Oscilent Corporation | 610 - 613 Series Ceramic Resonator
Page 1 of 2
Ceramic Resonator
Series Number
Package
Description
Last Modified
610 ~ 613
FEATURES
- Low profile
- Wide frequency range
- Extended temperature ceramic resonator
- High stability
- RoHS Compliant
ZTA Ceramic
Low Profile
Jan. 07 2007
OPERATING CONDITIONS / ELECTRICAL CHARACTERISTICS
Series No.
610
611
612
613
Type
ZTA-MG
ZTA-MT
ZTA-MX
ZTA-MGL
Frequency
Range
(MHz)
1.79 ~ 8.00
6.00 ~ 13.00
12.00 ~ 20.00
20.01 ~ 25.99
26.00 ~ 60.00
3.00 ~ 8.00
±0.5%
-20 ~ +80
Frequency
Accuracy
@25°
Operating
Temperature
°C
Stability in
Temperature
(-20 ~ +80°C)
±0.3%
±0.3%
±0.3%
±0.3%
±0.3%
±0.3%
Aging for Ten
Years
-
±0.3%
±0.3%
±0.3%
±0.3%
±0.3%
±0.3%
.
IC (MG,MT) : 1/6TC4069UBPx2
IC (MX) : 1/6TC74HCU04x2
VDD : +5V
Series No.
610
611
Type
ZTA-MG
ZTA-MT
Frequency
(MHz)
1.79 ~ 8.00
6.01 ~ 13.00
12.00 ~ 23.99
612
ZTA-MX
24.00 ~ 31.99
32.00 ~ 60.00
Dimensions (max.)
W
10.0
10.0
10.0
10.0
10.0
H
7.5
10.0
10.0
7.5
6.5
C1 & C2 Values for Test Circuit
C1 (pF)
30
30
30
15
5
C2 (pF)
30
30
30
15
5
Oscilent Corporation | 610 - 613 Series Ceramic Resonator
Page 2 of 2
613
ZTA-MGL
3.00 ~ 8.00
10.0
5.5
30
30
.
PART NUMBER GUIDE
Part Number
Frequency
Frequency Accuracy
(%)
Operating
Temp (
°C
)
Packaging**
612
610 to 613 (see table
above)
- 20.0M
e.g. -12.1M = 12.10 MHz
Range =1.79 ~ 60.0 MHz
- 03
Blank*
= ±0.5%
-03
= ±0.3%
W
Blank*
=
-20 ~ +80
-N
=
-40 ~ +85
-W
=
-40 ~ +125
- TR
Blank*
= Bulk
-TT
= Ammo Pack (Qty =
2K)
NOTE:
Deviations on all parameters available. Please consult Oscilent for details.
DEFINITIONS:
Click on the characteristic names above, for definitions of the particular characteristic.
*STANDARDS:
"Blank" part number selections, indicate standard variables for the particular characteristic.
**PACKAGING:
Click on the packaging name above for Ammo Pack specifications
CALL
949.252.0522
18195 East McDurmott Street . Building D . Irvine . CA 92614 . USA
Fax: 949.252.0599 . E-Mail: Sales@Oscilent.com
