Part Number

Search

X1G004291004400

Description
LVPECL Output Clock Oscillator,
CategoryPassive components    oscillator
File Size348KB,7 Pages
ManufacturerSeiko Epson Corporation
Download Datasheet Parametric Compare View All

X1G004291004400 Overview

LVPECL Output Clock Oscillator,

X1G004291004400 Parametric

Parameter NameAttribute value
Objectid7318457545
Reach Compliance Codeunknown
Other featuresSTANDBY; ENABLE/DISABLE FUNCTION; TR, 10 INCH
maximum descent time0.0004 ns
Frequency Adjustment - MechanicalNO
frequency stability50%
Installation featuresSURFACE MOUNT
Nominal operating frequency400 MHz
Maximum operating temperature70 °C
Minimum operating temperature-20 °C
Oscillator typeLVPECL
Output load50 OHM
physical size7.0mm x 5.0mm x 1.4mm
longest rise time0.0004 ns
Maximum supply voltage3.63 V
Minimum supply voltage2.25 V
surface mountYES
maximum symmetry55/45 %
Clock OSC
SG7050EAN
SG7050EAN 400.000000MHz KJBA
Product name
X1G0042910044xx
Product Number / Ordering code
Please refer to the 9.Packing information about xx (last 2 digits)
Output waveform
LV-PECL
Pb free / Complies with EU RoHS directive
Reference weight Typ. 149 mg
1.Absolute maximum ratings
Parameter
Symbol
Maximum supply voltage
Storage temperature
Input voltage
Min.
-0.3
-40
-0.3
Typ.
-
-
-
Max.
+4
+125
Vcc+0.3
Unit
V
ºC
V
Conditions / Remarks
-
Storage as single product
ST or OE Terminal
Vcc-GND
T_stg
Vin
2.Specifications(characteristics)
Parameter
Symbol
Output frequency
Supply voltage
Operating temperature
Frequency tolerance
Current consumption
Stand-by current
Disable current
Symmetry
Output voltage(LV-PECL)
Output load condition(ECL)
Input voltage
Rise time
Fall time
Start-up time
Jitter
Min.
2.25
-20
-50
-
-
-
45
Vcc-1.0
-
-
70% Vcc
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-5
Typ.
400.0000
-
-
-
-
-
-
-
-
-
50
-
-
-
-
-
11.3
1.3
5.3
29.5
7.8
0.35
-39
-73
-100
-112
-122
-127
-128
-
Max.
3.63
+70
50
65
-
20.0
55
-
Vcc-1.62
-
-
30% Vcc
350
350
3
-
-
-
-
-
-
-
-
-
-
-
-
-
5
Unit
MHz
V
ºC
x10
-6
mA
mA
mA
%
V
V
Conditions / Remarks
-
-
-
OE = Vcc , L_ECL = 50 ohm
-
OE=GND
At output crossing point
-
-
Terminated to Vcc - 2.0V
OE Terminal
OE Terminal
Phase jitter
Phase noise
f0
Vcc
T_use
f_tol
Icc
I_std
I_dis
SYM
V
OH
V
OL
L_ECL
V
IH
V
IL
t
r
tf
t_str
t
DJ
T
RJ
t
RMS
t
p-p
t
acc
t
PJ
L(f)
ps
ps
ms
ps
ps
ps
ps
ps
ps
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
-6
At 20% to 80% output swing
At 20% to 80% output swing
-
Deterministic Jitter Vcc=2.5V
Random Jitter Vcc=2.5V
δ(RMS of total distribution) Vcc=2.5V
Peak to Peak Vcc=2.5V
Accumulated Jitter(δ) n=2 to 50000 cycles Vcc=2.5V
Offset Frequency: 12kHz to 20MHz Vcc=2.5V
Offset 1Hz Vcc=2.5V
Offset 10Hz Vcc=2.5V
Offset 100Hz Vcc=2.5V
Offset 1kHz Vcc=2.5V
Offset 10kHz Vcc=2.5V
Offset 100kHz Vcc=2.5V
Offset 1MHz Vcc=2.5V
Frequency aging
f_age
x10 /Year
@+25ºC first year
