DIAMOND
Fiber Optic Components
Specifications:
Single mode
Multimode
Units Test conditions
FSMA
∅
2.5
CONNECTOR
HMS-10/AG SM
HFS-10/AG MM
Insertion loss
(IL)
Return loss
(RL)*
Repeatability
Service life
Operating temperature
Storage temperature
Strain relief
(cable)
typ 0.2
45
max 0.5
typ 0.2
40
max 0.5
dB
IEC 1300-3-4;
λ
= 1300/1550 nm
dB
IEC 1300-3-6;
λ
= 1300/1550 nm
dB
IL: max
±
0.1
min 1000 matings
-40
-40
+85
+90
-40
-40
+85
+90
°
C
°
C
100
(signal interruption at 10)
N
* Measured with high resolution reflectometer HP 8504A
APPLICATIONS:
Telecommunications, CATV, LAN, MAN, WAN,
Test & Measurement, Industry, Medical,
Sensors
With SMA connectors with
∅
2.5 mm ferrules
Fiber alignment: SM: Active Core Alignment
via patented two-step
crimping process
MM: Via patented crimping
process
Polish:
Convex (PC)
Ferrule:
∅
2.5 mm tungsten carbide
with copper-nickel alloy
insert, spring loaded (10 N),
anti-rotation keyed, with air
pressure relief guides
Mating adapter: Tungsten carbide in Inox
housing
External parts:
Inox, 1/4"-36 UNS SMA
threading
Cable retention: Coupled to ferrule on cable
ODs
≤
3.5 mm, signal
interruption at 10 N
- Unterminated connector
- Terminated patch cable, patchcord or pigtail
See ordering information on reverse
See section on Tools and Equipment
COMPATIBILITY:
DESIGN/MATERIALS:
AVAILABLE AS:
TERMINATION TOOLS
AND EQUIPMENT:
DIAMOND SA
CH-6616 LOSONE
Via dei Patrizi 5
Tel. ++41-91/785 45 45
Fax ++41-91/785 45 00
e-mail: diamond@diamond-fo.com
Specifications subject to change
without notice
002-037-205P002028
CONNECTOR
SINGLE MODE
Type designation:
Ferrule materials:
External parts:
Polish geometry:
Dimensions
Fiber/Cable
9/125/900
9/125/900/2100
9/125/900/2500
9/125/900/3000
9/125/900/3500
FSMA
HMS-10/AG
Tungsten carbide/copper-nickel alloy insert
Inox
Convex (PC)
1/4"36 UNS-2B
55 max
Order Number
Unterminated connector
242 - 000 - 001 L 000
242 - 000 - 002 L 000
242 - 000 - 003 L 000
242 - 000 - 004 L 000
242 - 000 - 005 L 000
Terminated assembly
242 - xxx - 001 L xxx
242 - xxx - 002 L xxx
242 - xxx - 003 L xxx
242 - xxx - 004 L xxx
242 - xxx - 005 L xxx
1
2
3
4
38 rigid
Ex 8
Ø 2.5
Ex 6
12.3
Connectors for other fiber and cable dimensions available upon request
MULTIMODE
Type designation:
Ferrule materials:
External parts:
Polish geometry:
Dimensions
Fiber/Cable
50/125/900
50/125/900/2100
50/125/900/2500
50/125/900/3000
50/125/900/3500
HFS-10/AG
Tungsten carbide/copper-nickel alloy insert
Inox
Convex (PC)
1/4"36 UNS-2B
55 max
Order Number
Unterminated connector
241 - 000 - 001 L 000
241 - 000 - 002 L 000
241 - 000 - 003 L 000
241 - 000 - 004 L 000
241 - 000 - 005 L 000
Terminated assembly
241 - xxx - 001 L xxx
241 - xxx - 002 L xxx
241 - xxx - 003 L xxx
241 - xxx - 004 L xxx
241 - xxx - 005 L xxx
1
2
3
4
38 rigid
Ex 8
Ø 2.5
Ex 6
12.3
Connectors for other fiber and cable dimensions available upon request
1/4"36 UNS-2B
MATING ADAPTER
Type designation:
Material
Mating sleeve
Zirconia
External parts
Inox
23.5
Ex 5.5
1.2
Ø 2.5
MMT-10.2/A
Order Number
147 - 301 - 901 V 001
Mounting
perforation
9.5
6.5
+0
.2
0
7.2
Ex 8
3.8
Max wall tickness
7 mm
Order Number Codes
1
Connector code
2
Connector code for termination on other end of assembly
- For pigtails:
insert 000
- For patch assemblies: insert connector code for other connector
3
Code for fiber or cable
4
Length in meters
See ordering information for additional details
