3.0V/5.0V LOW PROFILE TCXO
MODEL: FOX801 SERIES
FEATURES
•
•
•
•
2.0mm Height Max
Low Cost
Clipped Sine Output
Tape and Reel (2,000 pcs. STD)
OPTIONS
•
•
•
•
'A' Version - 5.0V
'B' Version - 3.0V
VCTCXO - AE/BE Version
VCTCXO - AH/BH Version
(trimmerless)
• PART NUMBER SELECTION
Learn More - Internet Required
Part Number
250-Frequency-xxxxx
251-Frequency-xxxxx
252-Frequency-xxxxx
253-Frequency-xxxxx
254-Frequency-xxxxx
255-Frequency-xxxxx
Frequency
Operating
Model
Stability Temperature (ºC)
Number
FOX801A
-30 ~ +75
see table
FOX801AE see table
-30 ~ +75
FOX801AH see table
-30 ~ +75
FOX801B
-30 ~ +75
see table
FOX801BE see table
-30 ~ +75
FOX801BH see table
-30 ~ +75
Discontinued
Internet required
Learn more about:
Part Marking Identification
Tape and Reel Specification
Frequency
Range (MHz)
10.000 ~ 50.000
10.000 ~ 50.000
10.000 ~ 50.000
10.000 ~ 50.000
10.000 ~ 50.000
10.000 ~ 50.000
• ELECTRICAL CHARACTERISTICS
PARAMETERS
Frequency Range (F
O
)
Temperature Range
Operating
(T
OPR
)
Storage
(T
STG
)
Initial Frequency Tolerance (@25ºC)
Vc = 2.5V (A Series)
1
FOX801A/B/AE/BE
Vc = 1.5V (B Series)
1
FOX801AH/BH
Supply Voltage
(V
DD
)
A Version
B Version
Input Current
(I
DD
)
Frequency Stability
Over Temperature Range
Over Supply Voltage Change
(V
DD
± 5%)
Over Load Change
(10Ω ± 10% // 10pF ± 10%)
Output Waveform
(Clipped Sine)
Peak-to-Peak Level (Vp-p)
A Version: 10.000 ~ 15.999 MHz
A Version: 16.000 ~ 50.000 MHz
B Version: 10.000 ~ 15.999 MHz
B Version: 16.000 ~ 50.000 MHz
Output Load
Frequency Adjustment (Internal Trimmer)
FOX801A/B/AE/BE
FOX801AH/BH
Voltage Control Option (VCTCXO)
1
A Version
(Vc=2.5±2.0V)
FOX801A/B
B Version
(Vc=1.5±1.0V)
FOX801AE/BE
FOX801AH/BH
Aging per year
1
MAX
(unless otherwise noted)
10.000 ~ 50.000 MHz
-30ºC ~ +75ºC
-35ºC ~ +80ºC
±0.5PPM
±2.0PPM
5.0V ± 5%
3.0V ± 5%
2.0mA
±2.5PPM
±0.3PPM
±0.3PPM
1.0V Min
0.8V Min
0.8V Min
0.7V Min
10KΩ // 10pF
±3.0PPM
Trimmerless
None
±5.0PPM Min
±8.0PPM Min
±0.8PPM
All dimensions are in millimeters.
For proper operation, a control voltage (Vc) must be applied to pin 1 on VCTCXOs.
All specifications subject to change without notice.
Rev. 6/1/04
88
FOXElectronics
5570 Enterprise Parkway Fort Myers, Florida 33905 USA +1(239)693-0099 FAX +1(239)693-1554
http://www.foxonline.com
© 2004 FOX ELECTRONICS
