05126
Only One Name Means ProTek’Tion™
GBLC03 - GBLC24C
uLtRa LOW CaPaCItaNCE tVS aRRaY
DESCRIPtION
The GBLCxx and GBLCxxC Series are ultra low capacitance transient voltage suppressor arrays, designed to protect
applications such as portable electronics and SMART phones. This series is available in both unidirectional and bidi-
rectional configurations and is rated at 350 Watts for an 8/20µs waveshape.
The GBLCxx and GBLCxxC Series meets IEC 61000-4-2 (ESD) and IEC 61000-4-4 (EFT) requirements. At higher operat-
ing frequencies or faster edge rates, insertion loss and signal integrity are a major concern. This series offers a ultra
low capacitance and low leakage current in a miniature SOD-323 package.
SOD-323 PaCkaGE
FEatuRES
• Compatible with IEC 61000-4-2 (ESD): Air - 15kV, Contact - 8kV
Exceeds Level 4: Handles 10kV Contact & 25kV Air Discharge
• Compatible with IEC 61000-4-4 (EFT): 40A - 5/50ns
• Compatible with IEC 61000-4-5 (Surge)
• 350 Watts Peak Pulse Power per Line (tp = 8/20µs)
• Replacement for MLV (0805)
• Unidirectional & Bidirectional Configuration
• Protects One Power or I/O Port
• ESD Protection > 25kV
• Low Clamping Voltage
• Available in Multiple Voltages Ranging From 3V to 24V
• Ultra Low Capacitance: 3pF (Typical)
• RoHS Compliant
• REACH Compliant
aPPLICatIONS
•
•
•
•
Ethernet 10/100/1000 Base T
SMART Phones
Handheld - Wireless Systems
USB Interface
MEChaNICaL ChaRaCtERIStICS
•
•
•
•
Molded JEDEC SOD-323 Package
Approximate Weight: 5 milligrams
Lead-Free Pure-Tin Plating (Annealed)
Solder Reflow Temperature:
Pure-Tin - Sn, 100: 260-270°C
• 8mm Tape and Reel Per EIA Standard 481
• Flammability Rating UL 94V-0
PIN CONFIGuRatIONS
1
1
2
UNIDIRECTIONAL
2
BIDIRECTIONAL
05126.R16 3/13
Page 1
www.protekdevices.com
05126
Only One Name Means ProTek’Tion™
GBLC03 - GBLC24C
tYPICaL DEVICE ChaRaCtERIStICS
MaXIMuM RatINGS
@ 25°C unless Otherwise Specified
PaRaMEtER
Peak Pulse Power (tp = 8/20µs) - See Figure 1
Operating Temperature
Storage Temperature
SYMBOL
P
PP
T
A
T
STG
VaLuE
350
-55 to 150
-55 to 150
uNItS
Watts
°C
°C
ELECtRICaL ChaRaCtERIStICS PER LINE
@ 25°C unless Otherwise Specified
PaRt
NuMBER
(Note 1 -2)
DEVICE
MaRkING
RatED
StaND-OFF
VOLtaGE
V
WM
VOLtS
GBLC03
GBLC03C
GBLC05
GBLC05C
GBLC08
GBLC08C
GBLC12
GBLC12C
GBLC15
GBLC15C
GBLC24
GBLC24C
NOtES
3
3C
5
5C
8
8C
2
2C
6
6C
4
4C
3.3
3.3
5.0
5.0
8.0
8.0
12.0
12.0
15.0
15.0
24.0
24.0
MINIMuM
BREakDOWN
VOLtaGE
@ 1ma
V
(BR)
VOLtS
4.0
4.0
6.0
6.0
8.5
8.5
13.3
13.3
16.7
16.7
26.7
26.7
MaXIMuM
CLaMPING
VOLtaGE
(Fig. 2)
@ IP = 1a
V
C
VOLtS
7.0
7.0
9.8
9.8
13.4
13.4
19.0
19.0
24.0
24.0
43.0
43.0
MaXIMuM
LEakaGE
CuRRENt
@V
WM
I
D
µa
5
5
5
5
2
2
1
1
1
1
1
1
tYPICaL
CaPaCItaNCE
@0V, 1Mhz
C
pF
3
3
3
3
3
3
3
3
3
3
3
3
1. Part numbers with an additional “C” suffix are bidirectional devices, i.e., GBLC05C.
2. Unidirectional Only: Positive potential is applied from pin 1 to 2.
05126.R16 3/13
Page 2
www.protekdevices.com
05126
Only One Name Means ProTek’Tion™
GBLC03 - GBLC24C
tYPICaL DEVICE ChaRaCtERIStICS
FIGuRE 1
PEak PuLSE POWER VS PuLSE tIME
10,000
P
PP
- Peak Pulse Power - Watts
1,000
350W, 8/20µs Waveform
100
10
0.1
1
10
100
t
d
- Pulse Duration - µs
1,000
10,000
120
I
PP
- Peak Pulse Current - % of I
PP
FIGuRE 2
PuLSE WaVE FORM
t
f
Peak Value I
PP
TEST
WAVEFORM
PARAMETERS
t
f
= 8µs
t
d
= 20µs
100
80
60
40
20
0
0
5
e
-t
t
d
= t/(I
PP
/2)
10
15
t - time - µs
20
25
30
05126.R16 3/13
Page 3
www.protekdevices.com
05126
Only One Name Means ProTek’Tion™
GBLC03 - GBLC24C
SPICE MODEL
FIGuRE 1
SPICE MODEL
I/O
ABD
LCRD
LCRD
LCRD
Lg
0.6nH
Lg
0.6nH
ABD
ABD
I/O
LCRD
UNIDIRECTIONAL
BIDIRECTIONAL
ABD - Avalanche Breakdown Diode (TVS)
LCRD: Low Capacitance Rectifier Diode
Lg - Lead Inductance
taBLE 1 - SPICE PaRaMEtERS
PaRaMEtER
BV
IBV
C
jo
I
S
Vj
M
N
R
S
TT
EG
uNIt
V
µA
pF
A
V
-
-
Ohms
s
eV
aBD(tVS)
See Table 2
1
See Table 2
See Table 2
0.6
0.33
1
See Table 2
1E-8
1.11
LCRD
200
0.01
6
1E-11
0.6
0.33
1
0.75
1E-9
1.11
PaRt NuMBER
GBLC03 & GBLC03C
GBLC05 & GBLC05C
GBLC08 & GBLC08C
GBLC12 & GBLC12C
GBLC15 & GBLC15C
GBLC18 & GBLC18C
GBLC24 & GBLC24C
taBLE 2 - aBD SPECIFIC SPICE PaRaMEtERS
I
S
(aMPS)
B
V
(VOLtS)
C
jo
(
p
F)
4.0
6.0
8.5
13.3
16.7
20.0
26.7
438
284
146
123
102
80
61
1E-11
1E-11
1E-11
1E-13
1E-13
1E-13
1E-13
R
s
(OhMS)
0.21
0.14
0.28
0.40
0.52
0.80
1.54
05126.R16 3/13
Page 4
www.protekdevices.com
05126
Only One Name Means ProTek’Tion™
GBLC03 - GBLC24C
SOD-323 PaCkaGE INFORMatION
OutLINE DIMENSIONS
DIM
A
B
C
D
E
F
H
L
NOtES
C
A
E
B
MILLIMEtERS
MIN
1.60
1.15
2.39
0.80
0.25
0.10
-
0.20
INChES
MIN
0.063
0.045
0.094
0.031
0.010
0.004
-
0.008
MaX
1.90
1.45
2.70
1.10
0.40
0.20
0.10
-
MaX
0.075
0.057
0.106
0.043
0.016
0.008
0.004
-
F
D
H
1. Controlling dimension: millimeters.
2. Dimensioning and tolerances per ANSI Y14.5M, 1985.
3. Dimensions are exclusive of mold flash and metal burrs.
L
PaD LaYOut DIMENSIONS
DIM
A
B
C
NOtES
A
MILLIMEtERS
MIN
2.87
0.66
0.66
INChES
MIN
0.113
0.026
0.026
MaX
3.12
0.91
0.91
MaX
0.123
0.036
0.036
B
C
1. Controlling dimension: millimeters.
05126.R16 3/13
Page 5
www.protekdevices.com
