
0.362
220
0.505
270
0.557
330
0.650
390
0.770
470
1.03
560
1.14
680
1.50
820
1.98
1000
2.30
1200
2.55
1500
3.00
1800
4.00
2200
4.40
2700
5.80
3300
6.56
3900
8.63
4700
10.1
5600
11.2
6800
15.0
8200
20.8
10000
23.4
12000
26.0
15000
36.0
18000
40.0
CURRENT
RATING
A DC MAX
6.27
5.95
5.67
5.43
5.22
5.03
4.70
4.56
4.01
3.84
3.69
3.55
3.27
3.09
2.97
2.84
2.66
2.25
2.17
2.05
1.84
1.65
1.56
1.53
1.30
1.12
1.04
0.99
0.84
0.80
0.74
0.68
0.59
0.56
0.49
0.42
0.39
0.37
0.34
0.30
0.28
0.25
0.23
0.20
0.19
0.18
0.15
0.13
0.12
0.12
0.10
0.09
INC I
A DC
6.4
5.8
5.2
4.8
4.3
3.9
3.5
3.2
2.9
2.7
2.5
2.2
2.0
1.8
1.6
1.5
1.4
1.2
1.1
1.0
0.93
0.85
0.77
0.71
0.64
0.58
0.52
0.48
0.43
0.39
0.35
0.32
0.29
0.27
0.25
0.22
0.20
0.18
0.16
0.15
0.14
0.12
0.11
0.10
0.09
0.09
0.08
0.07
0.06
0.06
0.05
0.05
1000
0.400 in.
2.500 in.
12 in.
2
One Magnetics Pkwy, Gowanda, NY 14070
(f ) 716-532-2702
sales@gowanda.com
REV:
A
04062020
(t) 716-532-2234
www.GowandaComponentsGroup.com
www.gowanda.com
