F. MECHANICAL CHARACTERISTICS
機械特性
No.
1
Item
Solderability
焊錫附著性
Test Condition
Evaluation standard
2
Soldering Heat
Resistance
焊錫耐熱性
90% min. lead terminals shall be
Lead terminals are immersed in rosin for 5 seconds and then immersed wet with solder. (Except the
edge of terminal)
in solder bath of +270±5℃ for 3±1 seconds.
浸入端子部½附著焊鍚
90%以
端子部½浸入松香溶液
5
秒後,再浸入+270±5℃溶融焊鍚½中
3±1
秒.
上.(末端斷面不算)
Lead terminal are immersed up to 1.5mm from sounder’s body in soilder
bath of +300±5℃ for 3± 0.5 seconds or +260±5℃ for 10±1 seconds.
No interference in operation
操½上無任½不良
距離端子根部1.5mm 的½½,浸入+300±5℃的焊鍚½
3±0.5
秒,
或+260±5℃ 的焊錫½10±1 秒.
3
Terminal Mechanical The force 10 seconds of 9.8N (1.0kg) is applied to each terminal in axial
No damage and cutting off
Strength
direction.
端子不鬆動, 不脫½
端子強度
各端子的軸方向½以9.8N
(1.0kg)的力量10
秒.
Vibration
振動試驗
Buzzer shall be measured after being applied vibration of amplitude of The value of oscillation
1.5mm with 10 to 55hz band of vibration frequency to each of 3 frequency/ current consumption
should be in 10% compared with
per-pendicular directions for 2 hours.
initial ones .The SPL should be
振動週波數
10∼55HZ、全振幅 1.5mm
於
X.Y.Z 3
個方向,各
2
小時.
in ± 10dB compared with initial
The part only shall be dropped from a height of 75cm onto a 40mm thick one.
諧振頻率與消耗電流變化量須在
wooden board 3 times in 3 axes (X.Y.Z). (a total of 9 times).
±10%內.
輸出音壓變化量須在
單體從75 公分高處,
X.Y.Z.3
個方向,各3 回,½於
40mm
厚木板上.
±10dB
內.
4
5
Drop test
½下測試
G. ENVIRONMENT TEST
環境測試
No.
1
2
3
Item
High temp. test
高溫測試
Low temp. test
½溫測試
Humidity test
相對濕度測試
Test Condition
Evaluation standard
4
Temp. cycle test
溫度循環試驗
After being placed in a chamber at +95℃ for 240 hours
½於+95℃環境中
240
小時
After being placed in a chamber with –40℃for 240 hours
½於-40℃ 環境中
240
小時
After being placed in a chamber at +40℃ and 90±5% relative humidity
for 240 hours
Being placed for 4 hours at
½於+40℃, 相對濕度
90±5%
環境中
240
小時
+25℃, buzzer shall be
The part shall be subjected to 5 cycles. One cycle shall be consist of： measured. The value of
單體承受溫度循環測試
5
次,其循環內容如圖示：
oscillation frequency/ current
consumption should be in±10%
+95℃
compared with initial ones .The
SPL should be in±10dB
+25℃
+25℃
compared with initial one.
經測試後, 靜½於+25℃（室溫）
環境中4 小時後
,
諧振頻率與消耗
-40℃
電流變化量須在±10%內. 輸出音
壓變化量須在±10dB 內.
0.5hr 0.5hr 0.25 0.5hr
0.5hr
0.5hr 0.25
3hours
志豐電子股½有限公司
KINGSTATE ELECTRONICS CORP
4/5
KPEG212A
H. RELIABILITY TEST
信賴性測試
No.
Item
Test condition
Evaluation standard
Being placed for 4 hours at
+25℃, buzzer shall be
measured. The value of
oscillation frequency/ current
consumption should be in ±10%
compared with initial ones .The
SPL should be in ±10dB
compared with initial one.
經測試後, 靜½於+25℃（室溫）
環境中
4
小時後,諧振頻率與消耗
電流變化量須在±10%內. 輸出音
壓變化量須在±10dB 內.
1
1.Continuous life test
高溫½½測試(連續)
48 hours continuous operation at +70℃ with rated voltage applied.
在+70℃環境下,以額定電壓連續操½48 小時.
Operating life
2.Intermittent life test
室溫½½測試(間歇)
test
A duty cycle of 1 minute on, 1 minutes off, a minimum of 5000 times at room
½½測試
temp.( +25±2℃)and rated voltage applied.
在室溫下(+25±2℃), 以額定電壓操½, 通電1 分鐘/斷電1 分鐘,測試
5000
次循環.
TEST CONDITION.
Standard Test Condition
一般測試條件
Judgment Test Condition
爭議時測試條件
:
:
:
:
a) Temperature : +5 ~ +35℃
a)
溫度
: +5 ~ +35℃
a) Temperature : +25 ± 2℃
a)
溫度
: +25 ± 2℃
b) Humidity : 45-85%
b)
濕度
: 45-85%
b) Humidity : 60-70%
b)
濕度
: 60-70%
c) Pressure : 860-1060mbar
c)
氣壓
: 860-1060mbar
c) Pressure : 860-1060mbar
c)
氣壓
: 860-1060mbar
I. PACKING STANDARD
包裝規格
12x5+11x5+10=125PCS
Out Box
(2LAYER =250PCS)
Out Box
Carton Box
(10PCS Out Box)
550
mm
m
330
m
Out Box
Carton Box
310mmx248mmx49mm
550mmx330mmx290mm
2x125PCS=250PCS
250PCSx10=2,500PCS
志豐電子股½有限公司
KINGSTATE ELECTRONICS CORP
5/5
290mm
KPEG212A
