CAT16-PC5F12LF: DescriptionConcave Chip Array; File Size350KB，2 Pages; ManufacturerBourns; Websitehttp://www.bourns.com

Download Datasheet View All

CAT16-PC5F12LF Overview

Concave Chip Array

Preview

Download Datasheet

View All

Features

■

HIGH PERFORMANCE TERMINATION

NETWORK

Miniaturized circuitry and packaging

for space reduction

Designed for gigabit communication

networks

■

Controlled impedance

RoHS compliant*

CAT16-PC5F12LF - Concave Chip Array

Electrical Characteristics

Resistance

R1 ...............................................70 ohms

R2 .............................................187 ohms

Tolerance ............................................±1 %

TCR........................................±200 ppm/ ˚C

Temperature Range .........-55 ˚C to +125 ˚C

Max. Operating Voltage ....................5 VDC

Max. Power Resistance ................ .0625 W

Solderability .....................>95 % Coverage

Product Dimensions

.60

.10

(.024

.004)

1.60

.15

(.063

.060)

.80

.10

(.031

.004)

.45

.10

(.018

.004)

.30

.10 DIA.

(.012

.004)

.40

.10

(.016

.004)

For Standard Values Used in Capacitors,

Inductors, and Resistors,

click here.

DIMENSIONS ARE:

6.40

.15

(.253

.006)

.40

.10

(.016

.004)

(INCHES)

Packaging Specifications

4000 pcs - per 7 " reel

2.00

0.20

(.079

.008)

4.0

.10

(.157

.004)

2.0

.05

(.079

.002)

0.9

0.1

(.035

.004)

0.5

DIA.

(.512

.020)

60.0

1.0

DIA.

(2.36

.039)

12.0

0.2

(.472

.008)

0.5

(.827

.020)

15.4

1.0

(.606

.039)

178.0

2.0

(7.008

.080)

6.9

0.2

(.272

.008)

5.5

0.1

(.217

.004)

4.0

±.10

(.158

±.004)

1.5 +.10/-0

(.060 +.004/-0)

1.75

.10

(.069

.004)

13.0

0.3

(.512

.012)

Derating Curve

Rated power in percentage (%)

Land Pattern

Solder resist

100

-55

(ϒ Ambient temperature

125

0.7 to 0.9

(.028 to .035)

Land

Chip resistor array CAT

2.0 to 2.2

(.079 to .087)

Schematic

0.4 to 0.45

(.016 to .0178)

0.80

(.032)

11/06

*RoHS Directive 2002/95/EC Jan 27 2003 including Annex.

Specifications are subject to change without notice.

Customers should verify actual device performance in their specific applications.
