OISA1310AST1113 Overview

Polarization Insensitive Fiber Isolator Array

Polarization Insensitive Fiber
Isolator Array (Single Stage)
OISA Series
Product Description
Oplink’s single-stage, multi-port isolator is an array device with the identical
package size of a single-port isolator. It offers port options of dual or triple
ports on both input and output sides. The Oplink isolator array minimizes
back reflection and back scattering in the reverse direction for any state of
polarization. It features low cost with high performance including low inser-
tion loss, low channel cross talk, high return loss, low polarization dependent
loss (PDL) and low polarization mode dispersion (PMD). Oplink’s innovative
array solution provides significant space savings in EDFA array or multi stage
EDFA applications.
L
CH1
CH2
CH3
Ø
CH1
CH2
CH3
Performance Specificationns
OISA Series
Premium
Grade A
Unit
Features
Operating Wavelength Range
Insertion Loss
[1]
1310 ± 15 or
1480 ± 15 or
1528 ~ 1564 or
1570 ~ 1605
< 0.6
> 22
< 0.1
< 0.25
< 0.05
> 55
> 50
<2
Corning SMF-28
250µm Bare Fiber
0 to +70
-40 to +85
(ø) 5.5 x (L) 34.0
< 0.8
> 21
< 0.15
nm
dB
dB
dB
ps
ps
dB
dB
W
Wide Operating Wavelength Range
and Temperature Range
Low Insertion Loss
High Isolation
Ultra Low PDL & Option for Ultra Low
PMD
Highly Stable & Reliable
Epoxy-free Optical Path
Compact Package Size
Isolation (over operating wavelength
range, 0~70°C, all SOP)
Polarization Dependent Loss
Polarization Mode
Dispersion
Channel Crosstalk
Return Loss
Maximum Power Handling
Fiber Type
Fiber Jacket
Operating Temperature
Storage Temperature
Package Dimensions
[3]
Pigtail Coloring (both sides)
(Standard)
(Low PMD)
Applications
Fiberoptic Amplifiers
CATV Fiberoptic Links
WDM Systems
Fiberoptic Instruments
Transmitters and Fiber Lasers
Laboratory R&D
Arrayed Modules
°C
°C
mm
Ch.1 = Red, Ch.2 = Black, Ch.3 = clear
[1] The maximum IL is under all states of polarization and within the full operating temperature and wavelength ranges
specified.
[2] All the parameters are excluding connectors.
[3] The mechanical tolerance should be +/-0.2mm on all package dimensions unless otherwise custom specified.
S0056 - R04. 20120123
