CLE135, CLE130E, CLE130W
940nm High Efficiency GaAs/AlGaAs IREDs
features
•
higher power output
•
cathode connected to case
•
TO-46 header with three lens options
•
different package styles provide
flexible design options
description
The original Clairex CLE130 series has
been upgraded. The new series
features current state of the art
GaAs/AlGaAs technology for increased
quantum efficiency. The chip substrate
is N type material resulting in the case
being common to the cathode. The
original configuration can still be
supplied as a special order. Three
different lens options are offered.
Contact Clairex for other electrical and
package options.
®
Clairex
Technologies, Inc.
absolute maximum ratings
(T
A
= 25°C unless otherwise stated)
storage temperature
CLE135 and CLE130W ............................................................. -65°C to +150°C
CLE130E ................................................................................... -40°C to +125°C
operating temperature
CLE135 and CLE130W ............................................................. -65°C to +125°C
CLE130E ................................................................................... -40°C to +100°C
lead soldering temperature
(1)
.........................................................................260°C
continuous forward current
(2)
....................................................................... 100mA
peak forward current (1.0ms pulse width, 10% duty cycle)................................. 1A
reverse voltage ................................................................................................... 5V
(3)
continuous power dissipation ................................................................... 200mW
notes:
1. 0.06” (1.5mm) from the header for 5 seconds maximum.
2. Derate linearly 0.80mA/°C from 25°C free air temperature to T
A
= +125°C.
3. Derate linearly 1.60mW/°C from 25°C free air temperature to T
A
= +125°C.
electrical characteristics
(T
A
= 25°C unless otherwise noted)
symbol parameter
CLE130 Series
V
F
I
R
λ
p
BW
t
r,
t
f
Forward voltage
Reverse current
Peak wavelength
Spectral bandwidth
Output rise and fall time
min
-
-
-
-
-
typ
1.5
-
940
50
700
max
1.8
10
-
-
-
units
V
µA
nm
nm
ns
test conditions
I
F
= 100mA
V
R
= 3V
I
F
= 100mA
I
F
= 20mA
I
F
= 100mA
CLE130E
P
O
P
O
θ
HP
Total output power
Total output power
Emission angle at half power points
Total output power
Total output power
Emission angle at half power points
-
2.0
-
-
1.5
-
12.5
2.5
80
10
2.0
70
-
-
-
-
-
-
mW
mW
deg.
mW
mW
deg.
I
F
= 100mA
I
F
= 20mA
I
F
= 20mA
I
F
= 100mA
I
F
= 20mA
I
F
= 20mA
CLE130W
P
O
P
O
θ
HP
CLE135
P
O
Total output power
-
10
-
mW
I
F
= 100mA
(4)
2
E
e
Irradiance
-
2.0
-
mW/cm
I
F
= 100mA
(4)
2
E
e
Irradiance
0.4
0.5
-
mW/cm
I
F
= 20mA
θ
HP
Emission angle at half power points
-
22
-
deg.
I
F
= 20mA
note:
4. E
e
is a measure of irradiance (power/unit area) within a 0.444" (1.128cm) diameter area, centered on the
mechanical axis of the device and spaced 2.54" (6.45cm) from the lens side of the tab. This is geometrically
equivalent to a 10° cone.
Clairex reserves the right to make changes at any time to improve design and to provide the best possible product.
Clairex Technologies, Inc.
Phone: 972-265-4900
1301 East Plano Parkway
Fax: 972-265-4949
Plano, Texas 75074-8524
www.clairex.com
