AD4C213
1 Form A / 1 Form B
400V / 25
Ω
MOSFET Output Solid State Relay
Description
The AD4C213 is composed of two isolated relays; one
normally open and one normally closed. Each relay has a
bi-directional, single-pole, single-throw contact. Completely
independent of its counterpart, each consists of an LED
that activates an integrated circuit, which in turn drives a
pair of DMOS transistors. These transistors are protected
with free-wheeling diodes that can handle up to 1.5A of
inrush current, making the relay ideal for switching lamps
and highly inductive loads.
The AD4C213 comes standard in a miniature 8 pin DIP
package making it ideal for high-density board applications.
Features
1 Form A / 1 Form B Integrated in 1 Package
Low Input Control Current (1.5mA TYP)
150mA Maximum Continuous Load Current
Low On Resistance (25 MAX – Both Poles)
High Isolation Voltage (2.5kV
RMS
, 3.75kV
RMS
-H Option)
Long Life / High Reliability
RoHS / Pb-Free / REACH Compliant
Agency Approvals
UL/C-UL:
VDE:
File # E201932
File # 40035191 (EN 60747-5-2)
Applications
Meter Reading Systems
Multiplexers
Data Acquisition
Medical Equipment
Battery Monitoring
Home / Safety Security Systems
Absolute Maximum Ratings
The values indicated are absolute stress ratings. Functional
operation of the device is not implied at these or any
conditions in excess of those defined in electrical
characteristics section of this document. Exposure to
absolute Maximum Ratings may cause permanent damage
to the device and may adversely affect reliability.
Storage Temperature …………………………..-55 to +125°C
Operating Temperature …………………………-40 to +85°C
Continuous Input Current ………………………………..50mA
Transient Input Current ………………….……………..500mA
Reverse Input Control Voltage …………..…………………5V
Input Power Dissipation …………………………………40mW
Output Power Dissipation ……………………………..800mW
Solder Temperature – Wave (10sec)……………….….260°C
Solder Temperature – IR Reflow (10sec)….…………..260°C
Schematic Diagram
Ordering Information
Part Number
AD4C213
AD4C213-H
AD4C213-S
AD4C213-HS
AD4C213-STR
AD4C213-HSTR
Description
8 pin DIP, (50/Tube)
3.75kV
RMS
V
ISO
, 8 pin DIP, (50/Tube)
8 pin SMD, (50/Tube)
3.75kV
RMS
, 8 pin SMD, (50/Tube)
8 pin SMD, Tape and Reel (1000/Reel)
3.75kV
RMS
, 8 pin SMD, Tape and Reel (1000/Reel)
NOTE: Suffixes listed above are not included in marking on
device for part number identification
© 2014 Solid State Optronics
•
San José, CA
www.ssousa.com
•
+1.408.293.4600
Page 1 of 9
AD4C213 /H/S/TR
Rev 2.00 (03/05/2014)
001801
AD4C213
1 Form A / 1 Form B
400V / 25
Ω
MOSFET Output Solid State Relay
Electrical Characteristics,
T
A
= 25°C (unless otherwise specified)
Parameter
Input Specifications
LED Forward Voltage
LED Reverse Voltage
Turn-On Current (Form A – Normally Open)
Turn-On Current (Form B – Normally Closed)
Turn-Off Current (Form A – Normally Open)
Turn-Off Current (Form B – Normally Open)
V
F
BV
R
I
F(NO)
I
F(NC)
I
FOFF(NO)
I
FOFF(NC)
-
5
-
-
-
-
1.2
-
1.5
0.5
0.5
1.5
1.5
-
5
-
-
5
V
V
mA
mA
mA
mA
I
F
= 10mA
I
R
= 10μA
I
O
= 150mA
I
O
= 150mA
I
O
= 150mA
I
O
= 150mA
Symbol
Min.
Typ.
Max.
Units
Test Conditions
Output Specifications – Form A (Normally Open)
Blocking Voltage
Continuous Load Current
On Resistance
Leakage Current
Output Capacitance
Offset Voltage
Turn-On Time
Turn-Off Time
V
B
I
O
R
ON
I
Oleak
C
OUT
V
OFFSET
T
ON
T
OFF
400
-
-
-
-
-
-
-
-
-
17
0.2
25
-
1
0.05
-
150
25
1
-
0.2
5
5
V
mA
Ω
A
pF
mV
mS
mS
I
O
=1A
I
F
=5mA
I
F
=5mA, I
O
=150mA
I
F
=0mA, V
O
=400V
V
O
=25V, f=1.0MHz
I
F
=5mA
I
F
=5mA, I
O
=150mA
I
F
=0mA, I
O
=150mA
Output Specifications – Form B (Normally Closed)
Blocking Voltage
Continuous Load Current
On Resistance
Leakage Current
Output Capacitance
Offset Voltage
Turn-On Time
Turn-Off Time
V
B
I
O
R
ON
I
Oleak
C
OUT
V
OFFSET
T
ON
T
OFF
400
-
-
-
-
-
-
-
-
-
20
0.2
15
-
0.1
1
-
150
25
1
-
0.2
5
5
V
mA
Ω
A
pF
mV
mS
mS
I
F
=5mA, I
O
=1A
I
F
=0mA
I
F
=0mA, I
O
=150mA
I
F
=5mA, V
O
=400V
I
F
=5mA, V
O
=25V, f=1.0MHz
I
F
=0mA
I
F
=0mA, I
O
=150mA
I
F
=5mA, I
O
=150mA
Coupled Specifications
Coupled Capacitance
Contact Transient Ratio
C
COUPLED
-
-
2,000
3
7,000
-
0
pF
V/S
dV = 50V
Isolation Specifications
Isolation Voltage
-H Option
Input-Output Resistance
V
ISO
V
ISO
R
I-O
2,500
3,750
-
-
-
10
12
-
-
-
V
RMS
V
RMS
RH
≤
50%, t=1min
RH
≤
50%, t=1min
V
I-O
= 500V
DC
© 2014 Solid State Optronics
•
San José, CA
www.ssousa.com
•
+1.408.293.4600
Page 2 of 9
AD4C213 /H/S/TR
Rev 2.00 (03/05/2014)
001801
AD4C213
1 Form A / 1 Form B
400V / 25
Ω
MOSFET Output Solid State Relay
AD4C213 Solder Temperature Profile Recommendations
(1)
Infrared Reflow:
Refer to the following figure as an example of an optimal temperature profile for single occurrence infrared reflow.
Soldering process should not exceed temperature or time limits expressed herein. Surface temperature of device
package should not exceed 250ºC:
G
F
D
E
H
B
A
C
Figure 1
Process
Step
A
B
C
D
E
F
G
H
Description
Preheat Start Temperature (ºC)
Preheat Finish Temperature (ºC)
Preheat Time (s)
Melting Temperature (ºC)
Time above Melting Temperature (s)
Peak Temperature, at Terminal (ºC)
Dwell Time at Peak Temperature (s)
Cool-down (ºC/s)
150ºC
180ºC
90 - 120s
230ºC
30s
260ºC
10s
<6ºC/s
Parameter
(2)
Wave Solder:
Maximum Temperature:
Maximum Time:
Pre-heating:
Single Occurrence
260ºC (at terminal)
10s
100 - 150ºC (30 - 90s)
(3)
Hand Solder:
Maximum Temperature:
Maximum Time:
Single Occurrence
350ºC
3s
(at tip of soldering iron)
© 2014 Solid State Optronics
•
San José, CA
www.ssousa.com
•
+1.408.293.4600
Page 5 of 9
AD4C213 /H/S/TR
Rev 2.00 (03/05/2014)
001801
